- Page 1 Blaster Soft System Owner’s Manual CANADIAN ADDRESS 92 Commerce Park Dr. Unit #2 Barrie, ON L4N 8W8 Canada www.waterdepot.com...
- Page 2 IMPORTANT: Do not make any adjustments to these units, they are factory set. Should you encounter problems with the performance of the Blaster, then you should call for service. Your dealer is trained in testing water and setting your machines according to the recommendation of the manufacturer.
-
Page 3: Table Of Contents
Bypass Valve Operation ....................6 Consumer Valve Programming Setup ................7 Factory settings ....................... 8 User Display ........................9 Blaster Soft Set Up ......................10 Installation Flow Diagram ....................11 Wiring Diagram ......................12 CD Cell Cleaning ......................15 Wiring ..........................16 Platinum Drawings and Part Numbers ................ -
Page 4: Instructions
Instructions The control valve, fittings and/or bypass are designed to accommodate minor plumbing misalignments but are not designed to support the weight of a system or the plumbing. Do not use Vaseline, oils, other hydrocarbon lubricants or spray silicone anywhere. A silicon lubricant may be used on black o-rings but is not necessary. -
Page 5: Installation Fitting Assemblies
Installation Fitting Assemblies The installation fittings connect to the control valve or the bypass valve using nuts that ONLY REQUIRE HAND TIGHTENING. Hand tighten nut connections between control valve and installation fittings, control valve and bypass valve, and bypass valve and installation fittings allow for easy serviceability. Do not use a pipe wrench to tighten nuts on installation fittings. -
Page 7: Consumer Valve Programming Setup
Consumer Valve Programming Set Up GENERAL OPERATION When the system is operating on of Two displays will be shown: time of day or days until the next regeneration. Pressing UP or DOWN will toggle Between the two choices. TO SET TIME OF DAY 1. - Page 8 Factory Setup of Blastersoft Blastersoft setup of valve: 1) Fill cycle 9.5 lbs. of salt 2) Softening 120 minutes 3) Backwash cycle 10 Minutes 4) Brine cycle 60 minutes 5) Rinse cycle 4 minutes 6) Ozone draw cycle 30 minutes Setting the relay: On time First relay at:...
-
Page 9: User Display
User Displays General Operation When the system is operating one of two displays will be shown. Pressing UP or DOWN button will alternate between the displays. One of the displays is always the current time of day (to the nearest hour). The second display is the days remaining until next regeneration. -
Page 10: Blaster Soft Set Up
BLASTER SOFT SET UP NOTE: The Blaster Soft come factory set, only to be changed by trained/qualified technicians. Changes may be necessary should the water quality change. First Stage of Settings Instructions Description Set time clock As per normal operation... - Page 13 Example: Brine Line Installation...
- Page 14 CD Cell Inlet Port CD Cell Outlet Port CD Cell H.V. Wire Connection To Clean the CD Cell: 1.) Remove the CD Cell outlet tubing at the locations shown above. 2.) Disconnect the CD Cell H.V. wire from the frequency driver. 3.) Disconnect the CD Cell from its grounding clips and remove from generator.
