- Page 1 Operating Instructions 10-channel remote control “HT-10”, 2.4 GHz Item No. 1518204...
-
Page 2: Table Of Contents
Table of Contents Page Introduction ................................3 Explanation of Symbols ............................3 Intended Use ...............................4 Product Description .............................4 Scope of Delivery ..............................5 Safety Notes ................................5 a) General ................................5 b) Operation ...............................6 Battery and Rechargeable Battery Notes ......................7 Charging Rechargeable Batteries ........................8 Operating Elements of the Transmitter ........................9 10. -
Page 3: Introduction
1. Introduction Dear Customer, thank you for purchasing this product. This product complies with the statutory national and European requirements. To maintain this status and to ensure safe operation, you as the user must observe these operating instructions! These operating instructions are part of this product. They contain important notes on commissioning and handling. -
Page 4: Intended Use
3. Intended Use The 10-channel remote control "HT-10" is solely designed for private use in the field of model construction and the operating times associated with it. This system is not suitable for industrial use, such as controlling machines or equipment. -
Page 5: Scope Of Delivery
5. Scope of Delivery • Remote control transmitter • Remote control receiver • Binding plug • Latching bracket with screws • Operating instructions on CD Current operating instructions Download the current operating instructions via the link www.conrad.com/downloads or scan the QR code displayed. -
Page 6: B) Operation
• Please check the functional safety of your model and of the remote control system each time before you use the model. Watch out for any visible damage such as defective plug connections or damaged cables. All movable parts on the model have to be running smoothly. However, there must be no tolerance or 'play' in the bearing. -
Page 7: Battery And Rechargeable Battery Notes
7. Battery and Rechargeable Battery Notes Although use of batteries and rechargeable batteries in everyday life is a matter of course today, there are many dangers and problems. Therefore, always observe the following information and safety notes in handling of batteries and rechargeable batteries. •... -
Page 8: Charging Rechargeable Batteries
8. Charging Rechargeable Batteries If you use rechargeable batteries for power supply of the receiver, they are usually flat at delivery and must be charged. Observe: Before a rechargeable battery reaches maximum capacity, several complete discharge and charge cycles are necessary. Always discharge the rechargeable battery at regular intervals, since charging a "half-full"... -
Page 9: Operating Elements Of The Transmitter
9. Operating Elements of the Transmitter Figure 1 1 Transmitter aerial 11 Reverse switch for channel 1 - 4 2 Dial switch for channel 8 12 Mixer switch 3 Carrying handle 13 Binding button 4 Switch for channel 9 14 Trimming button for channel 4 5 Switch for channel 10 15 Control stick for channel 3 and 4 6 Trimming button for channel 2... -
Page 10: Setting Up The Transmitter
10. Setting up the Transmitter In the further course of these instructions, figures in the text always refer to the adjacent figure or the figures within the section. References to other figures are indicated with the corresponding figure number. a) Inserting the Batteries For the power supply of the transmitter you will need 4 alkaline batteries (e.g. -
Page 11: C) Setting The Control Stick Length
c) Setting the Control Stick Length You can adjust the length of the control sticks, depend- ing on your steering habits. To do so simply hold the bottom part of the grip (1) and turn the upper part (2) up anti-clockwise. You can now set the length of the control lever by turning the bottom part of the grip. -
Page 12: Setting Up The Receiver
11. Setting up the Receiver a) Connecting the Receiver The receiver offers connection options for up to 10 ser- vos (channels 1 to 10 correspond to the receiver outputs "CH1" to "CH10"). The servos can also be replaced by motor/speed controllers or switching elements. If the remote control is used for a plane/helicopter model, the receiver outputs "CH1"... - Page 13 When using servos with high power demand, we recommend to always use a receiver battery pack. The connections are designed for Futaba plug connectors. If required, you can also easily use JR plugs or plug connectors of the same build. Important! When connecting servos and speed controllers, always make sure of correct polarity of the plug connec- tors.
