Summary of Contents for Reely HT-5
- Page 1 Operating instructions Remote Control "HT-5", 2.4 GHz Item No. 1414497 Version 04/16...
-
Page 2: Table Of Contents
Table of Contents Page Introduction ................................3 Explanation of Symbols ............................3 Intended Use ...............................4 Product Description .............................4 Scope of Delivery ..............................5 Safety Notes ................................5 a) General Information ............................5 b) Operation ...............................6 Battery and Rechargeable Battery Notes ......................7 Charging the Rechargeable Batteries ........................7 Operating Elements of the Transmitter ........................8 10. -
Page 3: Introduction
Introduction Dear Customer, Thank you for purchasing this product. This product complies with the statutory national and European requirements. To maintain this status and to ensure safe operation, you as the user must observe these operating instructions! These operating instructions are part of this product. They contain important notes on commissioning and handling. -
Page 4: Intended Use
Intended Use The 5-channel remote control "HT-5" is solely designed for private use in the field of model construction and the oper- ating times associated with it. This system is not suitable for industrial use, such as controlling machines or equipment. -
Page 5: Scope Of Delivery
Scope of Delivery • Remote control transmitter • Remote control receiver • Binding plug • Operating instructions on CD Current operating instructions: 1. Open www.conrad.com/downloads in a browser or scan the QR-code shown on the right. 2. Select the document type and language, and then enter the corresponding order number in the search field. -
Page 6: B) Operation
• Please check the functional safety of your model and of the remote control system each time before you use the model. Watch out for any visible damage such as defective plug connections or damaged cables. All movable parts on the model have to be running smoothly. However, there must be no tolerance or 'play' in the bearing. •... -
Page 7: Battery And Rechargeable Battery Notes
Battery and Rechargeable Battery Notes • Keep batteries/rechargeable batteries out of the reach of children. • Do not leave any batteries/rechargeable batteries lying around openly. There is a risk of batteries being swallowed by children or pets. If swallowed, consult a doctor immediately! •... -
Page 8: Operating Elements Of The Transmitter
Operating Elements of the Transmitter Figure 1 1 Transmitter aerial 10 Delta mixer switch 2 Carrying handle 11 Binding button 3 Trim button for elevator function 12 Trim button for rudder function 4 Toggle switch for channel 5 13 Control lever for rudder and motor function 5 Control lever for elevator and aileron function 14 Trim button for motor function 6 Trim button for aileron function... -
Page 9: Setting Up The Transmitter
Setting up the Transmitter In the further course of these instructions, figures in the text always refer to the adjacent figure or the figures within the section. References to other figures are indicated with the corresponding figure number. a) Inserting the Batteries For the power supply of the transmitter you will need 4 alkaline batteries (e.g. -
Page 10: C) Setting The Control Lever Length
c) Setting the Control Lever Length You can adjust the length of the control levers, depending on your steering habits. To do so simply hold the bottom part of the grip (1) and turn the upper part (2) up anti-clockwise. You can now set the length of the control lever by turning the bottom part of the grip. -
Page 11: Setting Up The Receiver
Setting up the Receiver a) Receiver Connection The receiver offers the possibility of connecting 5 servos (receiver output "CH1", "CH2", "CH3", "CH4" and "CH5") that are later assigned the following control functions in the model: "CH1" = Aileron/roll servo "CH2" = Elevator/nod servo "CH3"... -
Page 12: B) Installing The Receiver
b) Installing the Receiver Installation of the receiver depends on the model. For this reason, you should always follow the recommendations of the model manufacturer regarding the installation. Regardless of the model, you should always try to install the receiver so that it is protected from dust, dirt, moisture, heat and vibration in the best possible way and is not located in the direct proximity of the rechargeable battery/motor lines. -
Page 13: Installing The Servos
Installing the Servos The installation of a servo (1) always depends on the particular model used. Detailed information on this can be found in the construction documents of the model. Generally, however, try screwing in the servos in a vibra- tion-dampened manner. -
Page 14: Setting The Trim
Then the linkage or rudder rods must be adjusted so that the trim has its original value (90°-range between servo lever and rods) again and the model still runs straight. The remote control "HT-5" has a finely tuned digital trim- ming with which the first four control channels can be indi- vidually set with a trimming button (also see figure 1, items 3, 6, 12 and 14). -
Page 15: Checking The Servo Directions Of Travel
Checking the Servo Directions of Travel a) Checking the Control Lever Functions For figure 10 for this section, see the next page. Connect the servos inserted in the model to the receiver. Pay attention to the assignment of the receiver outputs as described above. - Page 16 Figure 10...