-
Page 16: Platinum Drawings And Part Numbers
Platinum Drawings and Part Numbers... -
Page 17: Front Cover And Drive Assembly
Front Cover and Drive Assembly Drawing No. Order No. Description Quantity CLK V334201 WD1HS Front Cover Assembly CLK V310701 WD1 Motor CLK V310601 WD1 Drive Bracket & Spring Clip CLK V3353HS WD1HS PC Board No Relay CLK V3353HR WD1HR PC Board w/Relay CLK V3110 WD1 Drive Gear 12x36 CLK V3109... -
Page 18: Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston And Spacer Stack Assembly
Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston and Spacer Stack Assembly Drawing No. Order No. Description Quantity CLK V3005 WD1 Spacer Stack Assembly CLK V3004 Drive Cap ASY CLK V3343 WD1HS Drive Back Plate CLK V3011* WD1 Piston Downflow ASY CLK V301101* WD1 Piston Upflow ASY CLK V3174... -
Page 19: Drive Cap Assembly, Downflow Piston, Regerant Piston And Spacer Stack Assembly
Drive Cap Assembly, Downflow Piston, Regenerant Piston and Spacer Stack Assembly Drawing No. Order No. Description Quantity CLK V3430 WD1.5 Spacer Stack Assembly CLK V3004 Drive Cap ASY CLK V3343 WD1HS Drive Back Plate CLK V3407 WD1.5 Piston Downflow ASY CLK V3174 WD1 Regenerant Piston CLK V3135... -
Page 20: Injector Cap, Injector Screen, Injector, Plug And O-Ring
Injector Cap, Injector Screen, Injector, Plug and O-Ring Drawing Order No. Description Quantity CLK V3176 Injector Cap CLK V3152 O-ring 135 CLK V3177 Injector Screen CLK V30101Z WD1 Injector ASY Z Plug CLK V30101A WD1 INJECTOR ASY A BLACK CLK V30101B WD1 INJECTOR ASY B BROWN CLK V30101C WD1 INJECTOR ASY C VIOLET... -
Page 21: Refill Flow Control Assembly And Refill Port Plug
Refill Flow Control Assembly and Refill Port Plug Drawing Order No. Description Quantity CLK V319501 WD1 Refill Port Plug ASY This part is required for backwash only systems CLK H4615 Elbow Locking Clip CLK JCPP6 Polytube insert 3/8" CLK JCPG6PBLK Nut 3/8"... -
Page 22: Drain Line - ¾
Drain Line – 3/4” Drawing No. Order No. Description Quantity CLK H4615 Elbow Locking Clip CLK PKP10TS8BU Polytube insert 5/8 Option CLK V3192 WD1 Nut ¾ Drain Elbow Option CLK V315801 WD1 Drain Elbow ¾ Male ASY CLK V3163 O-ring 019 CLK V315901 WD1 DLFC Retainer ASY CLK V3162007... -
Page 23: Water Meter, Meter Plug And Mixing Valve
Water Meter, Meter Plug and Mixing Valve Drawing No. Order No. Description Quantity CLK V3151 WD1 Nut 1" QC CLK V3003* WD1 Meter ASY CLK V311801 WD1 Turbine ASY CLK V3105 O-ring 215 CLK V300301 WD1 Meter Plug ASY CLK V3013 Mixing Valve Optional *Order number V3003 includes CLK V311801 WS1 Turbine ASY and V3105 O-ring 215. -
Page 24: Installation Fitting Assemblies
Installation Fitting Assemblies Order No: CLK V3007 Order No: CLK V300701 Description: WD1 Fitting 1" PVC Male NPT Elbow Assembly Description: WD1 Fitting ¾" & 1" PVC Solvent 90º ASY Drawing Order No. Description Quantity Drawing No. Order No. Description Quantity CLK V3151 WD1 Nut 1"... - Page 25 Installation Fitting Assemblies Order No: CLK V300704 Order No: CLK V300705 Description: WD1 Fitting 1" Plastic Male NPT Assembly Description: WD1 Fitting 1-1/4" Plastic Male Assembly Drawing No. Order No. Description Quantity Drawing No. Order No. Description Quantity CLK V3151 WD1 Nut 1"...
-
Page 26: Bypass Valve
Bypass Valve Drawing No. Order No. Description Quantity CLK V3151 WD1 Nut 1" Quick Connect CLK V3150 WD1 Split Ring CLK V3105 O-Ring 215 CLK V3145 WD1 Bypass 1" Rotor CLK V3146 WD1 Bypass Cap CLK V3147 WD1 Bypass Handle CLK V3148 WD1 Bypass Rotor Seal Retainer CLK V3152... -
Page 27: Ws1 Wrench
WS1 Wrench (Order No. CLK V319301) Although no tools are necessary to assemble or disassemble the valve, the WS1 wrench (shown in various positions on the valve) may be purchased to aid in assembly or disassembly. Econo Air Birm Installation Fitting Assemblies... -
Page 28: Trouble Shooting
Trouble Shooting Problem Follow up Action Sulphur coming through Check the amount of sulphur you Set to everyday regeneration, 60 min are trying to remove…it may be draw too much to remove or low PH Iron coming through Same as above, ph of 6.8 or lower Same as above may require a ph filter Unit regenerating in...
