KEYLESS ENTRY ALARM UPGRADE MODULE
Congratulations on your purchase of the PRO 9232a automotive Keyless Entry
Upgrade Alarm System. This system is a state - of - the - art auto security system
that is designed to automatically arm and disarm when it receives a command from
your existing Factory Keyless Entry Transmitter. Taking a few moments to read this
manual will help to ensure that your vehicle is protected at all times.
NOTE:
The system has the ability to beep the vehicle's horn, sound a siren, or both. Where
a beep or chirp is mentioned, consider either or both may sound.
ARMING THE SYSTEM : ( ACTIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. Press and release the Lock button on the keychain transmitter.
3. The siren and or horn will beep one time, the parking lamps will flash one time,
and the red dash mounted LED will begin to slowly flash, indicating that the
system is ARMED.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection. If the siren "chirped"
three times, sometime after arming, the exclusive delayed dome light learn circuit
has been programmed and the system detected a open entry point after the
learned delay expired. Again, closing the hood, trunk, or doors will correct the
problem and you do not need to disarm the system to make the correction. If the
siren/horn did not sound when arming, then the chirps have been turned off, and
you should refer to the section titled " ELIMINATING THE ARM / DISARM CHIRPS "
in this manual.
4. Any time the door lock switch in the vehicle is used to lock the doors while
the ignition key is turned off, the system will immediately arm. To lock the doors
after entering the vehicle, make sure the ignition key is switched on first.
Turning the ignition key on first will stop the system from arming.
ARMING THE SYSTEM : ( PASSIVE )
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. The dash mounted LED will begin to flash rapidly, indicating that the system
Model PRO 9232a
OWNER'S MANUAL
128-6626
1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox Pursuit PRO 9232a
Summary of Contents for Audiovox Pursuit PRO 9232a
- Page 1 KEYLESS ENTRY ALARM UPGRADE MODULE Congratulations on your purchase of the PRO 9232a automotive Keyless Entry Upgrade Alarm System. This system is a state - of - the - art auto security system that is designed to automatically arm and disarm when it receives a command from your existing Factory Keyless Entry Transmitter.
- Page 2 is automatically ( passively ) arming. As an added convenience, the 30 second automatic passive arming will not begin until all doors are closed, allowing passen- gers to exit the vehicle at their convenience. 3. In 30 seconds, you will hear a single short chip from the siren, and the vehicle’s parking lamps will flash one time, indicating that the system has ARMED.
- Page 3 installed, the vehicle’s interior lights will turn on for 30 seconds, or until the ignition key is turned on. NOTE: If your system has been programmed for “ passive arming “, then it will begin to re-arm immediately after disarming. This is indicated by a rapid flashing of the red dash mounted LED Opening one of the vehicle’s doors will suspend the passive arming process until all doors have been closed, or until the ignition key has been turned on.
- Page 4 TO ENTER THE VALET MODE: 1. Disarm the unit by use of the factory transmitter or by use of the manual override sequence. 2. Turn the ignition switch to the “On” position. 3. Press and hold the valet/override pushbutton switch for 5 seconds. The LED turns on, indicating valet mode has been successfully entered.
- Page 5 the manual override sequence. If the code is not successfully entered within the three attempts, disarming with the manual override switch will be locked for 10 minutes. In many cases, to increase the security of your system, you may elect to change the manual override code to a number that is more familiar to you, or simply to have a different code than was pre-assigned from the factory.
- Page 6 Custom Code Programming Example: To Change the code from the factory pre-assigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.
- Page 7 To operate the optional accessory; 1. Press the lock, then unlock, then lock buttons on your keychain transmitter within 3 seconds. 2. The optional accessory will immediately activate. OPTIONAL AUTO LOCK/UNLOCK FEATURE : If your existing factory installed keyless entry system did not include the automatic door lock and unlock feature, then this feature can be activated from the PRO 9232 upgrade module.
- Page 8 PRO 9232a SYSTEM FUNCTIONS AT A GLANCE DASH L.E.D. INDICATORS RAPID FLASHING SLOW FLASHING ON - SOLID 3 FLASH ... PAUSE ... 2 FLASH ... PAUSE ... 1 FLASH ... PAUSE ... CHIRP INDICATORS 1 CHIRP * 2 CHIRPS* 3 CHIRPS 3 CHIRPS 4 CHIRPS 2 SHORT CHIRPS - 1 LONG CHIRP...
