- Page 1 (English) DM-PD0001-05 Dealer's Manual ROAD Trekking City Touring/ URBAN SPORT E-BIKE Comfort Bike Flat Pedal DEORE XT PD-M8040 SAINT PD-MX80 PD-M828 Non-Series PD-GR500...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT NOTICE ....................3 TO ENSURE SAFETY ....................4 LIST OF TOOLS TO BE USED .................. 6 INSTALLATION ....................... 8 Mounting the pedals on the crank arms ....................8 ADJUSTMENT ...................... 10 Adjusting the gripping force ........................10 MAINTENANCE ....................13 Pin ................................13 Axle unit ..............................14 Replacing and mounting the reflectors ....................17... -
Page 3: Important Notice
• All manuals and technical documents are accessible online at https://si.shimano.com. • For consumers who do not have easy access to the internet, please contact a SHIMANO distributor or any of the SHIMANO offices to obtain a hardcopy of the User's Manual. -
Page 4: To Ensure Safety
• Be sure to follow the instructions provided in the manuals when installing the product. It is recommended that you use SHIMANO genuine parts. Loose nuts or bolts and product damage may cause a sudden accident such as a fall and lead to serious injury. -
Page 5: List Of Tools To Be Used
LIST OF TOOLS TO BE USED... - Page 6 LIST OF TOOLS TO BE USED LIST OF TOOLS TO BE USED The following tools are needed to assemble this product. Tool Tool Tool 2 mm hexagon wrench 10 mm spanner TL-PD33 8 mm hexagon wrench 15 mm spanner TL-PD40 7 mm spanner 20 mm spanner TL-PD63...
-
Page 7: Installation
INSTALLATION... -
Page 8: Mounting The Pedals On The Crank Arms
INSTALLATION Mounting the pedals on the crank arms INSTALLATION „ Mounting the pedals on the crank arms Apply a small amount of grease to the thread to prevent sticking. PD-MX80/PD-GR500 Use a 15 mm spanner or 8 mm hexagon 15 mm spanner wrench to mount the pedals on the 8 mm hexagon wrench crank arms. -
Page 9: Adjustment
ADJUSTMENT... -
Page 10: Adjusting The Gripping Force
ADJUSTMENT Adjusting the gripping force ADJUSTMENT „ Adjusting the gripping force PD-MX80/PD-GR500 Remove spacers or add pins to adjust the gripping force between the shoes and the pedals. • On this pedal, there are 18 pin mounting locations on top and bottom in total. Spacer •... - Page 11 ADJUSTMENT Adjusting the gripping force PD-M8040/PD-M828 Replace the long pins or short pins to adjust the gripping force between the shoes and the Short pin pedals. Long pin • The number of pins differs depending on the model. : Pin installation positions...
-
Page 12: Maintenance
MAINTENANCE... -
Page 13: Pin
MAINTENANCE MAINTENANCE „ Pin If the pins become worn or damaged, replace them with new pins. Hexalobular[#15] PD-MX80/PD-GR500 2 mm hexagon wrench Tightening torque 2 - 2.5 N·m 1 - 1.5 N·m PD-M8040/PD-M828... -
Page 14: Axle Unit
• The right pedal has a left-hand thread; the left pedal has a right-hand thread. Use the Shimano original tool TL-PD63 or TL-PD33, or 7 mm and 10 mm spanners to turn the cone (10 mm) to adjust the rotation. - Page 15 • The right pedal has a left-hand thread; the left pedal has a right-hand thread. PD-M8040 Use the Shimano original tool TL-PD63 or TL-PD33, or 7 mm and 10 mm spanners to turn the cone (10 mm) to adjust the rotation. PD-M828 Use 7 mm and 8 mm spanners to turn the cone (8 mm) to adjust the rotation.
- Page 16 MAINTENANCE Axle unit With the cone locked, tighten the lock nut (7 mm). 7 mm spanner Crank side PD-M8040 Lock bush Body cup Cone Lock nut TL-PD63/33 Lock nut tightening torque (PD-M8040) 5 - 7 N·m Lock nut tightening torque (PD-M828) PD-M828 5 - 7 N·m...
-
Page 17: Replacing And Mounting The Reflectors
MAINTENANCE Replacing and mounting the reflectors „ Replacing and mounting the reflectors PD-MX80/PD-GR500 A special reflector set SM-PD64 is available. Mount reflectors with pins. Reflector Tightening torque 2 - 2.5 N·m NOTICE • When using the product without a reflector, adjust the protrusion of pins using attached spacers. - Page 18 MAINTENANCE Replacing and mounting the reflectors PD-M8040 A special reflector set SM-PD67 is Reflector fixing nut available. Mount reflectors with reflector Spring washer fixing nuts and reflector fixing plate. Washer Reflector fixing plate Reflector Tightening torque 1 - 1.5 N·m (C) (D)
- Page 19 Please note: specifications are subject to change for improvement without notice. (English) © Nov. 2019 by SHIMANO INC. ITP...