-
Page 14: B) Mounting The Receiver
b) Mounting the Receiver Installation of the receiver depends on the model. For this reason, you should always follow the recommendations of the model manufacturer regarding the installation. Regardless of the model, you should always try to install the receiver so that it is protected from dust, dirt, moisture, heat and vibration in the best possible way. -
Page 15: Installing The Servos
12. Installing the Servos The installation of a servo (1) always depends on the particular model used. Detailed information on this can be found in the construction documents of the model. Generally, however, try screwing in the servos in a vi- bration-dampened manner. -
Page 16: Setting The Trim
13. Setting the Trim The trim mostly serves to correct the slight inclination of the servo levers for channels 1 to 4 due to the interlock and the connected irregular control movements. Additionally, there is the option to adjust the model in operation precisely, e.g. -
Page 17: Checking The Servo Directions Of Travel
14. Checking the Servo Directions of Travel For function, driving or ship models, you can individually specify the driving and steering functions of the control levers, since both control levers are returned to the middle position by spring force. For flight or helicopter models, it is best to comply with the above control lever functions for channels 1 to 4. -
Page 18: Switching The Servo Directions Of Travel
15. Switching the Servo Directions of Travel If the movement directions of the servos or the speed controller function at the receiver outputs "CH1" to "CH4" are not as required, you can switch the running direc- tion of the servos or the speed controller function in the transmitter with the reverse switches (also see figure 1, item 11). -
Page 19: Conversion Of The Control Lever Functions
16. Conversion of the Control Lever Functions If you want to control a motor-powered flight model with your "HT-10" remote control, the left control lever must not return to the middle position on its own at forward or reveres movement (throttle/pitch function). It must remain in the position into which it was last moved. -
Page 20: Changing The Control Lever Allocation
17. Changing the Control Lever Allocation If you do not want to operate your motor or helicopter model by controlling the throttle/pitch function with the left control lever (mode II) as intended ex works, but with the right control lever (mode I), the transmitter can be adjusted accordingly. -
Page 21: Mixer Function
18. Mixer Function The remote control "HT-10" has a mixer function that can be activated with the mixer switch (also see figure 1, item 12). When the slider is in the bottom position, regular operation without mixer function is active. If the slider is pushed up, channel 1 "CH1"... - Page 22 Figure 13...
- Page 23 Use of the mixer in a crawler: In a crawler where every chain is controlled via a dedicated motor with speed controller, channel 2 "CH2" and channel 3 "CH3" can be used for driving. The control then takes place with the two control levers and the mixing function can be switched off.
- Page 24 If you want to control only using one control lever, the two speed controllers for the left and right chains must be con- nected to channel 1 "CH1" and channel 2 "CH2". When the mixer has been activated, the model must react according to figure 15.
-
Page 25: Switching The Digital Code
"AFHDS 2A" encoded receiver. If you want to operate a REELY receiver with the digital code "AFHDS", the transmitter must be switched first and then the receiver must be bound to the transmitter (see following chapter). -
Page 26: Binding Function
20. Binding Function To enable transmitter and receiver to work together, they must be bound by the same digital code. In the delivery state, transmitter and receiver are aligned with each other and can be used at once. The binding settings must be renewed mainly after a replacement of the transmitter or receiver or to remove any interferences. -
Page 27: Simulator Function, Student Transmitter Function
21. Simulator Function, Student Transmitter Function If required, you can also use the transmitter at the PC for simulations or games. In this case, you will require the optional USB cable (Conrad item no. 517956) and suitable computer software (e.g. flight simulation games, etc.). The USB cable is connected to the PS2 interface socket (1) at the rear of the transmitter. -
Page 28: Troubleshooting
23. Troubleshooting Problem Remedy Transmitter doesn’t respond • Check the batteries in the transmitter. • Check the polarity of the batteries. • Check the battery contacts of the remote control. • Check the on/off switch. The servos do not respond •... -
Page 29: Disposal
24. Disposal a) Product Electronic devices are recyclable and should not be disposed of in household waste. Dispose of the prod- uct according to the applicable statutory provisions at the end of its service life. Remove any inserted batteries/rechargeable batteries and dispose of them separately from the product. b) Batteries/Rechargeable Batteries You as the end user are required by law (Battery Ordinance) to return all used batteries/rechargeable batteries. -
Page 30: Technical Data
26. Technical Data a) Transmitter Frequency range ........2.4 GHz Transmission output ......<20 dBm (<100 mW) Channel number ........10 Encoding ..........AFHDS / AFHDS 2A (Automatic Frequency Hopping Digital System) Signal output .........PS 2 socket (PPM) Operating voltage .........6 V/DC via 4 type AA/mignon batteries Dimensions (W x H x D) .......174 x 187 x 80 mm Weight without batteries .......approx. - Page 32 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
