Range Road RR608 Assembly Manual

1.) Unpack all pieces from the tub & crate, empty bag with nuts, bolts and pins onto a flat surface.
2.) Find the main frame, lay on the floor with axle tabs facing up.
3.) Place the walking beams between the tabs on either side, there is not a right or left, either walking
beam can be used for both sides, however, one leg of the walking bean is longer than the other, the
39cm leg of the axle should be towards the front of the trailer on both sides. Line up the hole in the
walking beam with the tabs on the frame, push the pin in to hold axles in place.
