IDS SMS Duo V2
Training Guide
Introduction
The IDS SMS Duo V2 offers powerful, versatile and highly configurable sms reporting and
control capabilities, which will keep you informed and in control of your 805 alarm system when
away from your premises. The SMS Duo V2 module works with the IDS 805 Alarm Panel, and
consists of an X-SMS module and an interface that connects it to the 805 panel. The SMS Duo
V2 can also work as a standalone device with two end of line zone inputs and two outputs.
In this training guide we will cover step by step how to install the IDS SMS Duo V2 module, we
will explain the concept of programming the unit and go through some of the main commands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IDS SMS Duo V2
Summary of Contents for IDS SMS Duo V2
- Page 1 V2 can also work as a standalone device with two end of line zone inputs and two outputs. In this training guide we will cover step by step how to install the IDS SMS Duo V2 module, we will explain the concept of programming the unit and go through some of the main commands.
- Page 2 IDS805 alarm panel. The serial connection between the SMS Duo V2 module and the 805 Alarm Panel is shown in the image above. 1.2.
- Page 3 1.3. Defaulting the X-SMS Module It is recommended to default the X-SMS module on a new installation. To default the X-SMS module, hold the ‘Restore Defaults’ button on power up until the ‘Heart Beat LED’ comes on, ± 3 seconds. 1.4.
- Page 4 Interface Board Jumpers The interface board has 3 jumpers to enable/disable certain hardware. Jumper 1: Configures what device the interface is connected to. Keep off for SMS Duo V2. (Reports as zone 9) Jumper 2: Enables zone 1 on the interface board.
- Page 5 The cell networks limit the number of characters to 160 per SMS. The SMS Duo V2 doesn’t store any user codes, it just sends them to the 805 Panel. Make sure the code you use has the appropriate permissions in the 805 Alarm Panel.
- Page 6 You can also name the cell number when adding it to the SMS Duo V2. The SMS should look like this: 1234 add master 0740492481:Sid All phone number commands: Action Code Command Ext. Command Data Add phone number as a...
- Page 7 By default there is a threshold of 20 SMSes per day to a single phone number. You can increase or decrease this threshold by sending a threshold command. The threshold is reset every day at midnight based on the SMS Duo V2 time. To increase the threshold to 50 SMSes you will use the following information: Code –...
- Page 8 Disarm P1,P2 *Remember the SMS Duo v2 onboard zones are in partition 2 and needs to be armed to be violated. Except when using the Duo in standalone mode zones 9 & 10 are 24 hour zones and don’t need to be armed.
- Page 9 2.7. Panel Status Using the SMS Duo V2 you are able to check the status of various parts of the panel, such as Arm Status, Zone Status, Bypass Status, and PGM Status. To check the arm status of partition 1 you will use the following information: Code –...
- Page 10 Data – P1 (Partition number or name) The SMS should look like this: 1234 zone status p1 The SMS Duo V2 will reply as follows if zone 3 is bypassed and zone 6 is violated: “IDS SMS. P1 disarmed. Z03: bypassed.
- Page 11 2.8. Naming With the SMS Duo V2 you are able to name users, codes, sites, partitions, PGMs, and zones to better your reporting and to make sending commands easier. To name partition 1 you will use the following information: Code – 1234 (a valid user code in partition 1) Command –...
- Page 12 SMS Duo V2 it will perform that command. To set up this feature you must first set the command on the SMS Duo V2 and then enable it on any numbers that you want to have access to this feature.
- Page 13 2.11. Hints The SMS Duo V2 will send you a hint based on the command you send it. These hints are to help you know what other related commands you can send. By default hints is turned on for each user.
- Page 14 1234 Disarm Disarm P2 1234 Disarm Disarm P1 & P2 1234 Disarm P1,P2 Setting Time Set the SMS Duo v2 to retrieve the 1234 Time 061 458 2504 time once a week Naming Assigning a site name 1234 Site Name Home Name partition 1 “Main House”...
- Page 15 Action Code Command Ext. Comm Data Burglary/Restore Reporting Description Make burglary description open 1234 Burglary Name 6:Open Make restore description close 1234 Restore Name 6:Close Missed Call Function Set the missed call command to 1234 Missedcall ‘1234 pgm pulseh 1’ ‘1234 pgm pulseh 1’...
- Page 16 Action Code Command Ext. Comm Data List ext commands for 1234 Help Unbypass unbypassing List ext commands for airtime 1234 Help Airtime List ext commands for lockout 1234 Help Lockout List ext commands for PGMs 1234 Help List ext commands for zones 1234 Help Zone...
