See Water WD3P-4-302 Series Installation And Operation Manual

SEE WATER, INC.
WS Series® Duplex Control Panel
The WS Series® Duplex control panels will control two pumps in sewage,
wastewater, and dewatering applications. All panels are UL Listed for the
United States and Canada and come with a five-year warranty.
Model
WD3P-4-3021
WD3P-4-3022
WD3P-4-3023
WD3P-4-3024
WD3P-4-3025
WD3P-4-3026
WD3P-4-3027
WD3P-4-3028
WD3P-4-3029
WD3P-4-3030
WD3P-4-3031
WD3P-4-3032
WD3P-4-3033
WD3P-4-3034
Enclosure Mounting: NEMA 4X RATED
Mounting Brackets - A mounting bracket and screw pack are provided
with the premium enclosures. To assemble, turn the enclosure upside down
on a flat surface, place the mounting bracket over the square boss either
horizontally or vertically, and fasten the mounting bracket with the 1/4"-20
x 0.5 SS, countersunk phillips drive screws or vertically, with the mounting
brackets in any config., using any acceptable fastening technique.
Covers/Doors - Covers/doors have a gasket pre-assembled to seal
against the base.
Note: The control panel should not be mounted in a location that may be
subject to submersion.
FLA Range
(1.0-1.6 FLA)
(1.6-2.5 FLA)
(2.5-4.0 FLA)
(4.0-6.3 FLA)
(6.0-10.0 FLA)
(9.0-14.0 FLA)
(13.0-18.0 FLA)
(17.0-23.0 FLA)
(20.0-25.0 FLA)
(24.0-32.0 FLA)
(30.0-40.0 FLA)
(37.0-50.0 FLA)
(48.0-65.0 FLA)
(65.0-115.0 FLA)
Page 1-3
Three Phase Duplex Control Panel
Installation and Operation manual
WD3P-4-302X
Panel Installation:
1. Caution: To maintain the NEMA 4X rating, make
all wiring connections with seal tight cable grips or
conduit connections.
2. Run pump cables and floats cables through
conduit. Make field connections as shown on wiring
schematic.
3. Run power line conductor through conduit. Wire to
terminals per enclosed schematic.
4. Branch circuit protection to be provided by
installer.
5. Panel circuit breakers are closed
6. Floats are properly mounted at the correct levels
Note: Floats shall have free range of motion
without touching each other or other equipment
7. Connect service conductors 208/240/480V to
proper location
www.seewaterinc.com
951.487.8073 • 888.733.9283 • info@seewaterinc.com
22220 Opportunity Way, Suite 101 • Riverside, CA 92518
IM 751 REV. 01/20
