OPERATION INSTALLATION MAINTENANCE
MANUAL
FOR HALE SAM
BY
HALE PRODUCTS, INC.
A Unit of IDEX Corporation
607 NW 27th Ave, Ocala, FL 34475
(800) 533.3569
(800) 520.3473 (FAX)
www.haleproducts.com
MANUAL P/N FSG–MNL–00210 Revision A
COPYRIGHT © 2019 – 2020 BY HALE PRODUCTS, INC. ALL RIGHTS RESERVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HALE SAM and is the answer not in the manual?

Questions and answers

Related Manuals for Idex HALE SAM

Summary of Contents for Idex HALE SAM

  • Page 1 OPERATION INSTALLATION MAINTENANCE MANUAL FOR HALE SAM HALE PRODUCTS, INC. A Unit of IDEX Corporation 607 NW 27th Ave, Ocala, FL 34475 (800) 533.3569 (800) 520.3473 (FAX) www.haleproducts.com MANUAL P/N FSG–MNL–00210 Revision A COPYRIGHT © 2019 – 2020 BY HALE PRODUCTS, INC. ALL RIGHTS RESERVED...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section Title Page 1. SAFETY ............................. 1 Safety Headings ........................1 Safety Summary ........................1 2. GENERAL INSTRUCTIONS ....................... 7 SAM Numbering and Specifications References ..............8 3. TRANSPORTATION AND STORAGE ....................9 EAR99 Restrictions........................9 Shipping, Movement, And Installation Preparations .............. 9 Pump Gearbox Shipped Without Fluid ..................
  • Page 4 TABLE OF CONTENTS–CONTINUED Section Title Page 4.2.1.6 SAM Information Center Area/Section ..............27 4.2.1.7 User Assignable Quicksets Area/Section ..............27 4.2.2 SAM Control Center Customizable/Configurable Items ..........27 4.2.2.1 Discharge Valve Preset Pressure ................28 4.2.2.2 Discharge Valve Quickset Pressure................. 28 Pump Controller ........................
  • Page 5 TABLE OF CONTENTS–CONTINUED Section Title Page 5. INSTALLATION ..........................43 Drive Line Requirements ...................... 44 Power Requirements ......................45 Compressed Air Requirements ..................... 47 CAN Bus Requirements ......................47 Valve Mechanical Override Access Requirements .............. 48 OEM Connections To SAM ....................48 SAM Software And Configuration Passwords ..............
  • Page 6 TABLE OF CONTENTS–CONTINUED Section Title Page 6.3.1.2.1 Bypass Venting ....................70 6.3.1.2.2 Bypass Opening ....................71 6.3.1.3 Using Discharge Quicksets, Presets, And The SET PRESSURE Icon Group ..71 6.3.1.3.1 Activating A Quickset ..................71 6.3.1.3.2 Using The ADD LINE Button/Target ..............71 6.3.1.3.3 Changing A Discharges Pressure/Closing The Valve ........
  • Page 7 TABLE OF CONTENTS–CONTINUED Section Title Page 6.3.3.3.3 Close A Foam Discharge (With SAM) ..............90 6.3.3.3.4 Turn Off SmartFOAM (With SAM) ..............92 6.3.3.4 Using SmartCAFS With SAM ..................93 6.3.3.4.1 Activating A SmartCAFS Quickset ..............93 6.3.3.4.2 Activating A SmartCAFS Preset ................. 94 6.3.3.4.3 Changing A CAFS Discharge To FOAM ONLY ............
  • Page 8 TABLE OF CONTENTS–CONTINUED Section Title Page 7.1.2 Annually ......................... 120 7.1.2.1 NFPA 1901/1911 Testing Tips And Hints For The SAM System ......120 7.1.2.2 Akron Brass Swing-Out™ Valve Motor Operating Current Check ......121 8. ADJUSTMENTS ........................... 123 ITL–40 Calibration Using SAM Pump Controller ..............123 APPENDIX A.
  • Page 9 LIST OF FIGURES Number Title Page Figure 1. Hale ID Tag With Sample Markings ................8 Figure 2. SAM Network Diagram (CAN Buses) ................. 13 Figure 3. Set Pressure Icon Group .................... 15 Figure 4. Discharge Setup Confirmation Screen ..............16 Figure 5.
  • Page 10 LIST OF FIGURES–CONTINUED Number Title Page Figure 39. Pump Controller RPM Mode (SAM Manual Mode Only) ........... 33 Figure 40. Hale Twister ........................ 34 Figure 41. Pump Controller Tank Info Screens ................34 Figure 42. Pump Controller Pump Info Screen–No Action Required ........35 Figure 43.
  • Page 11 LIST OF FIGURES–CONTINUED Number Title Page Figure 77. Active Force Intake X Open Popup ................70 Figure 78. Activating Quickset Discharges (Touch–Drag–Drop) ..........71 Figure 79. Activating Additional Discharges ................72 Figure 80. Change A Discharge Pressure ................... 73 Figure 81. Closing A Discharge (Using Stop Button) ..............
  • Page 12 LIST OF FIGURES–CONTINUED Number Title Page Figure 115. Closing A CAFS Discharge Sequence ................ 97 Figure 116. SmartCAFS Display ..................... 97 Figure 117. Foam Off Popup Confirmation ................... 98 Figure 118. SAM Control Center USB Dongle ................99 Figure 119. Pump Controller USB Dongle ..................
  • Page 13 Abbreviations And Acronyms The abbreviations used in this manual are limited to standard (commonly used and accepted) scientific units of measure and therefore are NOT defined or listed. The acronyms used in this manual are defined in this listing (in numerical-alphabetical order) and are NOT defined within the text.
  • Page 14 Abbreviations And Acronyms – CONTINUED Negative No Connection National Fire Protection Act NFPA Original Equipment Manufacturer Operation Installation Maintenance Positive Part Number Power Take Off Society of Automotive Engineers Standard Operating Guidelines Suspect Parameter Number Temperature TEMP Unit ID Universal Serial Bus Local Area Wireless Technology WI-FI...

