IDS400 USER MANUAL Contents Glossary ..............7 Introduction to IDS400 ..........8 Notes ..................8 Understanding the Keypad Indicators ....9 Operation of the Keypad ........10 System Information ..........10 Programmed Functions ............10 User Codes ................11 Zone Information ..............11 Arming the System ........... - Page 6 IDS400 USER MANUAL 10. Alarm Memory ............18 10.1 To Display Alarm Memory: ........... 18 11. User Codes .............. 18 11.1 Entering New and Changing Old User Codes....... 18 11.2 Deleting User Codes ............19 12. Stay Zones ..............19 12.1 To Program Stay Zones ............
-
Page 7: Glossary
IDS400 USER MANUAL Glossary Alarm This is the history of the most recent violations that Memory occurred the last time the system was armed. To set the system into the ARMED mode. In this mode, violating a zone will activate an alarm condition and, if the system is programmed accordingly, will cause a reporting code to be sent to the monitoring company. -
Page 8: Introduction To Ids400
IDS400 USER MANUAL 1. Introduction to the IDS400 The IDS400 Control Panel is manufactured to the highest specification and will provide many years of service if correctly installed and main- tained. The unit is designed for simple operation yet provides the maximum protection for you, your family or business. -
Page 9: Understanding The Keypad Indicators
IDS400 USER MANUAL correctly, and properly placed to provide notification of an alarm condition. Smoke and heat detectors may not detect all fire situations. 2. Understanding the Keypad Indicators See illustration on inside front cover. Indicator (Red) ARMED u l l Indicator (Red) AWAY u l l... -
Page 10: Operation Of The Keypad
IDS400 USER MANUAL 3. Operation of the Keypad To ensure correct operation of your security system it is essential to familiarize yourself with the use of the keypad. The keypad has an audible indicator, command entry keys and zone and system status lights. The keypad is used to send commands to the system and to display the current system status. -
Page 11: User Codes
IDS400 USER MANUAL 4.2 User Codes 4.3 Zone Information t i x c t i t i x IDS400 USER MANUAL NO. 700-204-01A ISSUED NOV 2000 VER 1.01... -
Page 12: Arming The System
IDS400 USER MANUAL 5. Arming the System There are various options for arming the system 5.1 Away Arming Procedure [#] + [USER CODE] Ensure that the READY indicator is illuminated; if not, check that all protected doors and windows are closed and that motion has ceased in areas covered by motion detectors. -
Page 13: Quick Stay Arming
IDS400 USER MANUAL If necessary, close the front door. Press the [#] key to cancel any unintended entries. Enter a valid [ USER CODE open the front door. If the front door is opened the DO NOT system will arm in AWAY mode. The ARMED indicator will illuminate and the audible indicator will sound on and off for the duration of the exit delay. -
Page 14: Zone Bypassing
IDS400 USER MANUAL The alarm will arm immediately and the remote ARM indicator will illuminate. If programmed to do so, the siren will sound briefly - verify with your installer. NOTE: If a remote control is used, it is advisable to have the siren sound on arm and disarm function enabled. -
Page 15: To Un-Bypass Zone
IDS400 USER MANUAL 6.2 To Un-Bypass Zone [-] + [ZONE NUMBER] Press the [-] key. Press the number corresponding to the currently bypassed zone The zone indicator will extinguish - the zone is now active. 7. Disarming the System [#] + [USER CODE] To disarm the system, enter a valid [ USER CODE ] before the expiry of the entry delay. -
Page 16: To Disarm With A Key-Switch Or Remote Control
IDS400 USER MANUAL 7.1 To Disarm with a Key-Switch or Remote Control This option is not standard; check with your installer to verify installation. Press the remote button or twist and release the key-switch. The system will disarm and the remote indicator will extinguish. If programmed to do so, the siren will sound briefly - verify with your installer. -
Page 17: Duress Code
IDS400 USER MANUAL keypad audible indicator sounds. A PANIC ALARM can also be activated by any FIXED PANIC or buttons which have been installed. REMOTE PANIC If audible panic option has been selected, the siren will sound, and the PANIC REPORTING CODE will be transmitted to the monitoring company. -
Page 18: Alarm Memory
IDS400 USER MANUAL 10. Alarm Memory The Alarm Memory displays any zones which were violated or bypassed the last time the system was armed. 10.1 To Display Alarm Memory: [0] - Hold down the key until the keypad audible indicator sounds. If the ARMED indicator is flashing before you disarm the system, a violation has occurred. -
Page 19: Deleting User Codes
IDS400 USER MANUAL followed by the [-] key. The ARMED and READY indicators will begin to flash simultaneously indicating that the correct master code was entered. If an invalid code was entered the keypad will beep three times. Enter the [ ] you wish to change (1-15) USER CODE NUMBER followed by the [-] key. -
Page 20: To Cancel The Stay Zones
IDS400 USER MANUAL 12.2 To Cancel the Stay Zones Summary: [ 3] + [-] + [ZONE NUMBER] + [#] If an area programmed as a STAY zone will no longer be violated during STAY arming, then the STAY status of such a zone should be cancelled. -
Page 21: To Cancel The Chime Zones
IDS400 USER MANUAL mode. Press the [#] key to exit the chime programming mode. 13.2 To Cancel the Chime Zones Summary: [ 2] + [-] + [ZONE NUMBER] + [#] Hold down the [2] key until the audible indicator sounds. The AWAY indicator will flash to show that the panel is on the chime programming mode. -
Page 22: Trouble-Shooting
IDS400 USER MANUAL 14. Trouble-Shooting 14.1 Trouble Conditions In the event of a trouble condition the power indicator will flash. Trouble Condition refers to Low Battery power and/or AC Mains Failure. Check that the plug is in place and switched on. If the power indicator is still flashing once these checks have been done, contact your installer who will then check the battery power. -
Page 23: For Service
IDS400 USER MANUAL Will the panel not disarm? You may have entered an incorrect code. Press the [#] key first, then re-enter your user code. 14.4 For Service Central Station Information: Installer Information: IDS400 USER MANUAL NO. 700-204-01A ISSUED NOV 2000 VER 1.01... - Page 24 IDS400 USER MANUAL Index Alarm Memory ................7, 18 ........... 7, 9, 10, 12, 13, 15, 18, 19 Away ..............9, 12, 13 Quick ................. 10, 13 Stay ............7, 10, 12, 13, 19 Stay & Go ..............10, 13 Audible Indicator ........
- Page 25 IDS400 USER MANUAL Medical .................. 10, 16 Panic ................10, 14, 16 Power ................8, 9, 21 Power Save Mode ................10 Problems ..................21 Ready ............9, 12, 13, 18, 19, 20, 21 Remote Control (See “Keyswitch) Siren ..............10, 13, 15, 16 Strobe ..................
- Page 28 Warranty Inhep Electronics (Pty) Ltd guarantees all IDS Control Panels against defective parts and workmanship for 12 months from date of purchase. Inhep Electronics shall, at its option, repair or replace the defective equipment upon the return of such equipment to any Inhep Electronics branch.
