INSTALLATION INSTRUCTIONS
N I G H TC R A W L E R S H E A D L I G H T A N D A C C E N T L I G H T K I T F O R J E E P
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings,
cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT
IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT
IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY
NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR DAMAGE THE PRODUCT ITSELF OR
THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
2 7" Headlights
2 Headlight Adapters
6 PRISM+ 8" Flex-Strip Light
1 PRISM+ Bluetooth Automotive Controller
1 PRISM+ Remote
YOU WILL ALSO NEED:
Torx screwdriver set, Phillips screw driver, wire stripper, electrical tape, masking tape, dremel or file
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES
THIS COPY AND IS AWARE OF ITS IMPORTANCE FOR FUTURE USE.
MODIFICATIONS MAY NEED TO BE MADE
NIGHTCRAWLER HEADLIGHT TO PROPERLY SIT IN THE OEM BRACKET BUCKET YOU MAY NEED TO FILE AWAY A
FEW SMALL SECTIONS FROM THE BUCKET. REFER TO STEP 19 ON PAGE 5, AND PIC 17-20 FOR A CLOSER LOOK AT
THE MODIFICATIONS THAT NEED TO HAPPEN BEFORE STARTING THE INSTALLATION PROCESS.
CONTROLLER
REFER TO THE LAST PAGE OF THE INSTALLATION INSTRUCTIONS FOR L.E.D. COUNTS FOR EACH VARIATION OF
PRISM+ LIGHTS. BLUETOOTH CONTROLLERS HAVE A MAX CAPACITY OF 250 L.E.D.S CONNECTED TO IT AT A TIME.
MAX CAPACITY PER CHANNEL IS 100 L.E.D.S, BUT THE CONTROLLER SHOULD NEVER EXCEED A TOTAL OF 250
L.E.D.S CONNECTED TO IT.
STEP 1
Read and understand all steps in the instructions before
starting the installation. Park the vehicle on a hard, level
surface and turn off the ignition. Let your vehicle cool.
PAGE 1
302480
DPF-MRK-003 REV A 7/23/20
7" HEADLIGHTS
BLUETOOTH
10 48" Extension Cords
4 Loop Connectors
24 6" Cable Ties
10 Cable Tie Mount
TO YOUR OEM HEADLIGHT BRACKET BUCKET. FOR THE
HEADLIGHT ADAPTERS
8" FLEX STRIP LIGHT
REMOTE
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
2480
PIC 1
48" EXTENSION CORDS
LOOP CONNECTORS
