- Page 1 VIP-55 Video Inspection Probe Operation Guide V.9.6.17...
-
Page 2: Table Of Contents
VIP-55 Table of Contents VIP-55 Video Inspection Probe ........................3 FB Connect ................................4 Highlights ................................4 APP installation and use ..........................5 App installation ..............................5 USB Cable Use ..............................8 Configuration ..............................9 Specification ..............................10 Maintenance ..............................11 Troubleshoot ..............................11 After-sales service ............................12 888-545-1254 | www.PrecisionRatedOptics.com... -
Page 3: Vip-55 Video Inspection Probe
VIP-55 Video Inspection Probe Keeping the previous advantages of quick check, the new VIP-55 fiber inspection probe is designed to be smarter and more power saving. It has both WIFI and USB connections to help get end face images quickly sent and shown on a smart phone either in Android or Apple system. -
Page 4: Fb Connect
VIP-55 FB Connect FB Connect is the mobile software application for Android and IOS system. It can capture, display and record the fiber end-face image on the phone with ease. Highlights 1) Precise cone-shaped tip to reach 98% alignment consistency. -
Page 5: App Installation And Use
VIP-55 APP installation and use App installation Apple: Search for the app “FB Connect” in apple store and download as usual. Supports IOS 8.0 or above. Android: Search for the app “FB Connect” at app store and download as usual. Supports Android 4.4 or above. - Page 6 VIP-55 User can also share the file with the third party software to access external network. Adjustment Click the upper right corner, three functions will be shown including Brightness adjustment, Contrast adjustment and Calibrate function. 888-545-1254 | www.PrecisionRatedOptics.com...
- Page 7 VIP-55 Calibrate function to help easily delineate the zone areas stipulated in industrial standards. Brightness to adjust the device brightness automatically or manually. Contrast to adjust the device contrast automatically or manually. Reset User can change the WIFI password under setting selection as below image. If the password is forgotten, user can click the “reset”...
-
Page 8: Usb Cable Use
VIP-55 USB Cable Use The VIP-55 can also work with USB cable connection, besides the WIFI connection. User can switch between the modes through Quickswitch Double click the power button of the probe to switch between the modes. When the WIF/USB light turns green from blue, it indicates a normal USB signal output, which afterwards can be connected to mobiles or other PC for checking. -
Page 9: Configuration
VIP-55 Configuration Items Description Quantity Probe supports 2.4GHz WIFI channel 1pcs VIP-55 and USB2.0 wire connection 2.5mm Universal (Male) 1.25mm Universal (Male) 1pcs Standard tips LC Bulkhead (Female) each SC/FC Bulkhead (Female) USB to Micro USB cable, for charging or data translate... -
Page 10: Specification
VIP-55 Specification Items Values 400X Magnification Resolution <1um Field of View(mm) X: 0.3487 Y: 0.2632 Blue LED Light source Focus Way Single-way Focus time 1~5 s >98% Alignment Capture button Available Quick switch Available, switch between WIFI and USB Micro USB... -
Page 11: Maintenance
VIP-55 Maintenance Tips: Please clean the connector before the inspection if necessary. Please clean the device regularly to prevent any dust and debris from previous connectors to impair the inspection. Please keep the device in a clean and dry environment. -
Page 12: After-Sales Service
VIP-55 After-sales service The probe has 12 months guarantee period and life-long maintenance service. Any damage caused either by improper use, falling, disassemble by user, or uncontrollable natural disasters, like lightning or fire, will not be eligible to guarantee service. - Page 14 Precision Rated Optics, Inc Corporate Office Billing & Processing PO Box 877 Trexlertown, PA 18087 Precision Rated Optics, Inc Product Distribution Center Manufacturing & Testing 9999 Hamilton Blvd Breinigsville, PA 18031...