  • Page 15: Safety

    1.2 Safety Summary The following warnings and cautions are used throughout the Hale SAM manuals (and/or the items they reference) and are provided here as a safety summary. ALL ELECTRICAL SYSTEMS HAVE THE POTENTIAL TO CAUSE SPARKS DURING SERVICE.
  • Page 16 ELECTRICAL POWER TO THE VALVE MOTOR SHOULD BE DISCONNECTED BEFORE OP- ERATING THE VALVE PHYSICALLY USING THE MANUAL OVERRIDE HANDWHEEL. ELECTRICAL POWER TO THE VALVE MOTOR SHOULD BE DISCONNECTED BEFORE PHYSICALLY OVERRIDING ANY VALVE. OPERATORS SHOULD FIRST BE TRAINED TO OPERATE THE FIRE PUMP MANUALLY (US- ING PUSH BUTTONS, CONTROL RODS, AND MANUAL [NOT ELECTRICAL] VALVE OVER- RIDES.) •...
  • Page 17 ALWAYS STOP THE ENGINE, SET THE PARKING BRAKE, AND CHOCK THE WHEELS BE- FORE GOING UNDER THE TRUCK FOR ANY REASON. AVOID CONTACT WITH HOT SURFACES. THE PACKING GLAND AND PUMP BODY MAY PRESENT A TEMPERATURE HAZARD. OVERHEATING MAY RESULT IN A SCALDING WA- TER HAZARD.
  • Page 18 BOTH SYSTEMS. ALWAYS DISCONNECT THE POWER CABLE, GROUND STRAPS, ELECTRICAL WIRES AND CABLES FROM THE CONTROL UNIT OR OTHER HALE SAM EQUIPMENT BEFORE ELEC- TRIC ARC WELDING AT ANY POINT ON THE APPARATUS. ALWAYS TURN OFF CAFS FROM THE SMARTCAFS CONTROL DISPLAY.
  • Page 19 KEEP ALL I/O PORT COVERS IN PLACE DURING USE TO PREVENT WATER DAMAGE. OTHER ELECTRICAL COMPONENTS MUST NOT BE SUPPLIED FROM THE SAM SYSTEM SUPPLY. DO NOT CONNECT THE PRIMER AND HALE SAM TO THE SAME POWER WIRE. ONLY TOUCH THE SCREEN IN ONE PLACE AT A TIME. THE TOUCHSCREENS DO NOT...
  • Page 20 PERFORMING THIS PROCEDURE CAUSES SAM TO EXIT AUTO MODE. PUMP SEAL/PUMP SHAFT DAMAGE MAY OCCUR IF DRIP RATE IS LESS THAN ONCE EVERY 6 SECONDS. THIS CONDITION DEGRADES PUMP PERFORMANCE. SOME WATER ONLY OPERATIONS MAY DAMAGE THE CAFS SYSTEM IF THE CLUTCH IS ENGAGED.

  • Page 21: General Instructions

    2. GENERAL INSTRUCTIONS This manual covers the SAM system when local procedures do NOT exist. Basics of SAM and SAM operation, installation verification, preventive maintenance, and operator-based trouble- shooting are covered herein. Refer to the Technical Manual (FSG-MNL-00211) or the Parts Man- ual (FSG-MNL-00212) for additional information.

  • Page 22: Sam Numbering And Specifications References

    2.1 SAM Numbering and Specifications References SAM system only comes as part of a Hale pump kit or a Hale module and is therefore identified by the associated pump ID plate. Figure 1 shows the typical ID plate used on the Hale SAM. Figure 1.

  • Page 23: Transportation And Storage

    3.4 Storage Hale SAM systems should be stored indoors in a protected environment. Packaging is suitable to protect the system for typical storage times associated with vehicle production runs. If the pump needs to be stored for more than six months, see Hale Service Bulletin SB150 on the Hale website (www.haleproducts.com).
  • Page 24 THIS PAGE INTENTIONALLY BLANK.

  • Page 25: System Overview

    4. SYSTEM OVERVIEW SAM is designed to automate the pump operation by simplifying the man machine interface and speeding up the pumping process. SAMs purpose is to get water available to the fire ground faster and to allow the pump operator the freedom to control the pump from multiple locations and provides the advantage of a better (more direct) view of the fire scene and other company personnel.
  • Page 26 Finally, SAM is customizable (configurable) for your department operations regarding the follow- ing: • Valve names and colors • Up to four Quicksets (discharge valve at a preset pressure) may be selected for display on and controlled (with automation) from the SAM Auto Mode screen (which allows one touch control from that screen).

  • Page 27: Figure 2. Sam Network Diagram (Can Buses)

    Figure 2. SAM Network Diagram (CAN Buses) 13 (14 BLANK)

  • Page 29: Sam Touchscreens Navigation And Icon Definitions

    4.1 SAM Touchscreens Navigation And Icon Definitions The SAM system utilizes two (2) touchscreens: The SAM Control Center and the Pump Controller touchscreen (hereafter called the Pump Controller). Navigation for both screens is similar as they both share the same user interface and are touch navigated. NOT ALL GLOVES ALLOW THE SAM TOUCHSCREENS TO FUNCTION.

  • Page 30: Table 2. Sam Water Supply Icons

    Table 2. SAM Water Supply Icons Icon Definition Icon Definition Tank Water Open Tank Water Closed (Button) Draft/Hydrant Active Intake (Touch and Drag (TANK, PSI, inHG) to Toggle) (PSI Shown) Intake Button Intake Button (Pressure Mode) (Draft Mode) Deactivate Intake Target Activate Intake Target Opening Indicator Closing Indicator...

  • Page 31: Icon Groups

    Table 3. Touchscreen Icon Definitions–CONTINUED Icon Definition Icon Definition OK to Pump Pump OK Pump Details Button Pump History Button MODE RPM Button MODE PSI Button Increase Arrowhead Decrease Arrowhead Password Entry Button Opens Governor Menu Save Button Back Button Accept New Value Delete New Value Configuration Mode Button...

  • Page 32: Password Icon Group

    If the icon group is being used to change/set a pressure the icon group center provides a digital readout, the surrounding gauge portion contains a needle that moves along the dial face provid- ing an analog readout while touching the + or–button within the icon group raises or lowers (re- spectively) the pressure setting.

  • Page 33: Figure 6. Rpm Mode Governor Icon Group

    Drag a PRESET RPM button to the ENGINE SPEED target to change the speed of the apparatus engine directly to the desired (preset) engine speed. Figure 6. RPM Mode Governor Icon Group Figure 7 shows the governors PSI Mode icon group. The PSI Mode icon group is also only dis- played when SAM is in Manual Mode and provides three (3) buttons and one (1) target, used to control the apparatus engine speed to maintain the set discharge pressure or to change the gov- ernors mode.

  • Page 34: Valve Close/Open Icon Groups

    Figure 8 shows the governors mode screens when in the low intake pressure governing mode, the left-hand graphic shows the screen in SAM Auto Mode while the right-hand graphic shows the screen in SAM Manual Mode. Low intake pressure governing is a special mode used to protect the water supply when the intake side of the pumps pressure falls to a user selectable level.

  • Page 35: Engine Data Icon Group

    The tank-to-pump icon group provides manual control of the tank-to-pump valve, which controls the flow of water from the onboard water tank to the pump. With SAM in Auto Mode, this valve is controlled by the SAM system to prime the pump and provide an initial water supply for pumping operations.

  • Page 36: Buttons/Targets (Drag And Drop Navigation)

    4.1.2 Buttons/Targets (Drag And Drop Navigation) The SAM user interface utilizes drag and drop technics and items in the form of buttons and tar- gets. (See Figure 14.) Buttons typically appear around the perimeter of (or adjacent to) the target and some buttons incorporate chevrons to enhance the intuitiveness of how to drag the button to the target.

