for the parking lights load. In the "Head"
position of the lighting switch, the output is
further increased by all three pairs of coils
being connected in parallel.
2. Maintenance
(a) Check wiring occasionally to see that
all connections are clean and tight.
(b) Check tightness of rectifier securing
nut.
© LIGHTING SWITCH AT "HEAD"
INTERNAL CONNECTIONS OF ALTERNATOR
CIRCUIT DIAGRAMS FOR POSITIONS OF
LIGHTING SWITCH
Section G2h Page 2
Fig. 3
WIRING DIAGRAM
Fig. 4
