A full featured remote security system withon-board satellite/paging access
Hide thumbs Also See for Prestige Platinum APS-700:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual See also: Instruction and Installation Manual
The APS-700 is a full featured security system with on board paging technology that provides
you with a direct link to your vehicle from anywhere in the world. In addition to operating the
system from your keychain transmitter, this patent pending technology allows you to operate
the vehicle from any land or mobile telephone. You can command the security system to arm
or disarm, release the trunk, start the vehicle, and in case of a carjacking, put the APS-700 in
a special carjack mode that will flash the lights, sound the siren and prevent restarting of the
vehicle.
The APS-700 can be operated from a telephone by placing a call to the 1-800 number listed on
the wallet card enclosed. Identify yourself, give the operator your secret password and the
function you want your vehicle to perform. The operator will send the command through the
satellite and land based network and within minutes your vehicle will respond. It is advised that
you read this manual in it's entirety to understand all the features and options available to your
vehicle.
FEATURES:
2 Three Button RF Transmitters
Anti Code Grabbing Technology
Four Channel Receiver
Remote Panic In All Modes
Protected Valet
User Programmable Manual Override
7 Function LED
Intrusion Alert With Memory
Audible Arm, Disarm, Tamper, and Defective Zone Siren Confirmation
Instant Siren Activation
Starter Disable
Additional Engine Immobilizer Circuit (Optional Relay Required)
True Last Door Arming
Active Or Passive Arming Selectable
Programmable Auto Lock
Programmable Auto Unlock
Programmable Door Lock Output Duration
On Command Chirp Delete
User Selectable Permanent Chirp Delete
6 Tone Multi Tone Siren
Car Horn Activation For Additional Alarm Response
RF Inhibit With Ignition On
Dual Light Flash Output
Plug In Two Stage Shock Sensor
Over The Air Vehicle Access Of Channel 2 Auxiliary 1
Over The Air Vehicle Access Of Channel 3 Auxiliary 2
Over The Air Vehicle Access Of Channel 4 Auxiliary 3
Over The Air Vehicle Access Of Vehicle Theft / Hijack Sequence
AVAILABLE OPTIONS:
Remote Trunk Release (Must have power trunk)
Remote Keyless Entry (Must have power locks)
Illuminated Entry
Multi Vehicle Operation
Remote Start
Remote Power Window Control (Must have power windows)
Remote Garage Door Control (Must have electric garage door)
Model APS-700
Owner's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige Platinum APS-700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audiovox Prestige Platinum APS-700

Summary of Contents for Audiovox Prestige Platinum APS-700

  • Page 1 You can command the security system to arm or disarm, release the trunk, start the vehicle, and in case of a carjacking, put the APS-700 in a special carjack mode that will flash the lights, sound the siren and prevent restarting of the vehicle.
  • Page 2 YOUR ANTI CODE GRABBING TRANSMITTERS: The transmitters included with the APS-700 use technology considered to be the most se- cure form of radio frequency transmission available on today's Automotive Security Sys- tems. Thieves today may use a device commonly referred to as a code grabber. With this device, the code transmitted from a common RF transmitter can be captured and played back at a later date to disarm a standard security system.

  • Page 3: Protection While The System Is Armed

    point is opened during the 30 second arming cycle, arming will be suspended. When all entry points are closed, the arming cycle will begin again. At the end of the 30 seconds, The parking lights will flash once, the siren will chirp once, and the dash mounted LED will begin to flash slowly confirming the system is armed.

  • Page 4: Silent Disarming

    SILENT DISARMING: As you approach the vehicle, press and hold the arm/disarm button of your key chain trans- mitter for two seconds. The parking lights will flash twice, and the dash mounted LED will turn off confirming that the system is disarmed. If you have the optional door lock/unlock circuit installed, the doors will unlock.
  • Page 5 PROGRAMMING YOUR MANUAL OVERRIDE CODE: Your security system can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to disarm the system if you lose your transmitter, or if the transmitter battery fails. In order to provide the highest level of security, this system will allow you to program your personal manual override code.

  • Page 6: Eliminating The Normal Arm/Disarm Chirps

    ADDITIONAL REMOTE CHANNELS AVAILABLE FROM YOUR TRANSMITTER OR BY PAGING THE VEHICLE: The APS-700 security system has additional features that can be controlled from your keychain transmitter as well from the satellite paging network. These features can be configured to...
  • Page 7 configuration listed indicates the default setting from the factory. If the installation of your unit specifies a different transmitter configuration, the transmitter operation will be listed on the rear page of this manual. REMOTE CHANNEL 2 / AUXILIARY 1 FUNCTIONS: This security system has an additional feature that can be connected to a number of optional accessories.
  • Page 8 Once the vehicle comes to a complete stop for more than 5 seconds the APS-700 will cause the engine to shut off, disabling the vehicle and leaving the thief stranded. If the need arises to activate a theft command, the only way to reset this function is to call in a "Reset"...