  • Page 37: Sam Touchscreens

    Additional navigation is available during the transitions. If immediate opening of a master intake valve is required, touch the PRIMING or VENTING button (popup text). Then acknowledge the Force INTAKE X Open? confirmation popup that appears by touching the YES button. (NOTE: Us- ing this feature will override the priming function and could allow air from the supply hose into the pump.) See Figure 16.

  • Page 38: Sam Control Center Screens

    4.2.1 SAM Control Center Screens When power is first applied to the system the SAM splash screen (Figure 17) is displayed until the system boots into the user interface. If SAM completes the boot sequence and all of the Auto Mode conditions have NOT been met the SAM Control Center displays the landing screen (Figure 18) until all of the Auto Mode conditions are met and then transitions to the Auto Mode Home screen (Figure 19).

  • Page 39: System Options Button

    Figure 20 shows the seven (7) areas/sections the SAM Control Center touchscreen is divided into: System options, intake control, discharge control, onboard levels, mode control, information center, and user assignable quicksets. Figure 20. SAM Control Center Touchscreen Areas/Sections 4.2.1.1 System Options Button Touch and hold the system options button until the loading icon completes the circle (Figure 21) and the password screen is displayed (see Figure 22).

  • Page 40: Sam Control Center Menu Tabs

    Figure 22. SAM Control Center Password Screen 4.2.1.1.1 SAM Control Center Menu Tabs The password entered determines which menu tabs are displayed. Entering a user/dealer pass- word displays the tabs shown on Figure 23. Figure 23. SAM User/Dealer Menu Tabs Additionally, there are OEM/technician passwords which require a USB key to access.

  • Page 41: Security Tab

    To delete (reset) the Quicksets displayed on the SAM Auto Mode Home screen or to change the order of the Quicksets that are displayed on the SAM Auto Mode Home screen see paragraph 6.2.2.2, How To Change The Order Of (Or Delete) Quicksets On The Home Screen (page 58). 4.2.1.1.1.2 Security Tab Touch the Security tab (see Figure 23, page 24) to display the Change Password screen.

  • Page 42: Discharge Control Area/Section

    4.2.1.3 Discharge Control Area/Section The discharge control (see Figure 20, page 23), of the Auto Mode main screen allows the pump operator to select a Quickset, select any discharge, add line (another discharge), and/or change the pressure a discharge is set to or stop the line (discharge). To activate a Quickset simply touch the desired Quickset (see paragraph 6.3.1.3, page 71) and drag it to the discharge target icon (PUSH TO PUMP or ADD LINE).

  • Page 43: Mode Control Area/Section

    activated/selected. However, the onboard tank can only supply a finite amount of water so the pump operator must transition to a pressured (or draft) supply as soon as possible. The display is the result of the ITL–40 message traffic via the Green CAN bus. When a communi- cation (or other) error exists the onboard tank level display turns Red.

  • Page 44: Discharge Valve Preset Pressure

    Fire Company) so the passwords for these customizable/configurable items do NOT require a USB key for activation. The following customizable/configurable items are end user accessible: • Discharge valve preset pressure • Discharge valve Quickset pressure 4.2.2.1 Discharge Valve Preset Pressure Individual presets can be set for every discharge.

  • Page 45: Pressure Governor

    Figure 30. Pump Controller Boot Screen Figure 31. Pump Controller During SAM Auto Mode The SAM IS ACTIVE screen (Figure 31) is displayed while SAM is in Auto Mode and the screen provides read only status for apparatus interlocks, master intake and discharge pressures, en- gine RPM, tank fill and tank-to-pump position information, auxiliary circulation status, and pump capacity (only available in hydrant and on select pumps that pump above 600 GPM).

  • Page 46: Psi Mode

    The pressure governor does NOT accept control/user interface input from the touchscreen (or the knob portion of the Twister) while SAM is in Auto Mode. The default governor screen depends on what the SAM settings were when Auto Mode was exited (Manual Mode was enabled). See paragraph 4.3.1.1.1, PSI Mode (page 30) or 4.3.1.2, RPM Mode for the default screen/mode SAM enters upon exiting Auto Mode.

  • Page 47: Figure 33. Intake Psi Components

    The PSI Mode governor screen is divided into nine separate areas: System Options and Tab but- tons, Intake (master) PSI, Statuses and Alerts, Discharge (master) PSI, Mode button, PSI Set Point icon group, Preset buttons, Pump Capacity, and the Tank Info area. See Figure 32. The system options button provides access to the data logger controls, Revision Status infor- mation, and the Password Entry button.

  • Page 48: Low Intake Pressure Control Mode

    The mode buttons are described in paragraph 6.3.4.2.1, Using PSI Mode, page 101 and 6.3.4.2.2, Using RPM Mode, page 102. The PSI set point icon group (Figure 35) consists of an increase (+) button, a decrease (–) button, with a digital readout of the engines RPM in the center. The engines RPM digital readout also serves as an alternative target area (drop zone) for the preset PSI buttons.

  • Page 49: Rpm Mode

    Figure 37. Low Intake Pressure Control Mode Screen In low intake pressure control mode the governor switches from controlling the engine to main- tain the set master discharge pressure to maintaining a minimum master intake pressure. A WARNING is periodically displayed until the condition is corrected (see Figure 38). Each time the WARNING is displayed the operator can acknowledge the popup WARNING by touching the CON- FIRM button.

  • Page 50: Twister Electronic Throttle (In Sam Manual Mode)

    Additionally, the screen displays the status of the onboard water tank (OK, < 1/3, EMPTY). See FSG-MNL-00211 (Technical Manual For Hale SAM) for instructions to turn the Tank Level on to display a gauge icon group graphically showing the level in the tank.

  • Page 51: Pump Info Screens

    4.3.1.4 Pump Info Screens The Pump Info screen (Figure 42) provides anode status (for up to three [3] anodes) as Good, Replace, Error, or Not Available. The Pump Info screen provides temperature read out for the pump water and the gearbox oil. Figure 42.

  • Page 52: Figure 44. Pump Controller Pump Info Details Screen

    Figure 44 shows the Pump Details screens read only information listed for the pump. Figure 44. Pump Controller Pump Info Details Screen Figure 45 shows the Pump History screens read only information listed for the pump. Refer to FSG-MNL-00211 for the screen when SAM is in Manual Mode (annual testing). Figure 45.

  • Page 53: Engine Data Screen

    Figure 47 shows the Pump Test Data screens listed for the pump as recorded each time a pump test was conducted in the field (required yearly or after a major repair). Refer to FSG-MNL-00211 for the screen when SAM is in Manual Mode (annual testing). Figure 47.

  • Page 54: Pump Controller System Options Menu

    4.3.1.7 Pump Controller System Options Menu Touch the systems options button (touch and hold the button if the loading icon appears) to dis- play the system options Menu screen (Figure 50). The screen displays four (4) separate areas on the screen: The datalogger export control, the Back To Previous Menu button, the Revision Sta- tus information and the Password Entry button.

