2.2. EVB Kit Accessories

USB
Cable
L26-LB_EVB_User_Guide
FORCE_ON button
POWER switch
Micro USB connector
Indication LEDs
Antenna connector
L26-LB module
STANDBY switch
Test points
EVB
Bolts and
Coupling Nuts
Figure 2: L26-LB EVB Kit Accessories
Antenna
USB Flash
Drive
GNSS Module Series
L26-LB EVB User Guide
