See Water WS Series Installation And Operation Manual

SEE WATER, INC.
WS Series® Simplex Control Panel
The WS Series® Simplex control panels will control the pumps in sewage,
wastewater, and dewatering applications. All panels are UL Listed for the
United States and Canada and come with a five-year warranty.
Model
WS3P-TP-3001
WS3P-TP-3002
WS3P-TP-3003
WS3P-TP-3004
WS3P-TP-3005
WS3P-TP-3006
WS3P-TP-3007
WS3P-TP-3008
WS3P-TP-3009
WS3P-TP-3010
WS3P-TP-3011
WS3P-TP-3012
WS3P-TP-3013
WS3P-TP-3014
Enclosure Mounting: NEMA 4X RATED
Mounting Brackets - A mounting bracket and screw pack are provided
with the premium enclosures. To assemble, turn the enclosure upside down
on a flat surface, place the mounting bracket over the square boss either
horizontally or vertically, and fasten the mounting bracket with the 1/4"-20
x 0.5 SS, countersunk phillips drive screws or vertically, with the mounting
brackets in any config., using any acceptable fastening technique.
Covers/Doors - Covers/doors have a gasket pre-assembled to seal
against the base.
Note: The control panel should not be mounted in a location that may be
subject to submersion.
FLA Range
(1.0-1.6 FLA)
(1.6-2.5 FLA)
(2.5-4.0 FLA)
(4.0-6.3 FLA)
(6.0-10.0 FLA)
(9.0-14.0 FLA)
(13.0-18.0 FLA)
(17.0-23.0 FLA)
(20.0-25.0 FLA)
(24.0-32.0 FLA)
(30.0-40.0 FLA)
(37.0-50.0 FLA)
(48.0-65.0 FLA)
(65.0-115.0 FLA)
Page 1-3
Three Phase Simplex Control Panel
Installation and Operation Manual
WS3P-TP-300X

Panel Installation:

1. Caution: To maintain the NEMA 4X rating, make
all wiring connections with seal tight cable grips or
conduit connections.
2. Run pump cables and floats cables through
conduit. Make field connections as shown on wiring
schematic.
3. Run power line conductor through conduit. Wire to
terminals per enclosed schematic.
4. Branch circuit protection to be provided by
installer.
5. Panel circuit breakers are closed.
6. Floats are properly mounted at the correct levels.
Note: Floats shall have free range of motion
without touching each other or other equipment.
7. Connect service conductors 208/240/480V to
proper location.
www.seewaterinc.com
951.487.8073 • 888.733.9283 • info@seewaterinc.com
22220 Opportunity Way, Suite 101 • Riverside, CA 92518
IM 1008 REV. 01/20