  • Page 55: Sam Automated Pump Cooling

    The tablet utilized a secured wi-fi connection to ONLY communicate with the paired SAM Control Center and only one tablet can be paired to the associated SAM Control Center (apparatus). This allows multiple apparatuses to operate on the same fire scene without undesired tablet interac- tions and prevents other devices from being connected to the tablet.

  • Page 56: Pump Priming

    If the water temperature reaches (or exceeds) 122° F (50° C) the COOLANT TEMPERATURE HIGH CRITICAL WARNING (see Section 6.3.7, Operator Responses To SAM Alarms, page 106) is activated. When the onboard tank water temperature becomes too high the ONLY alternative is to flow wa- ter to atmosphere (ground) by ensuring an external water source is active and then slightly open- ing a discharge (or discharges).

  • Page 57: Manual Prime

    To stop priming prior to the timeout, simply touch the intake button and drag it off the target (swipe it back to where it was). If the SAM Auto prime does not operate as anticipated, simply use the manual prime (see para- graph 4.6.2, below).

  • Page 58: Sam And Foam Systems

    4.9 SAM And Foam Systems Hale Foam systems on a SAM equipped apparatus is always an option. One of the following foam systems may optionally be added to a SAM equipped apparatus: SmartFOAM or SmartCAFS. The SAM provided gateway to each foam system is described below. 4.9.1 SmartFOAM SAM utilizes the Green CAN bus to interface with the SmartFOAM system.

  • Page 59: Installation

    5. INSTALLATION The following guidelines assist the installer with system installation. Carefully review the proce- dures provided in the SAM TM (FSG-MNL-00211) to ensure proper installation of the system. Hale provides SAM systems in three forms: As a pump kit with loose valves, as a pump kit with installed valves, and as a Hale built module.

  • Page 60: Drive Line Requirements

    Hale Built Module As with a pump kit, the OEM/apparatus builder must install the Hale built SAM module following all guidelines provided in sections 5.1 (Drive Line Requirements, see page 44), 5.2 (Power Re- quirements, see page 45), 5.3 (Compressed Air Requirements, see page 47), and 5.4 (CAN Bus Requirements, see page 47) below.

  • Page 61: Power Requirements

    OTHER ELECTRICAL COMPONENTS MUST NOT BE SUPPLIED FROM THE SAM SYSTEM SUPPLY. DO NOT CONNECT THE PRIMER AND HALE SAM TO THE SAME POWER WIRE. When an optional SmartFOAM system is selected a third +12 VDC power source capable of 40 Amps (for a 1.7 AHP or 2.1 A foam pump), 60 Amps (for a 3.3 or 5.0 foam pump), or 80 Amps...

  • Page 62: Figure 52. Connect System Power Tag

    The entire system operates from +12 VDC. The SAM +12 VDC power maximum current (stated above) verses typical operating current (approximately 10 Amp unless valves are moving against high pressure) is significantly different. This large difference is due primarily to the current re- quired to deadhead a valve drive motor which, occurs when the valves are calibrated (and may occur when the valves are fully opened/closed).

  • Page 63: Compressed Air Requirements

    5.3 Compressed Air Requirements The OEM/apparatus builder shall supply dry compressed air with a minimum of 75 psi, a maxi- mum of 150 psi. (Typically, from the vehicle air brake system which is typically capable of the 90 psi to 150 psi at approximately 13 cfm at 1250 rpm.) The pump kit or module provides a loose coil of hose to connect the OEM/apparatus builder supplied air.

  • Page 64: Valve Mechanical Override Access Requirements

    5.5 Valve Mechanical Override Access Requirements Position/orient all valves to provide access to the mechanical override shaft (Figure 54). The shaft accepts a 7/16-in (11 mm) socket (or wrench). As much as possible position all valves to provide valve override using the socket (with or without an extension) and a driver. Figure 54.
  • Page 65 See Table 5 for a label and a SAM to OEM connection point cross reference listing. Table 5. SAM To OEM Connection Point Cross Reference Listing Label (NOTE 1/) SAM Component/Item OEM Component/Item TRUCK AIR Red Air Hose Apparatus Compressed Air Supply (Coiled near top of pump) (Also see paragraph 5.3, page.

  • Page 66: Sam Software And Configuration Passwords

    Verified OEM/ (Requires USB key) ter pressure sensor span, user password reset, revert to Apparatus Build- IDEX Permanent Valve Configuration, Error Code List (Not ers/Select Tech- clearable), CAN Data Logger (Downloadable to USB), Low nicians intake pressure control trigger value, Language...

  • Page 67: Table 7. Sam Pump Controller User/Dealer Password List

    Table 7. SAM Pump Controller User/Dealer Password List Password Menu Description Reference 43275 Pump Info Tab Reset Gearbox Oil Life Resets sensor module oil life counter to 500 hrs. 6161 Volume Allows user/dealer to set SAM Speaks See paragraph audio volume 6.2.2.1 on page 61 6363...
  • Page 68 THIS PAGE INTENTIONALLY BLANK.

  • Page 69: Commissioning, Startup, Operation, And Shutdown

    6. COMMISSIONING, STARTUP, OPERATION, AND SHUTDOWN OPERATORS SHOULD FIRST BE TRAINED TO OPERATE THE FIRE PUMP MANUALLY (US- ING PUSH BUTTONS, CONTROL RODS, AND PHYSICAL [NOT ELECTRICAL] VALVE OVER- RIDES.) • AUTOMATION ONLY MITIGATES PROBLEMS AROUND THE PUMP AND VALVES •...

  • Page 70: Commissioning

    THE PROCEDURES IN THIS SECTION PROVIDE ONLY GENERAL AND MINIMAL INSTRUC- TION. DO NOT REPLACE LOCAL PROCEDURES OR POLICIES OR RECOMMENDATIONS AND PROCEDURES PROVIDED IN THE APPARATUS/TRUCK/UNIT MANUAL WITH THESE PROCEDURES. THE PROCEDURES IN THIS SECTION ARE GENERAL OPERATING PROCEDURES BASED ONLY ON HALE EQUIPMENT.

  • Page 71: Sam Power On And Default Verifications

    Verify required Governor module is present, plugged into the Blue and the vehicle CAN ❑ networks, and the COM indicator (green LED) is illuminated. Verify required Twister electronic throttle is present and connected to the Green CAN net- ❑ work. Verify no COMM LOSS messages are displayed (or popped up) on the SAM Pump Controller or SAM Control Center SAM INFORMATION CENTER.

  • Page 72: Mode Selection Verifications

    D. Verify Pump Controller display transitions to Pump Controller read only screen (Figure 31). The SAM system is powered on and ready for mode selection. 6.1.2 Mode Selection Verifications The SAM system defaults to Auto Mode at power on with pump engaged as described below. If Manual Mode is desired the operator must switch to it as described in paragraph 6.1.2.2, Switch- ing To SAM Manual Mode.