  • Page 9: System Functions At A Glance

    ILLUMINATED ENTRY AUTO LOCK WITH IGNITION AUTO UNLOCK WITH IGNITION HEAD LAMP ILLUMINATION DURING ARMING HEADLIGHT ILLUMINATION DURING DISARMING PASSIVE (Automatic) ARMING DOOR LOCKS IN THE PASSIVE MODE APS-700 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2...

  • Page 10: Product Information

    Your APS-700 (Patent Pending), Satellite/Pager Based Remote Security System provides a direct link between you and your vehicle from virtually any phone in the world. You can command your vehicle to activate any of the installed options including unlocking the doors, arming or disarming the system, opening the trunk, auto locate or carjack/theft (Flash the lights, sound the horn, interrupt the starter.)
  • Page 11 El sistema APS-700 es un sistema de seguridad con todas las funciones y la tecnología de aviso incorporada que le proporciona un enlace directo con su vehículo desde dondequiera que se encuentre. Además de operar el sistema con su transmisor de llavero, esta nueva tecnología, cuya patente está...
  • Page 12 El Sistema de alarma con arranque remoto APS-700, con acceso por satélite / sistema de aviso incorporado, tiene muchas funciones y opciones que se eligen en el momento de la instalación. Para que tenga como referencia, la lista que aparece en la contratapa de este manual tiene indicadas las funciones y opciones que se instalaron.

  • Page 13: Protección Mientras El Sistema Está Activado

    L.E.D. no empieza a destellar enseguida, entonces ha dejado una puerta, el capó o el baúl abierto. Al cerrar cualquiera de estos puntos de acceso, se iniciará el ciclo de activación. Al abrir cualquier puerta protegida durante el ciclo de activación pasiva de 30 segundos se suspenderá...

  • Page 14: Desactivación Silenciosa

    DESACTIVACIÓN SILENCIOSA: Cuando se vaya acercando al vehículo, oprima el botón ARM / DISARM del transmisor de llavero y manténgalo apretado durante 2 segundos. Las luces de estacionamiento destellan dos veces y el indicador L.E.D. montado en el tablero se apaga para confirmar que el sistema está desactivado. La sirena no suena. Si tiene instalado el sistema de circuito opcional para trabar / destrabar, las puertas se destrabarán.
  • Page 15 PROGRAMACIÓN DEL CÓDIGO DE CAPTURA MANUAL: Se puede desactivar el sistema de seguridad sin usar el transmisor de llavero. Esta función es necesaria porque de ese modo tendrá la capacidad de desactivar el sistema si pierde el transmisor o si falla la pila del mismo. Para proporcionar el más alto nivel de seguridad, este sistema le permitirá...
  • Page 16 OTROS CANALES REMOTOS DEL TRANSMISOR O MEDIANTE EL SISTEMA DE AVISO PARA EL VEHÍCULO: El sistema de seguridad APS-700 tiene otras funciones que pueden controlarse con el transmisor de llavero, así como con la red del sistema de aviso por satélite. Se puede configurar estas funciones para operarlas con un solo botón del transmisor o con una...
  • Page 17 establecidos en fábrica. Si la instalación de su vehículo especifica una configuración distintas para el transmisor, la operación del transmisor aparecerá en la página de atrás de este manual. FUNCIONES REMOTAS DEL CANAL 2 / AUXILIAR 1 Este sistema de seguridad tiene una función adicional que puede conectarse a una serie de distintos accesorios opcionales.
  • Page 18 Una vez que el vehículo se detiene completamente durante más de 5 segundos, el sistema APS-700 hará que el motor se apague, desactivando el vehículo y dejando al ladrón a pie. Si surgiera la necesidad de activar el comando de robo, la única manera de restablecer esta función es llamar e indicar la orden “Reset”...
  • Page 19 RESUMEN DE LAS FUNCIONES DEL SISTEMA INDICADORES L.E.D. DEL TABLERO DESTELLO RAPIDO DESTELLO LENTO APAGADO ENCENDIDO CONTINUO 3 DESTELLOS ... PAUSA 2 DESTELLOS ... PAUSA 1 DESTELLO ... PAUSA INDICADORES DE CHIRRIDOS DE LA SIRENA Y/O BOCINA 1 CHIRRIDO 2 CHIRRIDOS 3 CHIRRIDOS 4 CHIRRIDOS 3 CHIRRIDOS CORTOS,...

  • Page 20: Información Sobre El Producto

    Su sistema de seguridad APS-700 con control remoto mediante satélite / sistema de aviso (cuya patente está pendiente) le proporciona un enlace directo entre usted y su vehículo desde prácticamente cualquier teléfono del mundo. Puede enviar una orden o comando a su vehículo para activar cualquiera de las opciones instaladas, incluso el destrabado de puertas,...
