- Page 1 ® I N STA LL ATION & USER GUIDE...
-
Page 2: Kit Components
KIT COMPONENTS Unbox and verify all components are present. 1 qty - Axis Cover SPECIFICATIONS 1. Cover skirt is approximately 12½" (measured down from the top of the swim spa shell). 2. Bottom of Rotating Lever Latch is approximately 17" at... -
Page 3: Installation
Grabbing and pulling on other components/parts of the cover to shift or maneuver the cover will result in unwarranted damage. Cover skirting has been flipped up to expose the layers of material for illustrative purposes. WATCH THE VIDEO: MasterSpas.com/axis... - Page 4 INSTALLATION LEVER CHANNEL Install Lever Channels (b) to both 8' ends of the swim spa skirting (Figure 2). Center Lever Channel on the swim spa skirting against the swim spa shell flange with “L” side up (Figure 3). Use 5 of the #8x½"...
- Page 5 Rotating Level Latch Base. The slot is present to allow downward adjustment of the base if necessary later. (Continued...) Repeat for opposite end. Top Center Screw Point Using Side Screw Points Using FIGURE 4 WATCH THE VIDEO: MasterSpas.com/axis...
- Page 6 INSTALLATION Next, push the top half of the Rotating Lever Latch (c) on to its base (d) mounted to the swim spa skirting with the lever end facing a 3 o’clock position (Figure 5). Insert the plastic pinned washer (e) into the center pivot shaft of the Rotating Lever Latch with pins aligned to the grooves in the shaft.
- Page 7 Install 1 Axis Cover Dome Label (i) into recessed, oval area on the Rotating Lever Latch (c) (Figure 6). Repeat for the opposite end. FIGURE 6 SECURING THE COVER Insert cover lever arm into the Lever Channel installed on the swim spa skirt (Figure 7 below and Figure 18 on page 13 provide illustrations for securing the cover).
- Page 8 Using provided #4x¾" Phillips Flat Head Screws (j), mount the cover locks located along the long sides of the Axis Cover to the swim spa skirting (Figure 8). These cover locks MUST be attached and secured when swim spa is not in use. Refer to cover lock system overview (Figure 9).
- Page 9 Cover locks measure FIGURE 9 approximately 7½" (from the top of the swim spa shell down). WATCH THE VIDEO: MasterSpas.com/axis...
-
Page 10: Opening The Cover
OPENING THE COVER ATTENTION: Be sure to remove any foreign objects such as small sticks, branches, or other debris from the top of cover before rolling it open. This prevents damage from occurring and debris from getting into the swim spa when it is rolled closed again. Tears or puncture damage caused to the cover by foreign objects are not covered by the limited warranty. - Page 11 FIGURE 11 FIGURE 12 FIGURE 13 Fully rolled diameter is approximately 28" (based on 19' swim spa model). FIGURE 15 WATCH THE VIDEO: MasterSpas.com/axis...
-
Page 12: Closing The Cover
CLOSING THE COVER Standing at the 8' end where the rolled cover is located, push the rolled cover across the surface of the swim spa, unrolling until out of reach. On the 8’ end where the rolled cover was located, place the cover lever arm edge (Figures 16 &... - Page 13 Simplified Side View Axis Cover Lever Channel FIGURE 18 Next, place cover lever arm edge into the Lever Channel mounted to swim spa skirt (Figure 18). Push down on cover lever arm and turn Rotating Lever Latch to secure (Figure 19).
-
Page 14: Cover Care
Covers must be fully removed from the usable areas of the swim spa during operation. Your local Master Spas dealer can be contacted for more information regarding information and purchase of a cover shelf accessory. - Page 15 It is important to review spacing and mounting of the cover shelf components before installation of the Axis Cover and cover shelf. Damage caused due to the cover being rolled off or falling off the end of the swim spa is not covered under warranty.
- Page 16 COVER CARE CLEANING The cover should be cleaned with mild soap and fresh water at least semi-monthly. Do not use abrasive soaps, petroleum based cleaners or silicon based treatments on the vinyl. Failure to properly take care of the cover may cause the vinyl to become brittle, seams to split and create uneven discoloration due to environmental factors such as dirt, bird droppings, leaves, tree sap, etc.
- Page 17 This warning label is also found on the cover and should be inspected periodically for premature wear or deterioration which affects its legibility. If the warning label on the cover is becoming illegible, Master Spas should be contacted to help provide a replacement label to be placed over the original ink screened warning.
-
Page 18: Limited Warranty
AXIS COVER SYST E M ® LIMITED WARRANTY Master Spas warrants the Axis Cover System (“Cover”) manufactured by Master Spas against defects in workmanship and/or material to the original retail purchaser from the date of original retail purchase. The Axis Cover System (vinyl cover skin, insulating... - Page 19 Master Spas’ Customer Service Department, at customerservice@masterspas.com or provide written notice of the defect to Master Spas, 6927 Lincoln Parkway, Fort Wayne, IN 46804. Within a reasonable time of receipt of the notice of the warranty claim, valid proof of purchase and detailed photos of the alleged claim; Master...
- Page 20 6927 Lincoln Parkway, Fort Wayne, IN 46804 800.860.7727 customerservice@masterspas.com MasterSpas.com The manufacturer reserves the right to change specifications or features without notice. As a manufacturer of spas and related products we stand behind every product we produce pursuant to those representations which are stated in our written limited warranty. Your dealer is an independent business person or company and not an employee or agent of the manufacturer.
