TUYA E202 User Manual

e
E202
(Tuya WiFi)
Smart Lock User Manual
Please read this manual carefully before use
Information & Safety Warnings
Note: Please prepare a Phillips screw driver and 4 AA batteries before

installation.

1. Keep your fingers clean before using this product.
2. In original settings, ii can be unlocked with any fingerprint, any card,
or password" 1234567890' ended with'#'.
3. Unlock: Press registered fingerprint on front handle sensor, or make
card close to lock pad, or enter password ended with"#".
4. If the power is insufficient, there will be an alarm prompt, and the lock
can be only unlocked around 50 times, please replace with 4 new
batteries in time. When batteries power running out, connecting a
power bank with Micro USB line though Emergency Power Port can
unlock, but the APP network function will be failure.
5. Please don·t use corrodent material to clean the surface.
6. When the password/fingerprint/card/APP can not unlock the door,
please use the key to unlock the door. Plee1111 keep the emergency key
with you or put it in outdoor safe place .
7. Waking up lock needs around 3 seconds or more, when long time no using.
B. The lock is suitable for 1.57 -3.94INCH thick doors.
°
9. Work temperature range: -22'F ~ 131 F.

Features

1. The total capacity of system is 100, and the first three are administrator.
2. Touching button, durable.
3. Support 6-8 password and 20 virtual password.
4. Support low power warning.
5. Support volume adjustment and door bell.
Name
Parameter
Fingerprint Sensor semiconductor.
DPI 500
Identify lime O.C3S
Unlock Way Fingerprint, Card, Password, Key and APP
System Capacity
100
Supply Voltage 6V
LoW Voltage Warning
4.BV
<= 50 uA
Standby Current
Installation
1. Installation Instructions
a. It is racommended lo look for professionals to install, watch the video
carefully before installing.
b. Please note that the connection line can't be pressed or folded during
.I n stallation.
c. Before the installation, the lock must be selected correctly according
lo the door opening direction, because the handle can't be adjusted.
d. Whlle installing, the door must be in half open state until
commissioning is completed.
e. After the l/i.&tallat1011 is completed, when the fingerprint, card,
password(1234567890) and#, APP, key unlock, test whether the front
handle and back handle unlock/lock normally or not.
f. If it does not work properly, please check if there is improper installation
or the power cord is loose.

2. Installation Overview

� �
l
151617
3. Confirm The Direction
This smart lock is suitable for Left Out/Left In/Right Out/Right In) 4 kinds of door
opening directions,
l � r
LeftHandDoor
� Left In
Outdoor
Indoor
Len out
Ou oor
4.0pen Hole
Please refer to the opening hole drawing, and drill right holes on the door.

5. Install Lock Body

5.1. Choose the lnstelletlon direction of the latch-bolt of the lock body by
the door opening directions.
� Left In/
�
5.2. Change the direction of lock body
a. Push the reversing block to the other
side.
b. Push the latch-bolt into the lock and
turn 180 degrees.
c. Put back the reversing block, and the
latch-bolt will pop up automatically.
the
5.3. Put the lock body into the door frame and tighten 2 fixing screws.
1. Front Panel
2.Connectlon Column
3.Square St■-1
4.LockBody
5.Connectlon Line
fl,811ckP11nel
1: SET' 9ulton
8.Connection Column Screws
9.Battery Cover
1 O.Battery Cover screw
11.Beck Handle
12.Connecllon Column Screws
13.Reverse Lock Knob
14.Back Locking Peddle
15.Dead-bolt
16.Latch-bolt
17 .Lock Body Screws
18.Connecllon Column
19.KeyHole
20.Emergancy Power Port
18192021
21.Front Handle
of
The Door
� door
Right Hand Door
c::::Y==
Righi In
Outdoor
Indoor
RightOut
�
Outdoor
�LeftOut/
Right Out
� Right ln
,-· Latch-bolt
@>-" ··Square Steel
0
Hole
""Dead-bolt
+
Lock Body(5052)
