Other Information

Using the HDMI Input Port

The HDMI Input port on the front side of the receiver works as a pass-
through port. This allows you to connect an external HDMI device to your
TV via the receiver. You can connect a Playstation
Follow the instructions below to use the pass-through port. Turn off your TV
before connecting additional devices.
1
Connect an HDMI cable (you will need to supply your own cable)
between the pass-through port on the front side of the receiver and the
HDMI device as illustrated below.
HDMI 1
2
Power on the TV and the additional device.
3
Press the INPUT button and toggle to the HDMI input that your
receiver is connected to on the TV. If your receiver is connected to
HDMI 1, then the PS3 (or other external device) can be accessed by
selecting HDMI 1. You can also label this input. See your TV's
Operating Instruction Manual for further details on labeling inputs.
Some HDMI devices have features which use HDMI-CEC control
signals. Some of these features are not supported by this pass-through
mode.
®
3 or other HDMI device.
HDMI Cable
(not supplied)
43
