Vortice ECODRY Instruction Booklet page 22

ENGLISH
HEATER SWITCH ON/OFF (Fig 8). (factory default setting "ON")
To exclude the resistance in summer times, press the button shown in fig. 8A-8B, after removing the front cover
(repeat steps of figures 2-3)
8A
ECODRY
ATTACHING MAIN BODY
• Reposition the front cover on the backplate (fig. 9).
• Insert and tighten two security screws into the bottom of the front cover.
• Turn power on.
• Test unit for correct operation. The LED light on the product cover remains continuous and white.
9
22
8B
ECODRY EC
ECODRY
