Kuryakyn 9411 Installation Instructions Manual

P R O S E R I E S h Y P E R C h A R G E R
fITS: ALL '02-UP VTX1800 MODELS
PARTS INCLUDED
1 Pro Hypercharger Assembly
1 Throttle Body Adapter
1 Hardware Kit
3 1/4-20 x 1/2" Socket Head Cap Screws (SHCS)
4 M5 x .80 x 16MM Hex Flange Screws
2 10-24 x .40 Button Socket Cap Screws (BSCS)
1 14" Long 5/32" Rubber Hose
1 Gasket with Adhesive
1 1/8" Chrome EFI Nipple
1 90 Degree Elbow
1 Vinyl Cap
1 1" Clevis
1 Installation Instructions
Please read and understand entire instructions before starting installation.
ThANk YOU fOR ChOOSING küRYAkYN!
IN ORDER TO PROTECT YOU AND OThERS fROM POSSIBLE INjURY
AND/OR PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION
TO ALL INSTRUCTIONS, WARNINGS, CAUTIONS AND ATTENTION NOTES
REGARDING ThE USE AND CARE Of ThIS PRODUCT.
WARNING! THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE
CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
CAUTION! This indication alerts you to the fact that ignoring the contents described herein
can result in potential injury or material damage.
ATTENTION! This indication alerts you to the fact that ignoring the contents described herein
may negatively affect product performance and functionality.
TOOLS SUGGESTED
Set of Hex Wrenches, Combination Wrenches, Socket Set and Ratchet
STRICTLY OBSERVE ThE fOLLOWING GUIDELINES IN ORDER TO USE ThE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
PROCEDURE
STEP 1 Read and understand all steps in the instructions before starting the installation. Park
the motorcycle on a hard, level surface; turn off the ignition and allow the engine to cool.
NOTE
Some of our high performance air cleaners extend beyond the stock/OEM unit
to achieve smoother airflow and better performance. Riding position may be
affected.
NOTE
The addition of this air cleaner may change the fuel requirements of the engine.
For best drivability and performance.
STEP 2 Remove the seat and the rear mounting bolt of the fuel tank.
9411-15MC-0110
I N S TA L L AT I O N
9 4 1 1
INSTALLATION QUESTIONS
Küryakyn warrants that any Küryakyn products sold
hereunder, shall be free of defects in materials and
workmanship for a period of one (1) year from the
date of purchase by the consumer excepting the
• Küryakyn shall have no obligation in the event
the customer is unable to provide a receipt showing
the date the customer purchased the product(s).
maintained and operated under normal conditions.
• Küryakyn makes no warranty, expressed or
implied, with respect to any gold plated products.
• Küryakyn shall not be liable for any consequential
and incidental damages, including labor and
paint, resulting from failure of a Küryakyn product,
failure to deliver, delay in delivery, delivery in
nonconforming condition, or for any breech of con-
tract or duty between Küryakyn and a customer.
• Küryakyn products are often intended for use
in specific applications. Küryakyn makes no
• Küryakyn electrical products are warranted for
one (1) year from the date of purchase by the con-
sumer. Components of Küryakyn products containing
L.E.D.s will be warranted for defects in materials and
workmanship for 3 years from the date of purchase.
• Küryakyn makes no warranty of any kind in
regard to other manufacturer's products distributed
by Küryakyn. Küryakyn will pass on all warranties
made by the manufacturer and where possible, will
expedite the claim on behalf of the customer,
but ultimately, responsibility for disposition of the
You'll find all our innovations for H-D, GL and
Metric Cruisers in our annual catalogs. Order
online today–select the "CATALOGS" icon. Each
Küryakyn
Be sure to ask your local dealer about other
Küryakyn
©2005 Küryakyn USA
-cont.-
CUSTOMER SERVICE
877.370.3604 (toll free)
techsupport@kuryakyn.com
or call 715.247.2983
LIMITED WARRANTY
following provisions:
• The product must be properly installed,
warranty if a Küryakyn product is used in
applications other than intended.
warranty claim lies with the manufacturer.
ABOUT OUR CATALOG
product comes with a Proof-of-Purchase
®
good for a complimentary catalog.
Details in packaging.
® products, the motorcycle parts and
accessories designed for riders by riders.
® All Rights reserved.
