  • Page 1 TP-P6 Manual Multifunctional Test Platform...
  • Page 2 Precision Rate Optics for its use nor for any infringements of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent rights of Precision Rated Optics.
  • Page 3 Environmental Conditions The TP-P6 is designed to operate at a maximum relative humidity of 95% and at altitudes of up to 2,000 meters. For more information, please refer to the Specifications section.
  • Page 4 Warning!! PRO TP-P6 is a laser device. Users should avoid looking directly into the optical output. The use of a fiber scope or magnifier should also be avoided. The use of such devices can focus a highly intense beam onto the retina, which may result in permanent eye damage.
  • Page 5 How to Use This Manual Button or Menu: The operating units in the Graphical User Interface (GUI) that can be clicked by using the stylus are indicated by letters in square brackets, e.g. [Setup] and [Start]. Key: Function keys are on front panel, indicated by letter or icon in quotation marks, e.g. (POWER) (LIGHT).

  • Page 6: Table Of Contents

    4.3.1.2 Non-reflection Events 4.3.1.3 Inspection Events 4.4 Optical fiber Span and Event Types 5 Instruction of OTDR Modules of PRO TP-P6 5.1 Main Features of the OTDR Module 5.2 Measurement Mode of OTDR module 5.2.1 Auto Mode and Manual Mode 5.2.2 Averaging Mode and Real-Time Mode...
  • Page 7 Table of Contents 6 Preparing to use the OTDR 6.1 Connectors 6.2 Cleaning and Connecting to Optical Fiber 7 Testing with the OTDR 7.1 OTDR Quick Test 7.2 Trace Processing 7.3 Unsaved Traces 7.4 Saving a Trace 7.5 Auto Naming 7.6 Opening a Saved Trace File 7.7 Trace Viewing and Analysis 7.8 Information and Function Windows...
  • Page 8 Table of Contents 11 Trace and Event Analysis Settings 11.1 Opening a Trace File 11.2 Simultaneous Display MultipleTraces 11.3 Closing Trace Files 11.4 Trace Display 11.5 Switching and Moving Markers 11.6 Switching and Moving the Marked Point 11.7 Quickly Moving the Markers Outside of the Window 11.8 Locking the A/B Markers 11.9 Zooming in on the Trace 11.10 Cross Frame to Zoom-in on a Trace...
  • Page 9 16.7 Optical Connector Inspection Using the MCI Module 17 File Management 17.1 Transferring Files or Folders Between the PRO TP-P6 and a USB Storage Device 17.2 Transferring Files or Folders Between the PRO TP-P6 and a PC 17.3 Deleting Saved Files 18 Maintenance and Calibration 18.1 Cleaning Optical Interfaces...

  • Page 10: General Information

    This instrument has been carefully packed in accordance with standard shipping procedures. Examine the PRO TP-P6 for damage that may have occurred during shipment. If you find any damage or PRO TP-P6 is not operational, or if any of the included items are missing, please contact your nearest PRO representative: Precision Rated Optics, Inc.

  • Page 11: Introduction

    PRO TP-P6 is easy to handle and features a large, color touchscreen, accurate adjustment knob (AKA “Jog Shuttle”) and an intuitive Graphical User Interface (GUI). The TP-P6 is compatible with Windows CE and has a large built-in memory, which allows for the storage of test data, manipulation of stored data, or transfer of stored data to a PC, via USB.

  • Page 12: Product Appearance

    1 General Information 1.4 Product Appearance LCD Touchscreen 3-Way Adjustment Knob ( AKA “Jog Shuttle”) Laser Indicator Start/Stop Direction Keys/Enter Return Help Backlight Power On/Off Charging Indicator Power Indicator Note: Power On/Off key is lower than other keys to avoid miss-operation. OTDR Module VFL Port OTDR Port...

  • Page 13: Front Panel Indicators Introduction

    1 General Information 1.5 Front Panel Indicators Introduction Icon Status Meaning System off Green, constant System on Power On/Off Red, bspaning Low battery, charging needed Red, constant Charging with power adapter Red, bspaning Low battery Charging Indicator Green, constant Charging complete, with power adapter Power adapter unplugged or connection is poor Red, bspaning Laser on...

  • Page 14: Control Methods

    ● Please apply adequate force (not too much) with stylus on the touchscreen, ● Only use the included PRO TP-P6 stylus. Do not use any other object as a stylus. Sharp objects like a ball point pen may permanently mark or damage the touchscreen.

  • Page 15: Instrument Interfaces Instructions

    1 General Information 1.8 Instrument Interfaces Instructions Interfaces on Platform Top (Left to right) Name Appearance Icon Description DC Input Power adapter input Serial Port For system adjustment (Not open to user) Audio Output Headphone or audio output Audio Input Microphone input RJ45 Port 10/100Mbps Ethernet port...
  • Page 16 Warning!! Remember that the PRO TP-P6 is a laser instrument. Users should avoid looking directly into the optical output. The use of a fiber scope or magnifier should also be avoided. The use of such devices can focus a highly intense beam onto the retina, which may result in permanent eye damage.

  • Page 17: Gui Icons Instruction

    ● The battery power indicator displayed on LCD screen will turn red (Low battery) when the battery power is insufficient. The PRO TP-P6 may then turn itself off. ● If unused for a long time, the PRO TP-P6 may not power on properly. If this occurs, please connect the power adapter and fully recharge the battery.