  • Page 73: Startup

    6.2 Startup NOT ALL GLOVES ALLOW THE SAM TOUCHSCREENS TO FUNCTION. TEST GLOVES ON ALL OF THE SAM TOUCHSCREENS PRIOR TO OPERATING SAM. DO NOT WEAR GLOVES THAT PREVENT THE TOUCHSCREENS FROM OPERATING. SAM TOUCHSCREENS DO NOT FUNCTION IF COMPLETELY COVERED AND/OR IM- MERSED IN WATER.

  • Page 74: Assigning Quicksets To The Home Screen

    6.2.1.1 Assigning Quicksets To The Home Screen To initially select the Quicksets displayed on the SAM Auto Mode Home screen (when none are displayed/selected), simply touch and drag the desired discharge to the desired Quickset posi- tion. Once the four Quicksets have been populated, no other changes/selections can be made on this screen without a reset.

  • Page 75: Change User/Dealer Password

    after the reset, touch and drag the desired discharge (select from the 12 valves displayed at top of page) to the desired Quickset position (HomeScreenQuickset1 thru 4 targets displayed at bot- tom of page). Perform the following to rearrange the order of the discharge valves displayed as Quickset or to change which discharge valve displays as a Quickset on the Auto Mode Home screen.

  • Page 76: How To Assign/Change Low Tank Water Alarm Trigger Level

    E. Touch Enter New Password text box. (Sets focus so the new password can be en- tered.) F. Using the number pad, touch the desired digits of new password. G. Touch ENTER button. H. Wait for PASSWORD SAVED to appear. See Figure 59. Figure 59.

  • Page 77: Set The Volume For Sam Speaks (Spoken Alerts)

    Figure 60. Pump Controller System Options Button And Loading Icon B. When Menu screen is displayed (see Figure 50, page 38), touch Password Entry button. Touching the Password Entry button (see Table 3), allows end users, OEMs, apparatus builders, and Hale FAST centers to enter specific passwords (see Table 7) required to configure/setup the Pump Controller parameters in the following subparagraph.

  • Page 78: Set Camera Names

    Figure 62. Set The Volume For SAM Speaks A. To increase speaker volume, touch increase arrow ( ) once for each increase desired. (Note: Holding the button does NOT continue to increase the volume.) B. To reduce speaker volume, touch decrease arrow ( ) once for each decrease desired.

  • Page 79: Calibration

    Sequentially, touch letters and digits of desired name. Touch Enter key. Figure 64. Set Camera Names Keyboard Screen F. Touch Save button (see Table 3, page 14). G. Acknowledge Saving Complete. popup (Figure 65). Figure 65. Camera Names Saved Acknowledgment H.

  • Page 80: Tank Level Off/On

    6.2.2.5 Tank Level Off/On Enter the Tank Tab (Text Box Tank Level) password (see Table 7, page 51) to view the water level as one of three color/textual based icons on the TANK tab of the Pump Controller (see Figure 41, page 34).

  • Page 81: Sam Operation

    A. On SAM Control Center, on SELECT DEVICE screen, touch icon (Table 3). MENU is displayed (Figure 68). Figure 68. (HOME ICON) MENU Screen B. Touch Reboot to GUI button. (See Figure 68.) 6.3 SAM Operation AVOID CONTACT WITH HOT SURFACES. OVERHEATING MAY RESULT IN A SCALDING WATER HAZARD.

  • Page 82: Auto Mode

    to the attack crew can be tricky. SAM controls the transition and controls the engine speed dur- ing the process to keep water flowing smoothly without disruption. Then tell SAM what discharge lines to open and their set pressure with a few swipes on the screen and SAM takes care of the details.

  • Page 83: Selecting The Desired Pumping Method

    Getting SAM into Auto Mode requires all the applicable bulleted items (listed above the figures) to be met. Additionally, SAM requires truck supplied compressed air (from the brake system) and water in the onboard water tank. SAM performs many functions; however, SAM does NOT adjust for friction losses or altitude. The system simply maintains pressure set points as measured near each individual discharge valve.

  • Page 84: Figure 72. Activating An Intake

    ALWAYS FOLLOW PROPER OPERATING PROCEDURES. THE PUMP OPERATOR MUST BE FAMILIAR WITH THE PUMP AND SAM OPERATING INSTRUCTIONS AS WELL AS OTHER OPERATING GUIDELINES FOR THE APPARATUS AND ACCESSORIES. NOTE Any manual activation initiated by the operator cancels auto flow operations. If supply hose is connected and hydrant is open, transition will begin.

  • Page 85: Figure 74. Activating A Hydrant Intake Sequence (Miv Disc Opening)

    C. Operator observes as SAM opens desired master intake valve using an algorithm that compensates for pressure changes that occur as a result of remaining air and/or turbulence created by opening valves disc. See Figure 74. Figure 74. Activating A Hydrant Intake Sequence (MIV Disc Opening) D.

  • Page 86: Bypass Venting

    E. SAM Control Center continues to display OPENING until master intake valve posi- tion sensor indicates master intake valve is fully open and sequence is complete. See Figure 76. Figure 76. Activating A Hydrant Intake Sequence (Complete) SAM closes tank-to-pump valve and fills the water tank as the water supply permits. All this can be done while flowing water or before the discharge is opened.

  • Page 87: Bypass Opening

    NOTE Touching NO cancels the command and does nothing. 6.3.1.2.2 Bypass Opening If desired (or as a bypass, when HYDRANT DETECTION SENSOR LOST. USE OVERRIDE is dis- played), the opening time may be reduced or bypassed as follows. A. On SAM Control Center, while OPENING is displayed for an intake, touch OPEN- ING button.

  • Page 88: Figure 79. Activating Additional Discharges

    To activate a discharge using the ADD LINE button, perform the following. A. Touch ADD LINE button. (See the right most side of Figure 78.) B. On SELECT DISCHARGE, screen, touch desired discharge button. (See the left-hand side of Figure 79.) Set the desired discharge pressure using either, the preset button (upper right of Figure 79) or the SET PRESSURE icon group (lower right of Figure 79).

  • Page 89: Changing A Discharges Pressure/Closing The Valve

    Touch button until needle indicates desired pressure. (If required, use–but- ton to lower pressure.) When button is released, a popup confirmation is displayed. Touch YES to activate the new line or touch NO to do nothing. 6.3.1.3.3 Changing A Discharges Pressure/Closing The Valve To change the set pressure of an open line, perform the following.

  • Page 90: Low Intake Pressure Control Mode

    B. Drag button to SET PRESSURE target (Figure 81–Center). C. Release button (remove finger from screen). The CLOSE LINE button activates automatically (the same as a preset would). No confirmation is required. If the operator only touches and releases the button; a confirmation popup window appears (Fig- ure 82).

  • Page 91: Figure 83. Initiating A Draft (Transition Shown Top-Left To Bottom-Right)

    Then perform the following. A. On SAM Control Center, touch and drag HYDRANT button to DRAFT. See top-left of Figure 83. NOTES A master intake valve may be opened multiple ways. Use the easiest method (typically determined by proximity, convenience, or local procedure). Perform instructions from paragraph 6.3.2.1, page 83.

