Summary of Contents for Wickes PDH170DS
- Page 1 BREAKER 1700W PDH170DS 223725...
-
Page 2: Table Of Contents
CONTENTS GENERAL POWER TOOL SAFETY WARNINGS COMPONENT LIST ACCESSORIES SYMBOLS TECHNICAL DATA NOISE INFORMATION OPERATING INSTRUCTIONS WORKING HINTS FOR YOUR TOOL TROUBLESHOOTING MAINTENANCE ENVIRONMENTAL PROTECTION PLUG REPLACEMENT (ONLY FOR REWIRABLE PLUG OF UK & IRELAND) DECLARATION OF CONFORMITY... -
Page 3: General Power Tool Safety Warnings
ORIGINAL INSTRUCTION GENERAL POWER TOOL SAFETY WARNINGS WARNING! This machine is capable of generating f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) significant forces, strict adherence to safety protected supply. Use of an RCD reduces the risk of guidance in this booklet is essential as is the use of electric shock. - Page 4 GENERAL POWER TOOL SAFETY WARNINGS caused by poorly maintained power tools. or remove the battery pack, if detachable, from f) Keep cutting tools sharp and clean. Properly the power tool before making any adjustments, changing accessories, or storing power tools. Such maintained cutting tools with sharp cutting edges are less preventive safety measures reduce the risk of starting the likely to bind and are easier to control.
-
Page 5: Component List
COMPONENT LIST Lock-on button Auxiliary handle On/off switch Point chisel and flat chisel Grease box cover Spanner... -
Page 6: Accessories
ACCESSORIES Auxiliary handle Flat Chisel Point Chisel Wrench We recommend that you purchase your accessories from the same store that sold you the tool. Use good quality accessories marked with a well-known brand name. Choose the type according to the work you intend to undertake. Refer to the accessory packaging for further details. -
Page 7: Noise Information
NOISE INFORMATION A weighted sound pressure : 92.87dB(A) A weighted sound power : 103.87dB(A) & K 3.0dB(A) Wear ear protection. VIBRATION INFORMATION Vibration total values (triax vector sum) determined according to EN 60745: Vibration emission value a 18.575 m/s² chiseling Uncertainty K = 1.52 m/s²... -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use This machine is suitable for gouging on concrete, bricks, stone and asphalt. After appropriate accessories are installed, it can also be used for squeezing and tamping. For low temperatures, new power tool or long-time storage, the machine reaches the full impact rate only after a certain time. - Page 9 2. FITTING THE AUXILIARY HANDLE (See Fig. B1,B2) For your personal safety we recommend using the auxiliary handle (4) at all times. To adjust the handle (4), loosen the knob on the auxiliary handle. Rotate the handle (4) around the handle collar and/or rotate the handle bar to the desired position.
- Page 10 4. OPERATING THE ON/OFF SWITCH (See Fig. D) ON/OFF SWITCH Depress the on/off switch (2) to start the tool and release it to stop your tool. CONTINUOUS USE Depress on/off switch (2) then lock-on button (1), release on/off switch (2) first and lock-on button (1) second. Your switch is now locked on for continuous use.
-
Page 11: Working Hints For Your Tool
WORKING HINTS FOR YOUR TOOL Always use sharp good quality chisels. The performance of the chisel is dependent on the quality of the bits used. 1. Reduce pressure on the bit when it is about to break through. 2. Always operate tool using both the handle and the front handle. 3. -
Page 12: Plug Replacement (Only For Rewirable Plug Of Uk & Ireland)
PLUG REPLACEMENT (ONLY FOR REWIRABLE PLUG OF UK & IRELAND) If you need to replace the fitted plug then follow the instructions below. IMPORTANT The wires in the mains lead are colored in accordance with the following code: Blue = Neutral Brown = Live As the colors of the wires in the mains lead of this appliance may not correspond with the colored markings identifying the terminals in your plug, proceed as follows. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Wickes Building Supplies Limited Declare that this product: BREAKER Description and SKU code: 223725 Complies with the following Directives and Regulations: 2006/42/EC, Machinery Directive 2014/30/EU, Electromagnetic Compatibility Directive 2011/65/EU & (EU)2015/863 (RoHS),Restriction of Hazardous Substances Directive 2000/14/EC amended by 2005/88/EC:... - Page 16 Customer Helpline 0345 2005409...
