4.3 Installing Battery
Note: Use only original battery or a battery approved by the manufacturer.
Do not use any other unauthorized batteries.
1. Remove the back cover.
2. Install battery by sliding it into battery compartment
with contacts facing upwards to the left.
3. Replace the back cover.
4.4 Charging Battery
Notes:
ƒ The battery comes partially charged.
ƒ Charge the battery only indoors and in dry locations.
ƒ Insert the Micro-USB plug carefully. It only fits one way.
ƒ Normal charge time takes 3-4 hours.
ƒ Do not leave the phone charging for more than 12 hours.
ƒ To maximise battery life limit multimedia functions.
ƒ Charge the battery between 0°C and 45°C. Charge the battery promptly
when flat.
ƒ With poor network conditions (less than 2 bars) battery life is reduced.
ƒ When not using the phone for long periods remove the battery.
1. Connect the provided charger to a suitable power outlet.
2. Plug the other end with micro-USB plug to phone's charging port.
3. The LED torch lights up during the charging process.
4. The
icon is displayed and the LED torch goes off once the battery is fully charged.
5. Once phone has been fully charged disconnect the charger from phone's charging port
and from the power outlet.
For charging alternatively use provided charging cradle.
WARNING: When a travel charger and its accessories are used to charge
the battery, check first whether they have been made or approved by the
manufacturer. Using other accessories can damage your mobile phone and
present a risk.
4.5 Switching Phone On for the First Time
1. Press and hold
2. Enter provided PIN code.
3. Select desired menu language (e.g. English) using direction keys (
confirm with Left Soft key.
4. Set date and time using direction keys (up/down/left/right) and confirm with Left Soft
key.
key.
9
and
) and