  • Page 92: Twister Operations (In Sam Auto Mode)

    SAM monitors discharge pressure. NOTE SAM primes again if the discharge pressure falls. SAM opens tank fill valve until onboard water tank is refilled. NOTE The SAM Control Center WATER indicator displays chevrons while the onboard water tank is refilling. 6.3.1.5 Twister Operations (In SAM Auto Mode) The SAM system limits the action of the Twister electronic throttle knob (see Figure 40, page 34)

  • Page 93: Mobile Operations-From Tablet

    6.3.1.6 Mobile Operations–From Tablet THE TABLET COMMUNICATES THROUGH THE SAM CONTROL CENTER LOCATED IN THE OPERATORS PANEL, IF THAT SCREEN FAILS, THE TABLET WILL NOT CONTROL THE AP- PARATUS. DO NOT HARD SHUTDOWN THE TABLET (POWER OFF BY HOLDING THE POWER BUT- TON FOR LONGER THAN 5 SECONDS).

  • Page 94: Emergency Idle Activation (From A Locked Screen)

    6.3.1.6.1 Emergency IDLE Activation (From A Locked Screen) If the tablet screen is locked and activation of an emergency IDLE is required; touch the IDLE but- ton. Then drag the IDLE button to the target and lift finger off the screen. See Figure 88. Figure 88.

  • Page 95: Unlocking The Tablet Display

    The SAM system is placed in Manual Mode, the tablet user interface is unavailable (until SAM Auto Mode is reestablished) and the tablet screen displays a notice and instructions (see Figure 90). Figure 90. Emergency IDLE Activated Screen Return to the operator panel (specifically the collocated SAM Control Center and the Pump Con- troller Touch Screen location) immediately.

  • Page 96: Additional Tablet Indicators (% Battery And Signal Strength)

    Touch and drag the popup button to the popup target. (See Figure 93.) Figure 93. Unlock Screen Popup Button And Target The tablet interface now functions the same as the SAM Control Center. For further quick start information reference the main body of the Quick Start Guide (FSG-MNL–00209). 6.3.1.6.3 Additional Tablet Indicators (% Battery And Signal Strength) The pump operator should constantly be aware of the % battery and wi-fi signal strength indica-...

  • Page 97: Loosing Wi-Fi Signal

    6.3.1.6.4 Loosing Wi-Fi Signal If the wi-fi signal strength falls below an acceptable level the tablet displays a warning. (See Figure 95.) Figure 95. Wi-Fi Signal Strength Warning Example Touch CONFIRM to dismiss the popup. IF THE TABLET-TO-SAM WI-FI CONNECTION IS LOST, RETURN TO A SAM CONTROL CEN- TER ON THE APPARATUS IMMEDIATELY.

  • Page 98: Manual Mode

    6.3.2 Manual Mode A PRESSURE HAZARD MAY EXIST EVEN WHEN THE PUMP IS NOT RUNNING. PRIOR TO REMOVING HOSES OR CAPS FROM PUMP CONNECTIONS, RELIEVE PRESSURE BY OPENING DRAINS. BLEEDER VALVES SHOULD ALSO BE USED WHEN CONNECTING TO AN INTAKE FROM A PRESSURIZED SOURCE. DO NOT EXCEED OPERATING PRESSURE LIMITS OF PUMP, INSTALLED PLUMBING, HOSE(S), OR EQUIPMENT IN USE.

  • Page 99: Opening An Intake

    6.3.2.1 Opening An Intake DO NOT RUN THE PRIMER FOR MORE THAN 45 SECONDS. IF PRIME IS NOT ACHIEVED IN 30–45 SECONDS, STOP AND LOOK FOR AIR LEAKS OR BLOCKED SUCTION HOSE. A SAM equipped apparatus utilizes two (2) types of intake valves: Master intake valves and auxil- iary (Pony) valves.

  • Page 100: Auxiliary (Pony) Intake (Akron Brass Valve) Manual Procedures

    Push and hold OPEN portion of rocker switch. NOTE If the MIV is somewhere between fully open and fully closed, the OPEN/CLOSE rocker MIV should NOT be left in this switch is alternately illuminated red and green. The condition, doing so causes excessive wear to the valve. Release switch when OPEN indicator illuminates steady green.

  • Page 101: Opening A Discharge

    6.3.2.2 Opening A Discharge A PRESSURE HAZARD MAY EXIST EVEN WHEN THE PUMP IS NOT RUNNING. PRIOR TO REMOVING HOSES OR CAPS FROM PUMP CONNECTIONS, RELIEVE PRESSURE BY OPENING DRAINS. BLEEDER VALVES SHOULD ALSO BE USED WHEN CONNECTING TO AN INTAKE FROM A PRESSURIZED SOURCE. Perform the following, as applicable and/or as desired, to manually (electronically) open a dis- charge (typically Step A.

  • Page 102: Closing An Intake

    DO NOT EXCEED OPERATING PRESSURE LIMITS OF PUMP, INSTALLED PLUMBING, HOSE(S), OR EQUIPMENT IN USE. The Akron Brass valve closes the same way as it opens except the valve turns in the opposite di- rection. See paragraph 6.3.2.2, above. 6.3.2.4 Closing An Intake WHEN CLOSING AN INTAKE IN MANUAL MODE, ENSURE THE PUMP HAS AN ADEQUATE WATER SUPPLY TO PREVENT OVERHEATING.

  • Page 103: Return To Sam Auto Mode

    6.3.2.5 Return To SAM Auto Mode To exit Manual Mode and return to automated operation (SAM Auto Mode), perform the follow- ing. A. On SAM Control Center, at bottom of MANUAL VALVE CONTROL screen, touch ACTIVATE SAM AUTOFLOW button. See Figure 100. Figure 100.

  • Page 104: Miscellaneous Tasks

    The manual settings will remain in effect until the valve has be controlled in Auto Mode. Once the valve has been controlled in Auto Mode the orange border is no longer displayed. 6.3.3 Miscellaneous Tasks While in Manual Mode the Pump Controller is used to control the tank-to-pump and tank fill valves.

  • Page 105: Activating A Smartfoam Quickset

    7 for CAFS). (Reference FSG-MNL-00158 for SmartFOAM or FSG-MNL-00157 for SmartCAFS) Once the two predecessors have been accomplished, to utilize foam with the SAM system, acti- vate a foam associated Quickset from the Auto Mode Home screen or foam associated preset from the Valve X screen via the Select Discharge screen.

  • Page 106: Activating A Smartfoam Preset

    6.3.3.3.2 Activating A SmartFOAM Preset To activate a SmartFOAM preset, perform the following. A. Select appropriate foam concentrate tank. (Reference FSG-MNL-00158.) B. Touch PUSH TO PUMP (or ADD LINE) target, to display SELECT DISCHARGE screen. See Figure 103. C. Touch desired discharge (valve) button. (All foam available discharges are la- beled with the word FOAM.) Valve X screen displays (see Figure 105).

