Summary of Contents for Reely 2267650
- Page 1 Operating Instructions 4 Channels Gen4 Pistol Grip Remote Control 2.4 GHz Item No. 2267650 Page 2 - 18...
-
Page 2: Table Of Contents
Table of contents Page Introduction ................................4 Explanation of symbols ............................4 Intended use ................................4 Delivery content ..............................4 Up-to-date operating instructions .........................5 Safety instructions ...............................5 a) General information ............................6 b) Operation ...............................6 c) Receiver / antenna ............................7 d) Transmitter..............................7 e) (Rechargeable) batteries ..........................7 Operating elements .............................8 a) Transmitter..............................8 b) Receiver / antenna ............................10... - Page 3 12. Care and cleaning ..............................17 13. Declaration of Conformity (DOC) ........................17 14. Disposal ................................17 a) Product ................................17 b) (Rechargeable) batteries ..........................17 15. Technical data ..............................18 a) Transmitter (TX)............................18 b) Receiver (RX) / antenna ..........................18...
-
Page 4: Introduction
1. Introduction Dear customer, Thank you for purchasing this product. This product complies with the statutory national and European requirements. To maintain this status and to ensure safe operation, you as the user must observe these operating instructions! These operating instructions are part of this product. They contain important notes on commissioning and handling. -
Page 5: Up-To-Date Operating Instructions
5. Up-to-date operating instructions Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown. Follow the instructions on the website. 6. Safety instructions Read the operating instructions carefully and especially observe the safety information. If you do not follow the safety instructions and information on proper handling in this manual, we assume no liability for any resulting personal injury or damage to property. -
Page 6: A) General Information
a) General information • This product is not a toy. It is not suitable for children under 14 years of age unless closely supervised by a responsible adult. • Do not leave packaging material lying around carelessly. This may become dangerous playing material for children. -
Page 7: C) Receiver / Antenna
c) Receiver / antenna • To prevent loss of control: - Make sure the receiver battery is disconnected before turning off the transmitter. - Do not power on the receiver during the setup process. • For best signal quality: - Mount the antenna is mounted perpendicular to the model body in an upright position. - Mount the receiver away from motors, electronic speed controllers, or any device that can interfere with the signal. -
Page 8: Operating Elements
7. Operating elements a) Transmitter... - Page 9 1 Panel cover 8 Power switch (ON/OFF) 15 Base / battery compartment 2 Steering reverse switch (ST.RV) 9 Bind button (BIND) 16 Three-position AUX switch (CH3) 3 Power indicator LED (R.LED) 10 Throttle reverse (TH.REV) 17 AUX button (CH4) 4 Steering trim (ST.TRIM -) 11 Steering trim (ST.TRIM +) 18 Steering wheel (CH1) 5 Status indicator: Green (G.LED)
-
Page 10: B) Receiver / Antenna
b) Receiver / antenna Signal Antenna Channel Description Steering servo Throttle servo AUX servo AUX servo / battery connector The battery can connect to any channel. CH3 and CH4 can be used for various switching tasks or additional control functions such as lighting circuits. -
Page 11: Standard Wiring Diagrams
9. Standard wiring diagrams Important: • Observe Safety instructions → "c) Receiver / antenna" on page 7. • Two-sided adhesive foam (servo tape) is a suitable method for fastening the base of the receiver / antenna to the model. a) Electronic speed controller (E.S.C.) E.S.C. -
Page 12: Operation
10. Operation a) Power ON Important: Turn the transmitter ON first, and then turn the receiver ON. 1. Check that the batteries are fully charged and installed correctly. 2. Switch the transmitter POWER ON, the R.LED will light. 3. Switch the receiver power supply ON. b) Binding (transmitter with receiver) The transmitter has already been bound to the receiver at the factory. -
Page 13: D) Power Off
d) Power OFF Important: Turn the receiver OFF first, and then turn the transmitter OFF. 1. Switch the receiver power supply OFF. 2. Switch the transmitter POWER OFF. 11. Controls a) Transmitter channels Channel Description Steering servo Throttle servo AUX servo switch (three-positions). For example, the three-switch positions affect the servos as follows: AUX servo button (minimum / maximum). -
Page 14: B) Beginner Mode
b) Beginner mode There are two modes, normal and beginner. Beginner mode is designed for novice model users. The throttle response will be reduced by 50% making the model easier to control. • To enter beginner mode: Press and hold the CH4 button and the steering wheel all the way counter-clockwise, and then switch the transmitter POWER ON. -
Page 15: E) Adjust Trim
Test the fail-safe 1. Turn the transmitter POWER ON first, then turn the receiver power supply ON. 2. Support the model on a stand so that any moving parts can run freely. 3. Activate and hold the throttle or steering, then switch the transmitter POWER OFF. 4. -
Page 16: F) Adjust Servo Travel
f) Adjust servo travel After installation, if the servo arms are not square / 90° to the axis of the servo (image A), adjust the servo travel to center the arm image B). You will not need to adjust the servo travel again unless the setup has changed. - Page 17 12. Care and cleaning Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they can cause damage to the housing and malfunctioning. • Before each cleaning, first turn the receiver OFF and then turn the transmitter OFF. •...
- Page 18 15. Technical data a) Transmitter (TX) Battery ..............4x AA 1.5 V (6 V/DC) Important: Do not use lithium batteries. The output may be <4.2 V which will trigger the low battery warn- ing. Low battery warning .........<4.2 V Channels ............4 Modes ...............Normal and beginner Application ............Car, boat Antenna ............internal...
- Page 19 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
