2
1
front view
5. Brightness sensor
6. Power supply plug
7. Audio video input
8. Serial port for external GPS receiver
9. Serial port for TMC receiver
10. Speaker
11. USB port

1.4 Keyboard

• SPEAK: repeats the last vocal instruction
and opens the volume control window
• MENU: opens the main menus available
• FIND: opens find window to search for
addresses, marks, POI
3
5
4
11
side view
• ESC: exits from the current menu and
switches into cursor mode or GPS mode
• JOYSTICK:
Upper arrow: moves the cursor up
Lower arrow: moves the cursor down
Right arrow: moves the cursor right
Left arrow: moves the cursor left
• ENT: confirm a choice or selection, opens
the function menu
• + zooms in the map
• - zooms out the map
• INFO: opens the full info window
• MODE: switches among the different
viewing options for map, instruction and
• PAGE: switches among the available pages:
10
• POWER: powers on and off the unit. Opens
9
8 7 6
trip computer pages
map, instructions and the trip computer
the brightness control window.