  • Page 107: Figure 107. Closing A Foam Discharge Sequence

    To close a SmartFOAM discharge, perform the following. A. On SAM Control Center Home screen, touch desired active FOAM discharge. Dis- plays Valve X screen displays. See left-hand side of Figure 107. B. On Valve X screen, swipe CLOSE LINE button to target (center of icon group). See right-hand side of Figure 107.

  • Page 108: Turn Off Smartfoam (With Sam)

    Figure 109. SmartFOAM Display With No FOAM Discharges Active 6.3.3.3.4 Turn Off SmartFOAM (With SAM) As stated above, SAM can control multiple FOAM capable discharges. No matter how many FOAM discharges are active, activating the FOAM OFF button turns off FOAM to all FOAM capable dis- charges and any open discharge continues flowing water ONLY.

  • Page 109: Using Smartcafs With Sam

    6.3.3.4 Using SmartCAFS With SAM ALTHOUGH SMARTFOAM AND SMARTCAFS BOTH UTILIZE THE FOAM LABEL, A FOAM LABELED DISCHARGE BUTTON DOES NOT OPERATE THE SAME WAY ON SAM FOR BOTH SYSTEMS. SAM also interfaces with a Hale SmartCAFS system. To utilize foam with the SAM system, two [2] predecessors must be accomplished prior to activating a FOAM or CAFS system.

  • Page 110: Activating A Smartcafs Preset

    Figure 111. Activating A CAFS Quickset C. Drag Quickset button to target (PUSH TO PUMP or ADD LINE). D. Release Quickset button (remove finger from screen). The SmartCAFS system powers on and activates preset #1. The associated concentration of foam solution is discharged. Operate CAFS from the SmartCAFS Control Display from this point, reference UV SmartCAFS In- stallation and Operation Manual (P/N FSG-MNL-00157).

  • Page 111: Changing A Cafs Discharge To Foam Only

    Figure 112. Selecting A CAFS Capable Discharge FROM THE VALVE X SCREEN, THE OPERATOR MAY SELECT WATER ONLY, FOAM ONLY, OR CAFS. TO SELECT WATER ONLY, SWIPE THE PSI PRESET (RIGHT-HAND SIDE OF THE ICON GROUP) TO THE TARGET. TO SELECT FOAM ONLY, SWIPE THE FOAM ONLY PRE- SET TO THE TARGET.

  • Page 112: Turning A Cafs Foam Only Discharge Off

    B. On Valve X screen, swipe FOAM ONLY button to target (center of icon group). See Figure 114. NOTE The next time the Valve X screen is accessed, a FOAM OFF button replaces the FOAM ONLY button. See Figure 114. See the following paragraph for instructions to use the new button.

  • Page 113: Figure 115. Closing A Cafs Discharge Sequence

    Figure 115. Closing A CAFS Discharge Sequence NOTES If only one CAFS discharge is open, the FOAM OFF and CLOSE LINE buttons activate automatically (the same as a preset would). No confirmation is required. If more than one CAFS discharge is open the FOAM OFF confirmation popup window appears (See Figure 108, page 91) and then the CLOSE LINE confirmation popup win- dow appears (See Figure 108, page 91).

  • Page 114: Turning Off Cafs (When Activated With Sam)

    6.3.3.4.5 Turning Off CAFS (When Activated With SAM) When SAM activates CAFS, (via activating a Quickset or a preset) and then CAFS is turned off (via the SAM Control Center) all open lines flow water only. ACTIVATING A FOAM OFF BUTTON TURNS OFF THE SMARTCAFS SYSTEM, TURNING OFF FOAM TO ALL FOAM CAPABLE DISCHARGES, HOWEVER, THE DISCHARGE(S) ARE NOT CLOSED AND CONTINUE TO FLOW WATER ONLY.

  • Page 115: Exporting The Pump Controller Datalogger File

    C. Connect USB stick to USB dongle on rear of SAM Control Center. See Figure 118. Figure 118. SAM Control Center USB Dongle D. On Device Select MENU, touch Menu icon. E. On Home MENU, touch More button. F. Touch Export Data Log To USB button. Saving …...

  • Page 116: Governor Operations From The Pump Controller

    C. On Pump Controller, touch Export Datalogger command. Saving file to the USB stick … appears below command. D. Wait for Data log file has been saved to the USB stick. to appear below com- mand. NOTES The save may take several minutes to complete. A comma separated values file named LogFile_MatrixDisplay.csv appears on the USB stick when the transfer completes.

  • Page 117: Using Psi Mode

    If mode is MODE PSI, target (DISCHARGE–––PSI) strobes. (See paragraph 4.1.2, Buttons/Targets (Drag-N-Drop Navigation), page 20, for navigation descriptions/information.) If mode is MODE RPM, target (ENGINE SPEED–––– RPM) strobes. NOTE No matter which governor mode is selected the (ENGINE SPEED–––– RPM) is always either the primary target (which strobes) or the alternate target (which does NOT strobe yet actives the preset buttons set point).

  • Page 118: Using Rpm Mode

    6.3.4.2.2 Using RPM Mode RPM Mode governor control of the apparatus is very similar to Auto Mode control of the appa- ratus, in that, the engine speed is being controlled to maintain a desired/selected set point. RPM Mode would be used anytime traditional governor operations are desired/required (typically dur- ing annual NFPA required pump testing) or if SAM Auto Mode fails or does NOT provide the de- sired control of the pump.

  • Page 119: Rpm Mode Operations

    B. On Pump Controller, observe set point pointer movement. C. Repeat Step A until desired set point is displayed. D. On Pump Controller, observe DISCHARGE PSI indication agrees with set point. 6.3.5.2 RPM Mode Operations The Twister control knob controls the engine the same way in RPM Mode as in PSI Mode except the SET ENGINE SPEED directly indicates the engines RPM (speed).

  • Page 120: Akron Brass Swing-Out Valve Physical Override

    C. Locate MIVs Manual Override placard/handwheel. See Figure 121. Figure 121. MIV Manual Override Placard (Handwheel NOT Shown) D. Override current valve position as follows. Rotate handwheel CW to close valve. Rotate handwheel CCW to open valve. Turn handwheel (as indicated by placard) until it stops. NOTE To verify master intake valve position there is an indicator arrow located on the master intake valve gearbox that points to an OPEN or a CLOSE label when the master intake...

  • Page 121: Figure 122. Akron Brass Valve Power Connector

    B. Locate and disconnect valve power connector. See Figure 122. Figure 122. Akron Brass Valve Power Connector C. At hex end of motor shaft, attach a 7-16-inch wrench (a ratchet wrench is easier and quicker to use) or socket. If using a socket, attach an electric driver (easiest and fastest) or ratchet.

