Summary of Contents for Briggs & Stratton 01813-1

  • Page 1 Call: Transfer Switch Helpline Llamada: Línea Directa de Interruptor de Transferencia Appelez: Ligne Directe de Commutateur de Transfert 1-800-743-4115 M-F 8-5 CT BRIGGSandSTRATTON.COM 100 Amp / 200 Amp Automatic Transfer Switch Models 01813-1, 01814-1, 01928-1 & 01929-1 Part No. 200931GS Rev. A (03/21/07)
  • Page 2: Table Of Contents

    SPECIFICATIONS ....... 11 Model 01813-1 ......11 Model 01814-1 .
  • Page 3: Important Safety Instructions

    Failure to properly ground transfer switch can result in electrocution. • DO NOT touch bare wires or receptacles. • DO NOT use transfer switch with worn, frayed, bare or otherwise damaged wiring. • DO NOT handle electrical cords while standing in water, while barefoot, or while hands or feet are wet.
  • Page 4: Introduction

    Installations must strictly comply with all applicable federal, state and local codes, standards and regulations. Your BSPP Transfer Switch is supplied with this combined “Installation and Operator’s Manual”.This is an important document and should be retained by the owner after the installation has been completed.
  • Page 5: Owner Orientation

    (generator).The transfer switch monitors utility and generator voltages and will automatically connect to the appropriate source of power. Major components of the transfer switch are a 2 pole disconnect circuit breaker (models 01928-1 & 01929-1 only), a 2 pole double throw transfer switch, control circuit board, fused utility terminals and interconnecting wiring.
  • Page 6: Installation

    Missing or damaged parts are not warranted. Shipment Contents • Automatic Power Transfer Switch • Installation and Operator’s Manual Figure 1 — A Typical Transfer Switch Mounting for Models 01813-1 & 01814-1 — — — — — — Control Wiring Water Heater Installation and Operator’s Manual...
  • Page 7 Briggs & Stratton Power Products Automatic Transfer Switch Figure 2 — A Typical Transfer Switch Mounting for Models 01928-1 & 01929-1 — — — — — — Control Wiring Water Heater Branch Circuits Figure 3 — An Alternate Transfer Switch Mounting —...
  • Page 8: Power Wiring Interconnections

    Installation and Operator’s Manual Supervisory Control Wiring Terminal strip on control module in transfer switch has four connections for customer use.There are two sets of “Normally Closed” contacts available.They will be opened when generator power is required.These can be used to lock out large loads when powered by generator.
  • Page 9 Briggs & Stratton Power Products Automatic Transfer Switch Figure 4 — A Typical Installation Diagram for Transfer Switch To Utility Power Utility Connection Generator Connection Ground Lug To Generator Installation and Operator’s Manual NOTE: Models 01928-1 and 01929-1 have a utility disconnect circuit breaker built into the transfer switch enclosure.
  • Page 10: System Operation

    Briggs & Stratton Power Products Automatic Transfer Switch SYSTEM OPERATION To select automatic transfer operation, do the following: 1A. For models 01813-1 & 01814-1, set service disconnect switch that sends utility power to transfer switch contactor to “On” position. B. For models 01928-1 & 01929-1, set service disconnect switch that sends utility power to transfer switch utility disconnect circuit breaker to “On”...
  • Page 11: Specifications

    Briggs & Stratton Power Products Automatic Transfer Switch SPECIFICATIONS UL® 1008 Listed Transfer Switch Model 01813-1 Maximum Load Current:..100 Amps Rated AC Voltage... . . 250 Volts Poles .
  • Page 12: Troubleshooting

    Briggs & Stratton Power Products Automatic Transfer Switch TROUBLESHOOTING Problem Automatic transfer switch does not transfer to generator Automatic transfer switch does not transfer to utility Generator is still running after switch transfers to utility power Supervised loads (air conditioner, etc.) are operating when...
  • Page 13: Notes

