1.3 Cylinder description

The hydraulic cylinders for inboard engine UC 69-I, UC 116-I, UC 168-I, UC 215-I and UC 293-I models have
been designed and manufactured to be used as a component in the hydraulic steering systems, as described
in the previous paragraph.
The cylinder with mobile rod is installed directly to the arm of the helm through the proper ball joint on the
end part of the cylinder. On the opposite side it is fixed directly to the boat through a support with plate (see
par. 3.2). For the dual helm application, the single cylinder must be mounted with a tie bar. The following
picture shows the main cylinder components:
1
Cylinder body
2
Hose and purge connections
3 Ball joint
4
Support with mounting bracket
5
Rod

1.4 Technical features

C
SPECIFICATIONS
A
644 mm [25.33"]
B 494 mm [19.43"]
C (stroke)
D
E
Volume 69 cc - 4.2 cu. in
3233 N - 330 kg -
Maximum thrust*
727 lbs @70 bar
Bore
Oil
WARNING
*The cylinder thrust indicated is theoretical calculated with a system pressure as shown in the table. This
thrust does not correspond to the one generally used by the system but it represents the limit condition of use.
page 8
of 23 -
HYDRAULIC CYLINDERS FOR INBOARD ENGINES
UC 69-I UC 116-I
741 mm [22.17"]
563 mm [29.17"]
150 mm [5.9"] 178 mm [7"]
40 mm [1.57"] 40 mm [1.57"]
73 mm [2.87"] 73 mm [2.87"]
116 cc - 7 cu. in
6828 N - 696 kg -
1534 lbs @ 105 bar
25 mm [0.98"] 32 mm [1.25"]
OIL15 OIL15
5
3
2
A
B
UC 168-I
792 mm [31.18"]
614 mm [24.17"]
178 mm [7"]
40 mm [1.57"]
105 mm [4.13"]
168 cc - 10.25 cu. in 215 cc - 13.12 cu. in
9895 N - 1009 kg -
2224 lbs @ 105 bar
40 mm [1.57"]
OIL15
Installation and Maintenance Manual
1
D
UC 215-I
941 mm [37.05"]
713 mm [28.07"]
228 mm [8.98"]
40 mm [1.57"]
105 mm [4.13"]
9895 N - 1009 kg - 17317 N - 1765 kg -
2224 lbs @ 105 bar
40 mm [1.57"]
OIL15
4
UC 293-I
794 mm [31.26"]
616 mm [24.25"]
178 mm 7"]
40 mm [1.57"]
125 mm [4.92"]
293 cc - 17.8 cu. in
3892 lbs @ 105 bar
50 mm [1.97"]
OIL15
