Intelbras GF 1200 User Manual

Wi-fi router 5 (dual band ac 1200)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User guide
GF 1200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GF 1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Intelbras GF 1200

Summary of Contents for Intelbras GF 1200

  • Page 1 User guide GF 1200...
  • Page 2 Congratulations, you have just purchased a product with Intelbras quality and security. The GF 1200 router is designed for ISPs that want to deliver much higher performance Wi-Fi to their subscribers. With it you can share Internet access with multiple devices in a high-speed wireless network.
  • Page 3 Care and safety Adjust the position of the antennas. Usually, the vertical position is the most indicated. Prefer to install your router in the central part of the environ- ment and preferably in a higher location, for example on top of a furniture.

  • Page 4: Table Of Contents

    Summary 1. Technical specifications 2. Accessories 3. Installation 4. Configuration 4.1. Configuration via web interface ..............7 4.2.

  • Page 5: Technical Specifications

    Chipset Realtek® RTL8197F + RTL8211F + RTL8812BRH Flash Memory 8 MB RAM memory 64 MB OS Linux + Bifrost Intelbras Button Reset/WPS (Attention: this button does not have the function WPS enabled) Compatible with the Remotize platform ( https://remotize.intelbras.com.br ) Wireless parameters IEEE standards 802.11a/b/g/n/ac...

  • Page 6: Accessories

    Description of LEDs On: power-connected router Power Off: power-disconnected router On: router with internet access Internet Flashing: Internet port connected, but no Internet access Off: no network cable connected to the Internet port On: there is(are) device(s) are connected on LAN ports Flashing: there is(are) device(s) traveling data on LAN ports Off: no device connected to the LAN ports On: Wi-Fi on, no devices trafficking data...

  • Page 7: Installation

    3. Connect the computer to one of the LAN ports on the router using a network cable; Note: if you wish to access your router via Wi-Fi, access the wireless network named INTELBRAS or INTELBRAS_5G. If you wish to perform this configuration using a smartphone, disable the mobile data network before proceeding with the router settings.

  • Page 8: Dashboard

    Your router’s login page will open. As factory default, the user is admin and the password is admin . Enter these creden- tials in the corresponding fields and click on Enter. Login page Note: if access is not possible with these credentials: 1.

  • Page 9: Network Settings

    Internet (WAN) On the car titled Internet (WAN) , you can view the following Internet settings obtained: mode of operation, IP address, subnet mask, gateway, WAN MAC address, DNS1, DNS2 and DNS3. Local Area Network (LAN) On the card titled Local Area Network (LAN) , you can view the following LAN settings obtained: IP address, subnet mask, and LAN MAC address.
  • Page 10 Wi-Fi settings editing screen Wi-Fi network name and password By default, the 2.4 GHz and 5 GHz networks will be named INTELBRAS and INTELBRAS_5G , respectively. You can change the name and password of each separately by clicking on the icon and then on Edit to access the edit screen, as shown in the following image.
  • Page 11 » Network password: if you disable the previous option (Leave network open), you can set the password you want for your Wi-Fi network. This is the password you will use when connecting your wireless devices to the network (smart- phones, notebooks, tablets etc). The encryption used will be WPA/WPA2-PSK . Note: the fields Wi-Fi Network Name and Wi-Fi Network Password allow the following characters: “...
  • Page 12 Radio You can change the radio settings of each frequency separately by clicking on Radio settings and accessing the edit screen as shown below. 2.4 GHz and 5 GHz radio settings » Enabled: if activated (figure above), the radio of a certain frequency will be on and can provide Wi-Fi connection. If it is deactivated, the radio of a certain frequency will be turned off and will not be able to provide Wi-Fi connection.
  • Page 13 » 20 MHz: In this option, all wireless devices will be forced to connect to the router using the 20 MHz band. » For Wi-Fi 5 GHz network » 20/40/80 MHz: in this option, the router will make available the 20 MHz option, the 40 MHz option and the 80 MHz option for wireless devices to connect.
  • Page 14 » PPPoE: use this mode if your Internet access requires authentication via PPPoE. If selected, you will need at least one user and password (provided by your operator or internet provider) to authenticate with the Internet. It may be necessary to fill in the other fields. PPPoE mode Internet settings edit screen »...

  • Page 15: System Settings

    You can change the local area network (LAN) settings via the LAN tab, available from the Network menu (figure below). LAN settings editing screen » IP Address: is the IP address to access the router’s web interface (10.0.0.1 by default). When changing this information, you should use the new address you have chosen to access the router interface or perform access using the address http://meuintelbras.local .
  • Page 16 » Update: in this tab, in addition to viewing the current firmware version of the product, you can update your router manually by selecting a firmware file using the Select File button and then clicking Update . The figure below shows this tab with details.
  • Page 17 » Restore: in this tab, you can perform two actions (as shown below): 1. Change the time the Reset button should be pressed to restore your router settings to factory default. To do this, change the value of the pressed Time field (seconds) to the desired one and click on the Save button. 2.

  • Page 18: Frequently Asked Questions

    » Enable WAN ping: by enabling this function (image below), you can ping your router’s WAN and get a response. If you disable the function, the WAN ping will not get a response. WAN ping configuration screen 5. Frequently Asked Questions Problem Solution You can try the following options:...

  • Page 19: Warranty Term

    7. Intelbras is not responsible for the installation of this product and also for any attempts of fraud and/or sabotage on its products. Keep software and application updates, if any, up to date, as well as network protections necessary to protect against hackers.
  • Page 20 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Imported in Brazil by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia SC 281, km 4,5 – Sertão do Maruim – São José/SC – 88122-001 01.20 CNPJ 82.901.000/0014-41 –...