  • Page 122: Operator Responses To Sam Alarms

    6.3.7 Operator Responses To SAM Alarms The system includes a buzzer to provide beeps to get the operators attention. The system also comes standard with speakers to alert the operator and others on the fireground when critical events are happening with the water flow or truck. SAM Speaks follows selected caution/mes- sages/warning tones by spoken details of what is happening so the operator can react.
  • Page 123 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED CHECK HYDRANT SUPPLY During transition to hydrant Check for supply restrictions (Such (pressurized water supply) ex- as a closed hydrant valve, dam- cessive time elapses without aged/kinked supply hose, etc.) an appropriate intake pressure Equipment failure Perform Bypass Venting, para- graph 6.3.1.2.1, page 70 or para-...
  • Page 124 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED FOAM COMM LOSS, USE Equipment failure Use the SmartFOAM display to SMARTFOAM DISPLAY control foam lines NOTE SAM does NOT auto flush: • flush after Type B foam ops required • flush after Hale approved Type A foam ops NOT re- quired (but recommended)
  • Page 125 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED INLINE INTAKE MASTER IN- Equipment failure Perform valve physical override TAKE VALVE MODULE LOST (See paragraph 6.3.6.1, pg. 103) OPERATE IN LINE MASTER NOTE INTAKE VALVE WITH MAN- Report incident to maintenance UAL OVERRIDE KNOB INTAKE MODULE SIGNAL Equipment failure...
  • Page 126 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED LOW OIL PRESSURE Apparatus engine low oil level Shut down apparatus engine as CRITICAL soon as possible NOTE Check apparatus engine oil level Message passed thru from en- and correct if low gine ECU (via the CAN network) for SAM to display NOTE...
  • Page 127 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED POSSIBLE CAVITATION SAM detects an increase in en- Check for supply restrictions (Such gine speed AND no increase in as partially closed hydrant valve, discharge pressure(s) damaged/kinked supply hose, etc.) Reduce discharge flow rate (Water supply problem other than above) Equipment failure...
  • Page 128 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED RH INTAKE MASTER INTAKE Equipment failure Perform valve physical override VALVE MODULE LOST OPER- (See paragraph 6.3.6.1, pg. 103) ATE RH MASTER INTAKE NOTE VALVE WITH MANUAL OVER- Report incident to maintenance RIDE KNOB SAM SCREEN SIGNAL LOST Equipment failure...
  • Page 129 Table 8. SAM Operator Troubleshooting–CONTINUED SYMPTOM CAUSE REMEDY WARNINGS–CONTINUED WARNING LOW INTAKE Intake pressure falls below low Check for supply restrictions (Such PRESSURE intake pressure governor set as partially closed hydrant valve, point damaged/kinked supply hose, etc.) Intermittent/weak hydrant Add another water source (or change to new one) Reduce discharge flow rate (Water supply problem other than...

  • Page 130: Shutdown

    6.4 Shutdown This section provides instructions to properly shutdown the SAM tablet and top level instruction to shutdown the SAM system on the apparatus. 6.4.1 SAM Tablet Shutdown DO NOT HARD SHUTDOWN THE TABLET (POWER OFF BY HOLDING THE POWER BUT- TON FOR LONGER THAN 5 SECONDS).

  • Page 131: Sam At The Apparatus Shutdown

    D. Drag finger to bottom of screen. (See Figure 124.) E. Lift finger off screen. F. On confirmation pop up, touch YES. (See Figure 125.) Figure 125. Shutdown Confirmation G. Wait for tablet to turn off (screen goes dark). 6.4.2 SAM At The Apparatus Shutdown When SAM operations conclude, perform the following, as applicable and/or as desired, to shut- down and prepare the apparatus to stop pumping operations.

  • Page 132: Figure 126. Sam Home Screen (With Active Quickset Shown)

    Figure 126. SAM Home Screen (With Active Quickset Shown) C. If connected to an external water source, (depending on water quality) allow time for onboard water tank to fill. D. With onboard water tank full (if applicable), close all intake valves as follows. Swipe balloon for intake you desire to close to target.

  • Page 133: Preventive Maintenance

    7. PREVENTIVE MAINTENANCE Regular preventive maintenance assures continued dependable operation. This section provides rec- ommended actions to be completed for SAM system unique items. Refer to the Hale and/or OEM/ apparatus builder manual that came with the apparatus/pump for all ancillary item and/or pump maintenance item and their associated schedules.

  • Page 134: Table 10. Recommended Preventive Maintenance-Ancillary Equipment

    Table 10. Recommended Preventive Maintenance–Ancillary Equipment Interval Check/Test Action Required Item(s) Required After Each Use Check Master Intake Valve Inspect valve for debris. Supply of clean water (Hale MIV) Flush if exposed to contaminated water Grease (foam, salt, etc.) Lubricate disc edges Check And Clean Foam Remove strainers and clean strainers.

  • Page 135: After Each Use

    Table 10 Recommended Preventive Maintenance–CONTINUED Interval Check/Test Action Required Item(s) Required Bi-Monthly (Every 2 Months) Check All Navigator Pro Check that pressure indications are re- Calibrated test gauge Controllers peated, agree with the gauge on the op- erator panel. Check that all pressure indications read within 10% of a calibrated test gauge.

  • Page 136: Flush Pump

    7.1.1.2 Flush Pump After pumping salt water, contaminated water or foam solution, or if water containing sand/or other foreign matter has been used, connect the pump to a fresh water hydrant or other source of fresh clean fresh water and flush the contaminants out of the pump. Perform the following to flush a mid- ship pump with SAM.

  • Page 137: Akron Brass Swing-Out™ Valve Motor Operating Current Check

    • Manual Mode • No accuracy/resolution software override • The Auxiliary Cooling Solenoid is NOT open in Manual Mode • The Twister and/or the Pump Controller set point controls engine speed The following information may be of help in operate the SAM system for NFPA 1911 performance level testing, Tank-to-Pump Flow Rate testing purposes.
  • Page 138 THIS PAGE INTENTIONALLY BLANK.

  • Page 139: Adjustments

    8. ADJUSTMENTS This section provides descriptions of the SAM system adjustments and calibrations. This section also provides step by step instructions for the performance of SAM system adjustments and calibrations that may be performed by operators, installers, or maintenance personnel. 8.1 ITL–40 Calibration Using SAM Pump Controller PERFORMING THIS PROCEDURE CAUSES SAM TO EXIT AUTO MODE.

  • Page 140: Figure 129. Itl-40 Calibration Screen

    NOTE To exit calibration at any time, touch System Options icon (located in lower left-hand corner of screen, see Figure 128 thru Figure 130). D. Touch check box (located to the right of the instructions text box) when onboard wa- ter tank is full and you are ready to begin calibration.

  • Page 141: Appendix A. Manufacturers Information

    607 NW 27th Ave, Ocala, FL 34475 Email: https://www.haleproducts.com Godiva LTD Mailing: Tel: +44 (0) 1926 623600 (A Unit of IDEX Corp.) Charles Street, Warwick, England, CV34 5LR FAX: +44 (0) 1926 623666 Email: godiva@idexcorp.com A.2. Warranty See the Hale website (www.haleproducts.com) for product specific warranty and warranty proce-...

Table of Contents
