Pole Mount Kit for WIRA 40 Outdoor
Pole bracket for installing WIRA 40° antennas outdoor.

General Specifications

Order No.
Type
Max. load-bearing capacity
Adjustment range
Elevation
Usable pole diameters
Weight
Packing size (L x W x H)
Material
Bracket
Pole clips
Screws

Usable with the Following Antennas

WIRA 40 Antenna Series

Selecting the Installation Location

Caution
Risk of an injury or damage to property due to an inappropriate antenna mounting!
► Make sure that the pole has adequate load-bearing capacity.
► If necessary, use a different pole.
KATHREIN Solutions GmbH, Kronstaudener Weg 1, 83071 Stephanskirchen, Germany
Phone +49 8036 90831-20 | Fax +49 8036 90831 69 | www.kathrein-solutions.com | iot-info@kathrein-solutions.com
[kg]
[°]
[mm]
[kg]
Order No.
52010251
52010252
52010262
MK-WPGM-100-100-Outdoor
6.0
+20/–45 (elevation angle)
42–115
2.5
295 x 295 x 100
galvanised steel sheet
hot-dop galvanised steel
galvanised steel
Type
WIRA-40-linear-ETSI
WIRA-40-linear-FCC
