Walter AXIO Mounting Instructions page 3

A - Anodised aluminium axle + motor
B - Shaft + rinas. oooosite to the motor
C - Electrical box
D - Quick fastening system (qty depending on the width of the pool)
E - Axle support flange, beam support and alignment wedge
F - Rolling straps tobe fixed on the axle (qty depending of the width of the pool)
G - 50 cm slat strips (6 slats/strip) (qty depending of the length of the pool)
H - . S andow (qty dependi ng of the length of the pool\
1 - Beam
J - Duckboardinq (qty dependinq of the lenqth of the pool)
K - Connection box + protective qel
L - Key switch
M - PVC partition + str 9 iqht or anqled runner
N - Flange mounting bracket (optional)
0 - Beam bracket support (optional)
D - Kit of screws
D - Mounting instructions manual
Note: Pictures are not contractual. For information
(optional)
