Fermax LYNX Series Programming Manual

Digital panel
Hide thumbs Also See for LYNX Series:
Table of Contents

Advertisement

Quick Links

Download this manual
LYNX PANELS-Programming Manual
Code 97746I V06_14
DIGITAL LYNX
PANEL
BASIC PROGRAMMING MANUAL
This is the basic instruction manual for programming and starting up a LYNX series DIGITAL PANEL.
The DIGITAL panel may be configured remotely via the incorporated web server. This web server is accessed
via the G. E. panel default IP address, which for block panels is: 10.200.100.0
For more details see the LYNX Panel's Web server manual cod. 97744 in www.fermax.com.
To add users to the panel you need the Property Management Unit (Guard Unit) software.
Page 1

Advertisement

Table of Contents
loading

Related Manuals for Fermax LYNX Series

Summary of Contents for Fermax LYNX Series

  • Page 1 PANEL BASIC PROGRAMMING MANUAL This is the basic instruction manual for programming and starting up a LYNX series DIGITAL PANEL. The DIGITAL panel may be configured remotely via the incorporated web server. This web server is accessed via the G. E. panel default IP address, which for block panels is: 10.200.100.0 For more details see the LYNX Panel’s Web server manual cod.
  • Page 2 LYNX PANELS-Programming Manual Page 2...

  • Page 3: Table Of Contents

    LYNX PANELS-Programming Manual INDEX PROGRAMMING ACCESS ...............4 1 PANEL CONFIGURATION-SETTINGS MENU ........5 1.1 CALL PANEL SETTINGS-Type ..................5 1.2 CALL PANEL SETTINGS-Block# ................... 5 1.3 CALL PANEL SETTINGS-Panel# ................... 6 1.4 CALL PANEL SETTINGS-Panel Tag ................7 1.5 CALL PANEL SETTINGS-Alpha keypad ................ 7 1.6 CALL PANEL SETTINGS-Available blocks ..............

  • Page 4: Programming Access

    LYNX PANELS-Programming Manual PROGRAMMING ACCESS Prior to programming any parameter on the LYNX PANEL, you must access its programming mode, for which you need the access codes. The first of these is always the same, even though the second may change within the programming.

  • Page 5: Panel Configuration-Settings Menu

    LYNX PANELS-Programming Manual 1 PANEL CONFIGURATION-SETTINGS MENU From this section you configure all panel parameters. Procedure 1. From the CONFIGURATION MENU, press "1" on the numeric keypad to select CALL PANEL SETTINGS. 2. A list of available options appears concerning the call panel parameter settings, that are described in the following sections.

  • Page 6: Call Panel Settings-Panel

    LYNX PANELS-Programming Manual Procedure (for a "general entrance") 1. From the PANEL SETTINGS menu, press "2" on the numeric keypad to select Block#. 2. Use the left and right keys to select the type of panel from the available options. 3.

  • Page 7: Call Panel Settings-Panel Tag

    LYNX PANELS-Programming Manual 1.4 CALL PANEL SETTINGS-Panel Tag This allows you to assign a name to this panel. This name will appear on the monitors and the PMU, when called, as a reference. Procedure 1. From the CALL PANEL SETTINGS menu, press "4" on the numeric keypad to select Panel Tag 2.

  • Page 8: Call Panel Settings-Reset Settings

    2. Press "A" to confirm or "B", if you do not want to reset it now. 3. If you select "A" the panel will turn off, automatically restart after 30 to 60 seconds, while the FERMAX logo and home screen appears. Observations - During this start-up process the screen will display the firmware version installed and the MAC address.

  • Page 9: Audio Configuration-Settings Menu

    LYNX PANELS-Programming Manual 2 AUDIO CONFIGURATION-SETTINGS MENU From this section you can set the parameters regarding audio levels, which depend on the acoustic characteristics of the site's installation. Procedure 1. From the CONFIGURATION MENU, press "2" on the numeric keypad to select Audio settings. 2.

  • Page 10: Retroview

    LYNX PANELS-Programming Manual 3.2 Retroview With this option you can configure the panel so that the picture taken by its camera appears on the display. Procedure 1. From the CALL SETTINGS menu, press "2" to access the Retroview option. 2. Use the left and right arrow keys to select the required option. 3.

