Sony CDX-GT130 Marketing Specifications

CDX-GT130
Key Features
DRIVE-S Chassis
Detachable Faceplate with
Front Aux Input
Rear/Sub selectable Preout
with HPF/LPF
Specifications
Audio Features
Level Control: -8dB ∼ +18dB
Convenience Features
Illumination: Red
On-Screen Clock: 12H
Video Features
Display Technology: LCD
General
Color: '07 Gun Metallic
Audio
Preout Voltage: 2 volt
S/N Ratio: CEA 2006 S/N 82 dB
Frequency Response: 10-20,000Hz
Wow and Flutter: Below Measurable
Limit
Station Preset(s): FM18/AM12
Digital-to-Analog Converter: 24bit
Tuner Frequency Range: FM:Tuner
Frequency Range(MHz): 87.5-
107.9, AM:Tuner Frequency
Range(kHz): 530-1710
Signal-to-Noise Ratio: CD: 120dB
Tone Control(s): Low: +/-10 dB at
60Hz (XPLOD) Mid: +/-10dB at
1kHz (XPLOD) High: +/-10dB at
10kHz (XPLOD)
Tuner Type: SSIR-EXA
Output Impedance: 4-8 Ohms
Volume Control: Tel/Nav
Attenuation
CD Playback: Wow and flutter-Below
measurable limit
Band: AM / FM
Sensitivity (db): FM:Usable
sensitivity (75)(dBf):10
Convenience
Tilt Range: 45°
Amplifier Section
Speaker Impedance: 4-8 Ohms
Tuner
FM Usable Sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
S/N Ratio: 70 dB
Frequency Response: 20 - 15,000 Hz
Stereo Separation: 40 dB at 1 kHz
CD Receiver Head Unit
Tape Player
Frequency response: CD: 10-
20,000Hz
Power
Power Consumption (in
Operation): 45W
Output Power: 52W x4 High Power -
17 watts per channel minimum
continuous average power into 4
Ohms, 4 channels driven from 20
Hz to 20 kHz with no more than 5%
total harmonic distortion.
Input Power: 12 V DC car battery
(negative ground (earth))
Inputs and Outputs
Input(s): Front Aux In
Antenna Terminal(s): Aerial Input
Terminal
Audio Out (Variable/Fixed):
Speaker outputs (sure seal
connectors)
12V Trigger Output(s): Power
antenna Amplifier turn on
Analog Audio Input(s) (Total):
Front Aux-In
Dimensions
Weight: 1.2Kg
Measurements: 178 x 50 x 179mm
Supplied Accessories
Parts for installation and
connections (1 set)
Color: Gun Metallic
UPC Code: 027242743755