    Briggs & Stratton Power Products Automatic Transfer Switch Installation and Operator’s Manual NOTES...
  • Page 14 Briggs & Stratton Power Products Automatic Transfer Switch Installation and Operator’s Manual TRANSFER SWITCH SCHEMATIC...
  • Page 15 Briggs & Stratton Power Products Automatic Transfer Switch Installation and Operator’s Manual TRANSFER SWITCH WIRING DIAGRAM...
  • Page 16 Briggs & Stratton Power Products Automatic Transfer Switch TRANSFER SWITCH EXPLODED VIEW & PARTS LIST MODEL 01813-1 Item Part # Description ENCLOSURE, 16" x 12" x 6" BACK PANEL 195667GS TRANSFER SWITCH, 100A, with Cover & Handle PPHMS, #10 - 32 x 1/2"...
  • Page 17 Briggs & Stratton Power Products Automatic Transfer Switch TRANSFER SWITCH EXPLODED VIEW & PARTS LIST MODEL 01814-1 Item Part # Description ENCLOSURE, 22” x 16” x 7” BACK PANEL 195668GS TRANSFER SWITCH, 200A, with Cover & Handle PPHMS, #10 - 32 x 1/2"...
  • Page 18 Briggs & Stratton Power Products Automatic Transfer Switch TRANSFER SWITCH EXPLODED VIEW & PARTS LIST MODEL 01928-1 Item Part # Description ASSY, Enclosure BACK PANEL 195667GS TRANSFER SWITCH, 100A, with Handle PPHMS, #10 - 32 x 1/2" PPHMS, #6 - 32 x 1/4"...
  • Page 19 Briggs & Stratton Power Products Automatic Transfer Switch TRANSFER SWITCH EXPLODED VIEW & PARTS LIST MODEL 01929-1 Item Part # Description ASSY, Enclosure BACK PANEL 195668GS TRANSFER SWITCH, 200A, with Handle PPHMS, #10 - 32 x 1/2" PPHMS, #6 - 32 x 1/4"...
  • Page 20 Briggs & Stratton Power Products Automatic Transfer Switch Installation and Operator’s Manual NOTES...
  • Page 21: Warranty

    BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC TRANSFER SWITCH OWNER WARRANTY POLICY Effective November 1, 2005 replaces all undated Warranties and all Warranties dated before November 1, 2005 Briggs & Stratton Power Products Group, LLC will repair or replace, free of charge, any part(s) of the equipment that is defective in material or workmanship or both.Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.
  • Page 22 CARACTÉRISTIQUES ....... . . 31 Modèle 01813-1 ......31 Modèle 01814-1 .
  • Page 23: Directives De Sécurité Importantes

    Commutateur de transfert automatique Briggs & Stratton Power Products VEUILLEZ CONSERVER CES INSTRUCTIONS DIRECTIVES DE SÉCURITÉ IMPORTANTES Ceci est la sûreté le symbole vif. Il est utilisé pour vous alerter aux dangers de blessure personnels potentiels. Obéir tous messages de sûreté qui suivent ce symbole éviter la blessure ou la mort possibles.
  • Page 24: Introduction

    Commutateur de transfert automatique Briggs & Stratton Power Products INTRODUCTION Nous vous remercions d'avoir acheté ce commutateur de transfert automatique de Briggs & Stratton Power Products (BSPP). Ce commutateur de transfert convient UNIQUEMENT aux génératrices de secours résidentielles Briggs & Stratton. Ce produit est conçu pour être utilisé...
  • Page 25: Conseils Au Propriétaire

    Commutateur de transfert automatique Briggs & Stratton Power Products Conseils au Propriétaire Les illustrations se rapportent à des cas typiques et ont pour but de vous familiariser avec les différentes options d'installation de votre commutateur de transfert dont vous disposez. Au moment de négocier avec un installateur professionnel, il faudra tenir compte des facteurs suivants : les codes de sécurité...
  • Page 26: Installation

    Commutateur de Transfert Automatique • Manuel de d'Installation et l'Utilisateur Figure 6 — Une installation type du commutateur de transfert pour les modèles 01813-1 et 01814-1 — — — — — — Câblage de contrôle Chauffe- Guide d'installation et d'utilisation...
  • Page 27 Commutateur de transfert automatique Briggs & Stratton Power Products Figure 7 — Une installation type du commutateur de transfert pour les modèles 01928-1 et 01929-1 — — — — — — Câblage de contrôle Chauffe- Circuits de dérivation Figure 8 — Une installation alternative du commutateur de transfert —...
  • Page 28: Interconnexions Du Câblage D'alimentation

    Commutateur de transfert automatique Briggs & Stratton Power Products Interconnexions du Câblage d'Alimentation Tout le câblage doit être d'un gabarit approprié, bien fixé, et protégé par des conduits. Effectuez les raccords suivants entre le commutateur de transfert, le panneau de distribution principal, l'alimentation de service et la génératrice (Figure 9).
  • Page 29 Commutateur de transfert automatique Briggs & Stratton Power Products Guide d'installation et d'utilisation Figure 9 — Schéma d'Installation Typique du Commutateur de Transfert Vers l'Alimentation de Service REMARQUE: Les modèles 01928-1 et 01929-1 sont dotés d'utilité débranche le disjoncteur intégrés au boîtier du commutateur de transfert. Branchement de l'Électricité...
  • Page 30: Fonctionnement

    Commutateur de transfert automatique Briggs & Stratton Power Products FONCTIONNEMENT Pour actionner le transfert automatique, suivez la procédure décrite ci-dessous: 1A. Pour les modèles 01813-1 & 01814-1, réglez sur “On” l’interrupteur de débranchement de l’alimentation de service qui transmet l’alimentation de service à l’interrupteur de transfert.
  • Page 31: Modèle 01813-1

    Commutateur de transfert automatique Briggs & Stratton Power Products CARACTÉRISTIQUES UL® 1008 Enuméré Commutateur de Transfert Modéle 01813-1 Charge maximum/circuit: du point d'alimentation des charges ...100 Ampères Tension nominale C.A......250 Volts Pôles .
  • Page 32: Dépannage

