Audiovox Prestige Platinum APS-687C Owner's Manual

Audiovox Prestige Platinum APS-687C Owner's Manual

Deluxe 7 channel platinum remote start system with keyless entry
Hide thumbs Also See for Prestige Platinum APS-687C:
Table of Contents

Advertisement

Quick Links

Download this manual
Table Of Contents:
Features and Options
Your "Code Hopping" Transmitters
Keyless Entry
Optional Remote Function Channels
Optional Additional Remote Channel 4
Optional Additional Remote Channel 5, 6, 7
Valet Override, Programming & Safety Control Switch
Vehicle Service / Remote Start Override Mode
Turbo Timer Operation
Remote Starting The Vehicle
Automatic Start Timer Operation
Telematic Upgrade
Programmed Transmitter Notification (PTN)
Programming New or Replacement Transmitters
Features And Function Setting Chart
PATENTED: www.voxxintlcorp.com/company/patents
Rev b New Format 5/13
Model APS-687C
Owners Guide
Deluxe 7 Channel
Remote Start System
With Keyless Entry
Page 1
128-8782b
Page 2
Page 3
Page 3 - 4
Page 4
Page 4
Page 5
Page 6
Page 6
Page 6 - 7
Page 7 - 8
Page 9 - 10
Page 10
Page 10
Page 11
Page 12
1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige Platinum APS-687C and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox Prestige Platinum APS-687C

Summary of Contents for Audiovox Prestige Platinum APS-687C

  • Page 1 Model APS-687C Owners Guide Deluxe 7 Channel Remote Start System With Keyless Entry Table Of Contents: Features and Options Page 2 Your "Code Hopping" Transmitters Page 3 Keyless Entry Page 3 - 4 Optional Remote Function Channels Page 4 Optional Additional Remote Channel 4...
  • Page 2 Deluxe 7 Channel Remote Start System With Keyless Entry FEATURES :  2 Five Button Programmable RF Transmitters  Seven Channel Receiver (capable of accepting 4 transmitters)  Code Hopping Technology  External Superheterodyne Antenna w/PushButton Switch and LED  Safe Start RF Control (Double Push Of RF Transmitter) ...

  • Page 3: Keyless Entry

    YOUR "CODE HOPPING" TRANSMITTERS The transmitters included with your new remote start system use the most advanced and secure form of radio frequency transmission available on any current automotive remote sys- tem. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re-transmit at a later time to unlock your system.
  • Page 4 beep for 30 seconds or until the button is activated again for 3 seconds or any other button is operated. NOTE: This system has the ability to unlock the drivers door with the first press of the unlock transmitter button and then unlock all other doors when the unlock button is pressed a second time.
  • Page 5 ADDITIONAL REMOTE FUNCTION (CHANNEL 5) This system has an additional feature that can be connected to a number of different optional accessories. Some of the more common uses for this channel are:  Remote Trunk Release  Remote Window Closure ...

  • Page 6: Turbo Timer Mode

    Please consult your installing retailer for more information concerning the options available. PUSH-BUTTON LED RECEIVER VALET/OVERRIDE/SAFETY CONTROLSWITCH The Push-Button LED switch located in the receiver allows you to temporarily disable the remote starting function of the system. This IS recommended whenever the vehicle is being serviced. To place the system in the service mode: 1) With the system disarmed/unlocked, and the ignition switch off, Press and Hold the Push-Button, found on the windsheild receiver, in.

  • Page 7: Remote Starting The Vehicle

    TO ACTIVATE THE TURBO TIMER Anytime the ignition key is in the on position for more than 15 seconds: 1) Place the gear selector in park. 2) Set the parking, (hand), brake. 3) Be certain your foot is off the brake pedal. 4) Press the receiver's program/Push-Button switch 2 times within 5 seconds.

  • Page 8: To Remote Start The Vehicle

    WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if the car is garaged. TO REMOTE START THE VEHICLE Press and release the trunk/key button of your keychain transmitter two times within 2 seconds.
  • Page 9 OPERATING ON AUTOMATIC START UP TIMER MODE The system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine.

  • Page 10: Telematic Upgrade

    The parking lights will flash and the siren will chirp 4 times indicating the timed start mode is activated. CANCELING THE AUTOMATIC START UP TIMER To cancel the automatic start up timer do one of the following; 1. Start the vehicle manually with the use of the ignition key and depress the brake pedal.
  • Page 11 PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1) Transmitter Model Name Is Found On Back Of Transmitter Case 1) Turn the ignition key to the on position. 2) Press and release the valet/programming switch 3 times (Siren Chirps). 3) Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren.
  • Page 12 NOTE: Two step unlock is an option and may not have been installed. To purchase replacement transmitters or to get additional product information go to: www.prestigecarsecurity.com ©2013 Audiovox Electronics Corp., 150 Marcus Blvd. Hauppauge, N.Y. 11788 Page 12 128-8782b 12 of 12...
