hepco & becker 410999 00 01 Quick Start Manual

Fender guard for honda x-adv 2017-

Advertisement

Fender Guard
HONDA X-ADV
ab Baujahr 2017 / from date of manufacture 2017
Artikel Nr.: / Item-no.:
999
410
00 01
schwarz/black
INHALT
CONTENTS
1x
Schutzbügel Kotflügel
1x
Schraubensatz
2x Zylinderschraube ISK M6x30
2x Linsenkopfschraube M6x45
2x U- Scheibe Ø6,4
2x Aludistanz Ø15xØ7x20mm
BENÖTIGTE WERKZEUGE

TOOLS REQUIRED

Set
WICHTIG

IMPORTANT

Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Zur Montage ist eine zweite Person hilfreich.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
To mount this guard, a second person is helpful.
Guard for front fender
Screw kit:
2x allen screw M6x30
2x filister head screw M6x45
2x washer Ø6,4
2x alu spacer Ø15xØ7x20mm
Verlängerung
Ratsche
extension
Ratchet
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 410999 00 01 and is the answer not in the manual?

Questions and answers

Summary of Contents for hepco & becker 410999 00 01

  • Page 1 Fender Guard HONDA X-ADV ab Baujahr 2017 / from date of manufacture 2017 Artikel Nr.: / Item-no.: 00 01 schwarz/black INHALT CONTENTS Schutzbügel Kotflügel Guard for front fender Schraubensatz Screw kit: 2x Zylinderschraube ISK M6x30 2x allen screw M6x30 2x Linsenkopfschraube M6x45 2x filister head screw M6x45 2x U- Scheibe Ø6,4 2x washer Ø6,4...
  • Page 2 Fender Guard HONDA X-ADV ab Baujahr 2017 / from date of manufacture 2017 Artikel Nr.: / Item-no.: 00 01 schwarz/black VORBEREITUNG PREPARING Die 4 Originalschrauben des Fenders rechts und links entfernen und diesen auf dem Vorderrad ablegen, Originalschrauben entfallen. Remove the 4 original screws of the fender left and right and place it on the front wheel, original screws are obsolete. MONTAGEANLEITUNG MOUNTING INSTRUCTIONS Montage Fender Guard links/rechts:...