-
Page 17: B) Checking The Switching Channel Function
b) Checking the Switching Channel Function The additional switching channel "CH 5" is controlled with the toggle switch (also see figure 1, item 4). If, e.g., a servo to control landing/spoiler flaps, retractable landing gear or other special functions is connected at the receiver output "CH 5", the servo lever is in the middle position when the toggle switch at the transmitter is in the middle position ) as well. -
Page 18: Switching The Servo Directions Of Travel
Switching the Servo Directions of Travel If the rudder movements are not according to figure 10, you can switch the running direction of the servos at the receiver outputs "CH1" to "CH 4" at the reverse switches (also see figure 1, item 9). The switches at the transmitter are assigned as follows: "AIL"... -
Page 19: Changing The Control Lever Allocation
Changing the Control Lever Allocation If you want to control your flight model according to the chart shown in figure 10 (mode II), you can skip this section. If you prefer the throttle function on the right control lever and the elevator function on the left one (mode I), you may convert the transmitter accordingly. -
Page 20: Delta Mixer
For figure 14 for this section, see the next page. The remote control "HT-5" has a delta mixer that can be activated with the mixer switch (also see figure 1, item 10). When the slider is in the bottom position, regular operation without mixer function is active. When the slider is put up, the delta mixer is activated. - Page 21 Figure 14...
-
Page 22: Servo Path Limitation
Servo Path Limitation Use the servo path limitation or the dual rate function to reduce the servo deflections of channels 1, 2 and 4 from 100% to 60%. You can use this function to simply and easily reduce the reaction sensitivity of a model which reacts too aggressively at full extension. -
Page 23: Switching The Digital Code
"AFHDS 2A" encoded receiver. If you want to operate a Reely-receiver with the digital code "AFHDS", the transmitter must be switched first and then the receiver must be newly bound to the transmitter (see following chapter). -
Page 24: Binding Function
Binding Function To enable transmitter and receiver to work together, they must be bound by the same digital code. In the delivery state, transmitter and receiver are aligned with each other and can be used at once. The binding settings must be renewed mainly after a replacement of the transmitter or receiver or to remove any interferences. -
Page 25: Simulator Function, Student Transmitter Function
Alternatively, the signal output of the remote control may be used to control a teacher transmitter. In this case, the remote control "HT-5" acts as the student transmitter. Further information on this can be found in the operating Figure 18 instructions of the teacher transmitter. -
Page 26: Disposal
Disposal a) General Information Electronic devices are recyclable and should not be disposed of in household waste. At the end of its service life, dispose of the product according to the relevant statutory regulations. Remove any inserted batteries/rechargeable batteries and dispose of them separately from the product. b) Batteries and Rechargeable Batteries You as the end user are required by law (Battery Ordinance) to return all used batteries/rechargeable batteries. -
Page 27: Troubleshooting
Troubleshooting Even though the remote control system was built to the state of the art, there can still be interference or faults. For this reason, we would like to give you some information on how to deal with possible problems. Problem Remedy Transmitter doesn’t respond... -
Page 28: Technical Data
Technical Data a) Transmitter Frequency range ........2.4 GHz Channel number ........5 Encoding ..........AFHDS / AFHDS2A (Automatic Frequency Hopping Digital System) Signal output .........PS2 socket (PPM) Operating voltage .........6 V/DC via 4 type AA/mignon batteries Dimensions (W x H x D) .......174 x 187 x 80 mm Weight without batteries .......approx. - Page 32 Legal Notice This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
