- Page 1 INSTRUCTION MANUAL Cordless Recipro Saw JR103D JR105D Read before use.
-
Page 2: Specifications
Vibration The typical A-weighted noise level determined accord- The vibration total value (tri-axial vector sum) deter- ing to EN62841-2-11: mined according to EN62841-2-11: Model JR103D Model JR103D Sound pressure level (L ) : 78 dB(A) Work mode: cutting boards Uncertainty (K) : 3 dB(A) Vibration emission (a ) : 8.0 m/s... -
Page 3: Ec Declaration Of Conformity
Work mode: cutting wooden beams Avoid body contact with earthed or grounded Vibration emission (a ) 8.0 m/s surfaces, such as pipes, radiators, ranges and h,WB Uncertainty (K) : 1.5 m/s refrigerators. There is an increased risk of elec- tric shock if your body is earthed or grounded. Model JR105D Work mode: cutting boards Do not expose power tools to rain or wet con-... - Page 4 Always wear protective goggles to protect When using the tool, do not wear cloth work your eyes from injury when using power tools. gloves which may be entangled. The entangle- The goggles must comply with ANSI Z87.1 in ment of cloth work gloves in the moving parts may the USA, EN 166 in Europe, or AS/NZS 1336 result in personal injury.
- Page 5 MISUSE or failure to follow the safety also void the Makita warranty for the Makita tool and rules stated in this instruction manual may cause charger. serious personal injury.
-
Page 6: Functional Description
Battery protection system FUNCTIONAL DESCRIPTION The tool is equipped with a battery protection system. This system automatically cuts off power to the motor to extend battery life. CAUTION: The tool will automatically stop during operation if the Always be sure that the tool is tool and/or battery are placed under one of the following switched off and the battery cartridge is removed conditions:... - Page 7 Always clean out all chips or for- eign matter adhering to the blade and around the blade clamp. Failure to do so may cause insufficient tightening of the blade, resulting in a serious injury. For Model JR103D ► 1 . Lamp Pull the switch lever/trigger to light up the lamp. The lamp keeps on lighting while the switch lever/trigger is being pulled.
- Page 8 This can be extremely dangerous. NOTE: You can not use the jig saw blade with JR103D. ► 1 . Recipro saw blade 2. Hex wrench 3. Hole for recipro saw blade 4. Blade clamp To install the recipro/jig saw blade, loosen the bolt by hex wrench. When installing a recipro saw blade, press the bolt with the hex wrench to open the slot during inserting the blade.
-
Page 9: Operation
NOTICE: Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. 9 ENGLISH... -
Page 10: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885441B225 www.makita.com 20190117...