  • Page 11: Configuration Menu-Presentation

    LYNX PANELS-Programming Manual Add unit Use this function to indicate the units´ data (apartments) that we want to appear on the panel display. It allows you to include a maximum of 200 total registers out of 10,000 allowed by the system. If a call is made to a number out of this list, the message will be displayed with the message «non- existent number»...

  • Page 12: Language

    LYNX PANELS-Programming Manual 4.1 Language This allows you to select the panel´s language, both in programming and as a user, besides the voice synthesis. Procedure 1. From the Presentation menu, press "1" on the numeric keypad to select Language. 2. Select the desired language with the left and right arrows from the available options.

  • Page 13: Agenda

    LYNX PANELS-Programming Manual 4.3 AGENDA With this option we can indicate if when searching to make a call, the data from only 1 user is presented on the screen or 4 users at a time, one over the other. Procedure 1.

  • Page 14: Date And Time

    LYNX PANELS-Programming Manual 4.6 Date and Time Use this option to put the date/time incorporated in the street panel, along with the date's format. This data is continuously displayed on the screen, in user mode. Procedure 1. From the Presentation menu, press "6" to access the date &...

  • Page 15: Additional Information

    LYNX PANELS-Programming Manual 4.7 Additional information With this option we can indicate if we want the user's additional information to appear, when the display is in a user's mode. Procedure 1. From the Presentation menu, press "7" to select additional information.

  • Page 16: Relay

    LYNX PANELS-Programming Manual 5.1 Relay From this section we can set the parameters relative to the eventual functions of the Access Control (manage internal relays in the panel, or future external relays and/or lift control relay for lifts installed in the system).

  • Page 17: Relay Tag 1

    LYNX PANELS-Programming Manual 5.1.2 Relay tag 1 With this option you can enter the text to appear on the display while relay 1 is being activated. Procedure 1. From the Relay menu, press "2" on the numeric keypad to select Relay 1 tag. 2.

  • Page 18: Relay Time 2

    LYNX PANELS-Programming Manual 5.1.4. Relay time 2 Via this parameter we can program the time, in seconds, which we want to activate relay 2 when it is activated from one of the modes indicated in the previous point. Procedure 1. From the Relay menu, press "4" on the numeric keypad to select Relay 2 time.

  • Page 19: Lift Control Relay

    LYNX PANELS-Programming Manual 5.1.7 Lift control relay This option is used to define the configuration of the relay to control the lift. See "Observations" in section 1.5.1.3 Internal Relay 1. Procedure 1. From the Relay MENU, press "7" on the keypad to select Lift control relay.

  • Page 20: Pin Code

    LYNX PANELS-Programming Manual 5.3 PIN Code Users of the building may open the entrance door by entering the personal PIN via the panel's keypad. You can also change this PIN code by presenting a proximity card (if the panel has a reader). This code is assigned by the system administrator during the programming, but to use it you need to enable it following these steps.

  • Page 21: Installation Code

    LYNX PANELS-Programming Manual 5.4 Installation Code This parameter allows you to change the access code to access the panel's programming. Procedure 1. From the MENU of Access Control, press "4" on the numeric keypad to select Installer Code. 2. Press "A" to delete the number indicated by default. 3.

  • Page 22: Network

    LYNX PANELS-Programming Manual 6 NETWORK This parameter is only for informational purposes. It indicates the MAC and IP address on the panel. Procedure 1. From the Relay MENU, press "6" on the keypad to select RED. 4. Press B to exit and return to the MAIN MENU. Page 22...
  • Page 23 LYNX PANELS-Programming Manual APPENDIXES Resetting the INSTALLER CODE Description of keypad keys lll. Languages Available Page 23...
  • Page 24 LYNX PANELS-Programming Manual I. Resetting the INSTALLER CODE If the default installation code has been changed, and you do not remember or don't know which is the new code, it is possible to restore it to the default value: 1. Disconnect the panel’s power supply and wait a few seconds. 2.
  • Page 25 LYNX PANELS-Programming Manual lll. Languages Available The presentation of menus and messages in the display may be presented in any of the 31 languages. During the initial programming, and with the aim of facilitating the reading of the different language, the description of each of them is presented in the corresponding language and typography.
