MA-UMNT-MR-A3 Aruba Mounting Adapter Installation Guide
Overview
The MA-UMNT-MR-A3 is a universal mounting adapter designed to simplify the transition from Aruba to Cisco Meraki access points. This adapter works with
MR33, MR42/42E, MR52, MR53/53E, MR45/55, MR36/46/46E/56 indoor access points. MA-UMNT-MR-A3 can be attached directly to the Aruba mount without
the need to remove this mount from its current mounting location. Supported Aruba mounts: JW046A, JW047A, AP-200-MNT-W2, AP-220-MNT-W2,
AP-220-MNT-W2W.
Note: The MA-UMNT-MR-A3 does not work with any of the outdoor MR access points.
Note: The MA-UMNT-MR-A3 cannot mount Meraki access points by itself and must be paired with one of the listed Aruba mounts.
Package Contents
MA-UMNT-MR-A3 standard package includes the following equipment:
•
1x MA-UMNT-MR-A3
•
1x PH#2 M4XP0.6X14L security screw
•
2x PH 19mm long screws, M3.5 threads
•
1x TORX M4XP0.6X14L security screw
1
Advertisement
Related Manuals for Cisco MA-UMNT-MR-A3
Summary of Contents for Cisco MA-UMNT-MR-A3
- Page 1 Overview The MA-UMNT-MR-A3 is a universal mounting adapter designed to simplify the transition from Aruba to Cisco Meraki access points. This adapter works with MR33, MR42/42E, MR52, MR53/53E, MR45/55, MR36/46/46E/56 indoor access points. MA-UMNT-MR-A3 can be attached directly to the Aruba mount without the need to remove this mount from its current mounting location.
- Page 2 You will need the following tools to perform an installation: 1x Phillips head screwdriver 1x TORX screwdriver Installation Instructions Remove the current Aruba access point from the Aruba mount and ensure that the security lock on MA-UMNT-MR-A3 is not engaged.
- Page 3 If AP-200-MNT-W2 / AP-220-MNT-W2 / AP-220-MNT-W2W Aruba mounts are used, align the pins on the rear panel of the MA-UMNT-MR-A3 with the slots on the Aruba mount plate. Press the button on the bottom on the Aruba mount in and slide the MA-UMNT-MR-A3 into the Aruba mount until the pins are fully engaged.
- Page 4 Attach your Meraki access point to the Meraki mount cradle by lining up the top edge of the AP with the top tab of the mount cradle. Since the cradle is already mounted to MA-UMNT-MR-A3 universal mount, guide the AP towards the top tab and insert the top tab into the AP slot.
