SEE WATER, INC.
Oil Smart® Duplex System
The Oil Smart® OSD3P system incorporates pump controls and alarm
sensors that differentiate between oil and water, allowing companies to
responsibly discharge the water without the risk of pumping oil. Installation
of the OSD3P keeps companies in compliance with Elevator Code
ASME A17.1 and State/Federal regulations while reducing the risk of adverse
publicity, fines, and expensive cleanup cost.
Model
OSD3P-3021
OSD3P-3022
OSD3P-3023
OSD3P-3024
OSD3P-3025
OSD3P-3026
OSD3P-3027
OSD3P-3028
OSD3P-3029
OSD3P-3030
OSD3P-3031
OSD3P-3032
OSD3P-3033
Enclosure Mounting: NEMA 4X RATED
Mounting Brackets - A mounting bracket and screw pack are provided
with the premium enclosures. To assemble, turn the enclosure upside down
on a flat surface, place the mounting bracket over the square boss either
horizontally or vertically, and fasten the mounting bracket with the 1/4"-20
x 0.5 SS, countersunk phillips drive screws or vertically, with the mounting
brackets in any config., using any acceptable fastening technique.
Covers/Doors - Covers/doors have a gasket pre-assembled to seal against
the base.
Note: The control panel should not be mounted in a location that may be
subject to submersion.
FLA Range
(1.0-1.6 FLA)
(1.6-2.5 FLA)
(2.5-4.0 FLA)
(4.0-6.3 FLA)
(6.0-10.0 FLA)
(9.0-14.0 FLA)
(13.0-18.0 FLA)
(17.0-23.0 FLA)
(20.0-25.0 FLA)
(24.0-32.0 FLA)
(30.0-40.0 FLA)
(37.0-50.0 FLA)
(48.0-65.0 FLA)
Page 1-3
Three Phase Duplex Control Panel
Installation and Operation Manual
OSD3P-30XX
Panel Installation:
1. Caution: To maintain the NEMA 4X rating, make
all wiring connections with seal tight cable grips or
conduit connections.
2. Run pump cable and Oil Smart® cables through
conduit. Make field connections as shown on wiring
schematic.
3. Run power line conductor through conduit. Wire to
terminals per enclosed schematic.
4. Branch circuit protection to be provided by
installer.
5. Panel circuit breakers are closed.
6. Mount Oil Smart® pump switch and Liquid Smart®
alarm sensor with provided mounting hardware to
pump discharge pipe. The 'OFF' sensor of the Oil
Smart® pump switch shall be positioned at least 3"
above the impeller of the pump.
7. Mounting of the High Water Lag Sensor is
application driven and is to be placed where high
demand pump is to be activated.
8. Mounting of the Liquid Smart® sensor is
application driven and is to be placed where a high
liquid is deemed necessary. The Liquid Smart®
sensor is typically mounted 3" - 6" above the Oil
Smart® pump switch.
9. Connect service conductors 208/240/480V to
proper location
Remote Monitoring Dry Contacts:
• Normally Open dry contacts for high oil, high level,
pump run, and pump fault. Rated 0-60V AC/DC
www.seewaterinc.com
951.487.8073 • 888.733.9283 • info@seewaterinc.com
22220 Opportunity Way, Suite 101 • Riverside, CA 92518
IM 804 REV. 02/20