    Commutateur de transfert automatique Briggs & Stratton Power Products DÉPANNAGE PROBLÈMES Le commutateur de transfert automatique ne transfère pas à la génératrice Le commutateur de transfert automatique ne transfère pas à l'alimentation de service La génératrice continue de fonctionner après que le commutateur eut transféré...
  • Page 33: Garantie

    GARANTIE DU PROPRIÉTAIRE DU COMMUTATEUR DE TRANSFERT BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC Prise d’effet au 1 er Novembre 2005, annule et remplace toutes les garanties précédentes et les garanties antérieures au 1 er Novembre 2005 Briggs & Stratton Power Products Group, LLC réparera ou remplacera, sans frais, toutes pièces d'équipement défectueuses comportant un vice de matériau ou un défaut de fabrication ou les deux.
  • Page 34 ESPECIFICACIONES ........34 Modelo 01813-1 ......34 Modelo 01814-1 .
  • Page 35: Instrucciones Importantes De Seguridad

    Conectador automático de Briggs & Stratton Power Products CONSERVE ESTAS INSTRUCCIONES INSTRUCCIONES IMPORTANTES DE SEGURIDAD Éste es el símbolo de alerta de seguridad. Sirve para advertir al usuario de un posible riesgo para su integridad física. Siga todos los mensajes de seguridad que figuren después de este símbolo para evitar lesiones o incluso la muerte.
  • Page 36: Introducción

    Conectador automático de Briggs & Stratton Power Products INTRODUCCIÓN Muchas gracias por comprar un conectador automático de Briggs & Stratton. Este producto está pensado para utilizarlo como un sistema de reserva doméstico opcional que proporciona una fuente alternativa de energía eléctrica con capacidad para alimentar cargas tales como sistemas de calefacción y refrigeración y sistemas de comunicaciones, que cuando dejan de funcionar a causa de una interrupción de la alimentación eléctrica...
  • Page 37: Orientación Para El Propietario

    Conectador automático de Briggs & Stratton Power Products Orientación para el Propietario Las ilustraciones se aplican a circunstancias típicas y están destinadas a que usted se familiarice con las opciones de instalación disponibles con su conmutador de transferencia. Los códigos locales, la apariencia y las distancias son los factores fundamentales a tener en cuenta cuando se realiza la negociación con el profesional que tendrá...
  • Page 38: Instalación

    • Conmutador de transferencia de energía automático • Manual de instalación y operario Figura 11 — Montaje Habitual de un Conectador para los Modelos 01813-1 y 01814-1 — — — — — — Cableado de control Calentador de agua Circuitos derivados Manual de Instalación y del Operario...
  • Page 39 Conectador automático de Briggs & Stratton Power Products Figura 12 — Montaje Habitual de un Conectador para los Modelos 01928-1 y 01929-1 — — — — — — Cableado de control Calentador de agua Circuitos derivados Figura 13 — Montaje de un Conectador Alternativo —...
  • Page 40: Interconexiones De Cableado De Energía

    Conectador automático de Briggs & Stratton Power Products Interconexiones de Cableado de Energía Todo el cableado debe tener el tamaño adecuado y debe estar correctamente soportado.También debe estar protegido mediante un conducto. Realice las conexiones siguientes entre el conectador, el panel principal de distribución, la red pública y el generador (Figura 14 de la página siguiente).
  • Page 41 Conectador automático de Briggs & Stratton Power Products Figura 11 — Un Esquema Típico de Instalación para Conectador Conexión de la compañía proveedora de electricidad Conexión al generador Orejetas de conexión a tierra (GND) Al Generador Manual de Instalación y del Operario A la Red Pública NOTA: Los modelos 01928-1 y 01929-1 incorporan un utilidad desconecta cortacircuitos en la caja del conectador.
  • Page 42: Prueba Del Conectador Automático

    SISTEMA FUNCIONAMIENTO Para seleccionar el funcionamiento automático del conectador, haga lo siguiente: 1A. Para modelos 01813-1 y 01814-1, ponga el seccionador de servicio que envía tensión de la red pública al contactor del conectador en la posición “On” (cerrado). B. Para modelos 01928-1 y 01929-1, ponga el seccionador de servicio que envía tensión de la red pública al conectador de...
  • Page 43: Especificaciones

    ESPECIFICACIONES UL® 1008 Listó Conectador Modelo 01813-1 Carga máxima/circuito: desde el centro de carga ....... .100 A Tensión nominal c.a.
  • Page 44: Garantia

    POLÍTICA DE GARANTÍA PARA EL PROPIETARIO DEL CONECTADOR DE BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC Fecha de entrada en vigor: 1 de Noviembre de 2005. Sustituye a todas las garantías sin fecha y a las de fecha anterior al 1 de Noviembre de 2005 Briggs &...
