Approximate time to complete installation is 1-1/2" hours for two people
Recommended tools required for installing the Crop Catcher:
-9/16" socket
-7/16" socket
-Hammer
-Center Punch
-Ratchet
-11/32" Drill Bit
Industries, Ltd.
P.O. Box 119
St. Gregor, Saskatchewan
S0K 3X0 Canada
Ph#(306)366-2184 or Fax#(306)366-2145
Patent Pending
-Extension
-3/8" Drill
Advertisement
Related Manuals for Michel's CROP CATCHER
Summary of Contents for Michel's CROP CATCHER
- Page 1 Patent Pending Approximate time to complete installation is 1-1/2” hours for two people Recommended tools required for installing the Crop Catcher: -9/16” socket -7/16” socket -Ratchet -Extension -Hammer -Center Punch -11/32” Drill Bit -3/8” Drill Industries, Ltd. P.O. Box 119 St.
- Page 2 Unpack and check that all of the parts are with your Crop Catcher: Note: If AGCO Mounting Brackets are required the kit will come in Black. Figure 1. STEP 1 Bolt the Upright Support Brackets to the Mounting Brackets using two 3/8” carriage bolts. The Upright Brackets are mounted on the flange side of the Mounting Bracket and the carriage head is also on the bent flange side.
- Page 3 Figure 5. STEP 5 Center the Crop Catcher on the combine header and Install the mounting brackets flush with the front of the header tubing. Mark the mounting locations with a center punch and drill an 11/32” hole for the 3/8”...
- Page 4 As seen in Figure 8. Figure 8. To Care for your new Crop Catcher use a plastic cleaner such as the optional “Dust Away” Plastic Cleaner supplied by Michel’s. Do not use Glass Cleaner. For assistance on your Crop Catcher, please contact Michel’s Industries Ltd.
