ENGLISH

Filter replacing

If the LED light on the front of the unit flashes orange then the Filter needs to be changed. The Filter last about
for 20,000 uses.
1. Cut off the power supply.
2. Remove the two security screws from the main body, using the service tool provided for security screws(fig. 2).
3. Pull down the front cover and lift the front cover off the main body (fig. 3).
4. Turn the filter cover to open direction (fig. 10).
The dot is aligned with the arrow present on the motor cover (fig. 11B).
10
5. Lift the Filter parts off the main body and take the filter out of the cover(fig. 12)
12A
ECODRY
11
12B
Filter Cover
Filter
CLOSE
(A)
ECODRY EC
Filter
OPEN
(B)
Filter Cover
23
