CONGRATULATIONS! Your purchase of this state-of-the-art security system expresses a
deep concern for the security of your vehicle, its contents, and passengers. To fully appreciate
the many functions and safeguards incorporated in this system, please spend a few minutes
reading this manual. You may find unexpected features that could mean the difference
between "protected" and "fully protected"
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the
particular features and options installed in your vehicle as well as the override method
selected. Valet Switch manual override is pre-selected from the factory, however, the
system can be configured for "Custom Code" operation. Confirm the override mode selected
on the last page of this manual, and familiarize yourself with the section on it's operation.
FEATURES :
w 2 Three Button Programmable RF Transmitters (capable of accepting 4 transmitters)
w Separate Lock/Unlock Transmitter Buttons
w Four Channel Receiver
w Scan Deterrent Technology
w Selectable Manual Override Mode
w User Programmable Manual Override Code
w Active or Passive Arming Selectable
w Programmable Auto Lock On / Off
w Programmable Auto Unlock, Drivers, All, None
w Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds / 1 Sec, Dbl. 1 Sec
w Programmable Active or Passive Door Locks
w RF Inhibit with ignition on
w Interior Light Flasher (Arm/Disarm/Programming)
w Remote Trunk Release (must have electronic trunk release)
w LED Status Indicator Displays Arming, Armed, Disarmed & Valet
OPTIONS :
w Parking Light Flasher (Relay Required) (Arm/Disarm/Programming)
w Starter Disable (Relay Required)
w Multiple Vehicle Capable
w Remote Vehicle Starter
w Remote Power Window Roll Up
w Remote Garage Door Interface
Note: The "Arming" and "Disarming" references in this manual apply only to those vehicles
which have the optional starter inhibit relay installed, and take place when the vehicle
is locked and unlocked respectively.
Model PRO 9246FT3
Owner's Manual
Active/Passive Operation
Remote Keyless Entry
Advertisement
Table of Contents
Related Manuals for Audiovox Pursuit PRO 9246FT3
Summary of Contents for Audiovox Pursuit PRO 9246FT3
- Page 1 Active/Passive Operation Remote Keyless Entry CONGRATULATIONS! Your purchase of this state-of-the-art security system expresses a deep concern for the security of your vehicle, its contents, and passengers. To fully appreciate the many functions and safeguards incorporated in this system, please spend a few minutes reading this manual.
- Page 2 Locking / Arming (Active) 1. Turn off the engine, exit the vehicle, and close all doors. 2. Press and release the Lock button on the keychain transmitter. The doors will lock, the LED will begin to flash slowly and the vehicle’s parking lamps will flash once, if the optional parking light flasher was added.
- Page 3 CAR FINDER: As an added convenience, your system has the ability to flash the parking lights, (If this option has been added), on command from the transmitter. This feature is particularly useful to help locate your vehicle in a crowded parking lot. To access this feature, simply press and hold the Lock or Unlock button of your keychain transmitter for three seconds.
- Page 4 the factory with a pre-programmed override code of 11. To change this default override code, do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. Turn the ignition switch to the on position. 2.
- Page 5 pattern will be repeated three times indicating the new code (52) has been accepted and stored in memory. NOTE: If after step 7, the LED flashes a code other than what was just entered, this indicates that the code has not been changed. You will have to repeat steps 1 through 7 above being certain to note the following: Acceptable digits 10ths or units are 1 through 9.
- Page 6 Ignition Controlled Locks o Ignition Controlled Unlock o Drivers Door o All Doors o Passive Arming o Passive Door Locks o Starter Disable o Valet Override System o Custom Code Override System © 2000 Audiovox Electronics Corporation, Hauppauge, NY 11788 128-5885...
