Summary of Contents for Precision Rated Optics VIP-35
- Page 1 VIP-35 Manual Video Inspection Probe...
- Page 2 Precision Rate Optics for its use nor for any infringements of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent rights of Precision Rated Optics.
- Page 3 Structure/Parts A. Analog Probe This probe utilizes an analog CCD, which outputs an NTSC or a PAL signal. The signal is routed through a 4-pin connector that routes power into the probe, and the video signal out of the probe. This unit is suitable for use with our hand held LCD display.
- Page 4 3.5 Inch LCD Monitor Camera Camera Reserved Button Power Switch Reserved Button These monitors can be powered by an output 110-240V DC/AC or a rechargeable Li-ion battery equipped inside. Video input is dedicated to PAL/NTSC formatted probe. All of the display’s controls are built into the handle for easy access.
-
Page 5: Installation
Installation Tip Assembly Installing Tips on Probe Assembly & Tip Installed Standard Step 1 Locate tip you want to install and look at the threaded end. This screw acts as a “key” and is already mounded with the Key Channel. DO NOT try to screw the Key Channel off from the threaded Key, which might destroy the whole probe. -
Page 6: Specifications
Bulkhead Adapter, 2.5mm Universal Adapter, 1.25mm Universal Adapter, Soft Carrying Case VIP-35 w/Data Storage Kit Standard Package Includes: VIP-35, 400X Inspection Probe and Monitor, AC/DC Charger, FC/SC Bulkhead Adapter, LC Bulkhead Adapter, 2.5mm Universal Adapter, 1.25mm Universal Adapter, USB Data Cable, Soft Carrying Case www.PrecisionRatedOptics.com... -
Page 7: Warranty
● the product enclosure has been opened, other than as explained in this manual. ● the equipment serial number has been altered, erased, or removed. ● the equipment has been misused, neglected, or damaged by accident. P/N: PRO-VIP-35-M v.1.29.18 www.PrecisionRatedOptics.com Tel: (888) 545-1254 •... - Page 8 Precision Rated Optics, Inc. National Sales Office 2030 Blue Heron Circle Birmingham, AL 35242 Precision Rated Optics, Inc. Corporate Office Billing & Processing PO Box 877 Trexlertown, PA 18087 Precision Rated Optics, Inc. Product Distribution Center Manufacturing & Testing 9999 Hamilton Blvd...
