TELEFUNKEN TM 9.1 CLASSY
OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM 9.1 CLASSY and is the answer not in the manual?

Questions and answers

Related Manuals for Telefunken TM 9.1 CLASSY

Summary of Contents for Telefunken TM 9.1 CLASSY

  • Page 1 TELEFUNKEN TM 9.1 CLASSY OPERATING INSTRUCTIONS...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Contents DESCRIPTION ............................3 DISPLAY ICONS ............................3 TO START ..............................4 SETTING UP THE PHONE ......................... 5 USEFUL TIPS ............................. 5 HOW TO CHANGE THE LANGUAGE ......................5 HOW TO SET THE TIME AND DATE ......................6 USING THE KEYPAD TO ENTER TEXT ......................

  • Page 4: Description

    DESCRIPTION Earpiece Keypad Screen "Lock" key. Press 3 (OK), then * to (un)lock your phone OK/Options key 0/Space key Dial key and Call log access Profile key: press and hold to change the sound profile: Silent/Standard. In texting mode: symbol entry mode selection key Back key, Phonebook access Micro-USB socket End call key: Turn the phone on/off...

  • Page 5: To Start

    TO START 1. Installing the SIM card(s) NOTICE: Your phone is a dual SIM model, so it can support two SIM cards at the same time. Switch off your mobile phone. The slots for the SIM card are located on the back of the phone. Follow the diagram below to install the SIM card(s).

  • Page 6: Setting Up The Phone

    4. Charging the battery To charge the battery, connect the micro-USB connector to the phone charging port and the adaptor to a wall socket. The icon is displayed once the battery is fully charged. You can then disconnect the charger from the phone and from the wall socket. WARNING: When a travel charger and its accessories are used to charge the battery, please check first whether they have been made or approved by the manufacturer.

  • Page 7: How To Set The Time And Date

    HOW TO SET THE TIME AND DATE If you are using the phone for the first time, you will be automatically prompted to set the time and date. 1. Go to the Main menu , select Settings 2. Select Phone 3.
  • Page 8 Add to contacts list Send a message Send a text message to the selected contact Call Call the selected contact Delete Delete the selected contact from the address book Delete several To delete several contacts at the same time Import/Export Copy the contact from the phone to the SIM card and vice versa, or import/export the contact to/from the memory card Send a vCard...
  • Page 9 To delete several contacts at once 1. Press Options to select Delete several 2. Select one of the contacts to be deleted by pressing the centre key 3. Repeat step 2 to select all the contacts you would like to delete 4.

  • Page 10: How To Make/Answer A Call

    To Import/Export one/more contact(s) 1. Press Options to select Import/Export 2. To import one or more contacts from the memory card, select Import contacts . Then choose the file from which you would like to import the contact(s) 3. To export one or more contacts from the phone or SIM card, select Export contacts 4.

  • Page 11: How To Consult The Lists Of Calls

    To answer a call Press the key to answer a call. Press the red button to reject the call and transfer it to your voicemail. Press this key to end the call. Once the call is connected, the following options will be available: During the conversation, press Options to view the list of options: Put on hold Put the current call on hold...

  • Page 12: Reading And Writing Text Messages

    READING AND WRITING TEXT MESSAGES In the Message menu, you can consult, send and receive your text messages. When you receive a new message, the icon is displayed. Press Read to view the message. You will access the Inbox menu, where all received messages are stored.
  • Page 13 Call Call the contact Lock Lock a message so that it cannot be deleted Move Transfer a message from the SIM to the phone memory and vice versa Copy Copy a message to the SIM or phone memory Tick Tick off one or more messages Sort inbox messages by Time of receipt, Contacts, Sort Subject or Type...
  • Page 14 SIM 1 message centre View and edit the message centre number for SIM 1 SIM 2 message centre View and edit the message centre number for SIM 2 Message validity period Select the validity period for the message sent Status report Display or do not display the receipt report Save sent messages Choose if you would like to save messages sent on the phone...

  • Page 15: Multimedia

    Settings Personalize several settings for video mode. Your options are: "Size", "Anti- flicker", "Audio", "Video format" and "Memory". Press OK to select and change these settings AUDIO To play audio files on the audio player, download your choice of MP3 files from the memory card's audio folder into one of the music lists.
  • Page 16 Rename Rename the selected video Copy Copy the selected video Find Search for a video Sort Sort the videos by "Name", "Time", "Size" or "Type" Tick Tick one or more videos Picture Browse your available photos. To view a picture, press the centre key. In the picture gallery, press Options to display the following options: Delete Delete the selected picture...
  • Page 17 Background listening Listen to the radio while browsing the phone menu Memory Select whether you would like to use the phone's memory or SD card Video When you access the video player, the phone automatically searches for available videos. Press the left key to display the possible options: Local playback list View the list of videos available...

  • Page 18: Tools

    Delete Delete the selected recording Details View details of the selected recording Rename Rename the selected recording Copy Copy the selected recording Find Search for a recording Sort Sort the folders/files by "Name", "Time", "Size" or "Type" Tick Tick one or more recordings Folders This sub-menu will show you all picture, audio, video and other files saved on your memory card or your phone.
  • Page 19 Ringtone: you can choose between four pre-recorded Ringtones in the mobile phone, More ringtones to select a ringtone from a files on your memory card or Recorded ringtone to use a ringtone recorded with the voice recorder. Press OK to confirm your selection. Repeat: you can choose between Once (the alarm rings at the set time and is then deactivated), Every day (the alarm rings every day at the set time) or Days (select the days when you would like the alarm to ring).

  • Page 20: Settings

    E-book To open an e-book, search for it in the phone's external memory folders where you previously saved it. PROFILES Manage the phone's sound profile. You can use six different sound profiles: Standard, Silent, Indoor, Outdoor, Earpiece and Bluetooth. You can also create your own profiles. Profiles can be activated/deactivated or personalized in this menu.
  • Page 21 Calls Double SIM : Choose to (de)activate standby mode for each SIM card or (de)activate airplane mode. You can set this if you would like to reply with the SIM used for the call or with a text message. Choose a name for each SIM card.

  • Page 22: Safety Instructions

    Privacy: protect certain menus with a password. Enter the password to use this option. By default, the password is: 0000. Automatic keypad locking: choose to lock the keypad automatically if the phone is not used for 5 seconds, 15 seconds, 30 seconds, 1 minute or 5 minutes. Locking the keypad: activate or deactivate automatic keypad locking.
  • Page 23 Network services and costs This mobile phone is approved for use on the following GSM networks: 900/1800 MHz. To use the device, you should subscribe to the services of a mobile service provider. The use of such services can generate data transfer costs.

  • Page 24: Disposal Instructions

    Precautions for electronic devices Some electronic devices are susceptible to electromagnetic interference from mobile phones if inadequately shielded, such as the electronics system of vehicles; please consult the manufacturers of devices before using the phone, if necessary. Safety and general use in vehicles The safety airbag, brakes, speed control system and injection system shouldn’t be affected by wireless transmission.

  • Page 25: Warranty And After-Sales Service

    The TELEFUNKEN TM 9.1 phone was put on the European market for the first time in June 2016. Specific Absorption Rate (SAR) This device complies with international safety standards for exposure to radio waves. The value recorded for the Telefunken TM 9.1 Classy is 1,564 W/kg for the body and 1,17 W/kg for the head (average...
  • Page 26 measurement for 10 g of organic tissue). The maximum limit according to the WHO is 2 W / kg (average measurement for 10 g of organic tissue). This device meets RF exposure guidelines when used against the head or when positioned at least 0.5 cm away from the body.