  • Page 18: Using The Li-Ion Rechargeable Battery

    It will turn green when charging is complete. ● When the PRO TP-P6 is powered on and being charged, the LCD will also indicate the charge status. Note: If the TP-P6 is to be stored for a prolonged time, please charge the battery to 50%-70% before storing.

  • Page 19: Basic Operation

    2.3 Enter and Exit “Power Saving” Mode When the power is on, the user can set the PRO TP-P6 to “Power Saving” mode and return to normal status. In “Power Saving” mode, the LCD backlight will turn off.
  • Page 20 1. Select the “Modules” tab, then “Multifunctional Module“ or “Optical Connector Inspector” module. 2. Click the to launch the application. Note: Application programs are only accessible onscreen while the module is connected. The TP-P6 will automatically detect when a module has been connected. www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...

  • Page 21: Installing A Usb Keyboard Or Mouse

    Installing a USB keyboard or mouse on the PRO TP-P6 Connect the keyboard or mouse to the USB port. The USB port is on the top of PRO TP-P6. Note: ● You do not need to power down the PRO TP-P6 before connecting the keyboard and mouse. The platform will automatically recognize the keyboard and/or mouse.
  • Page 22 7.Select “OK” to finish the printer configuration. Note: ● The PRO TP-P6 only supports a USB printer with PCL language. Approved printers include the HP LaserJet 1022 and HP Laser P2015d, but others may be compatible as well. ● If the printer does not appear, remove the USB cable and reconnect the printer.

  • Page 23: Common Settings And Special Settings

    3 Common Settings and Special Settings 3.1 Main Setup Menu In the Setup menu, the user can customize many settings, including the interface style, language , “Power Saving” mode, system settings, touchscreen calibration, etc. Enter [Setup] Menu: After powering on, press the button to enter the [Setup} menu, as shown below: Fig 3.1 Setup Menu www.PrecisionRatedOptics.com...

  • Page 24: Select Language

    ● At the time of this printing, English and Chinese are the only two languages offered. 3.3 Automatic “Power Saving” Setting For prolonged testing sessions, it is suggested that you use the TP-P6 in “Power Saving” mode. The PRO TP-P6 is designed to automatically enter “Power Saving” mode after its idle time exceeds pre-set value (adjustable by the user).

  • Page 25: Recalibrating The Touchscreen

    3 Common Settings and Special Settings 3.4 Recalibrating the Touchscreen If the accuracy of the touchscreen seems abnormal, it is recommended that you recalibrate it. Recalibrating the Touchscreen 1. Click the button to enter into [Setup] menu. 2. While in the [Setup] menu, click [System Setup]. 3.

  • Page 26: Other Parameters Configuration

    Click on [System Setup] , then [Load Default]. You will then see “Restore factory settings?” Click “Yes” to restore to factory default settings, or “No” to cancel. Note: Keep in mind that restoring the TP-P6 to factory default setting will overide any settings you have made, including preferences and saved trace data. www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...

  • Page 27: Basic Information Of Otdr Module

    An OTDR (Optical Time Domain Reflectometer) is a measurement device for identifying optical fiber transmission problems. The PRO TP-P6 is mainly used to measure the attenuation of a whole optical fiber span, and to provide attenuation details relating to the length, location and characteristics of any event within the fiber optic span. An event can refer to faults caused by splicing, contamination, faulty connectors and/or bending in the fiber.

  • Page 28: Basic Definition And Classification Of Events

    4 Basic Information of OTDR Module 4.3 Basic Definition and Classification of Events 4.3.1 Events Events refer to any abnormal points causing attenuation or sudden change of scattering power, besides the normal scattering of optical fiber, which include all kinds of losses, such as bending, connections and breaks.

  • Page 29: Inspection Events

    4 Basic Information of OTDR Module 4.3.1.3 Inspection Events The OTDR sends a light pulse into the optical fiber to be inspected. It then receives returning light signals and starts calculating the “event” distance. The farther the distance is, the longer the time needed for scattered light to be received by the OTDR.

  • Page 30: Instruction Of Otdr Modules Of Pro Tp-P6

    5 Instruction of OTDR Modules of PRO TP-P6 5.1 Main Features of the OTDR Module ● High dynamic range and short dead zones. ● Complete sampling under low noise. Accurate low-loss detection. ● Resolution accurate to within 10cm. ● Multiple test models to meet the requirements of any test condition.

  • Page 31: Averaging Mode And Real-Time Mode

    5 Instruction of OTDR Modules of PRO TP-P6 5.2.2 Averaging Mode and Real-Time Mode Real-Time Mode: The OTDR will undertake a real-time measurement for the connector or exterior fiber and continually update the trace. While in “Real-Time Mode,” unless the user stops measuring, the OTDR will continue measuring.

  • Page 32: Otdr Interface

    5 Instruction of OTDR Modules of PRO TP-P6 5.3 OTDR Interface When powered on, the OTDR will show the main menu automatically. The platform automatically detects when an OTDR module (or any module) has been connected, and automatically enables the appropriate software to become accessible through the GUI.

  • Page 33: Icons In The Otdr Interface

    The “OTDR Trace Manager” software included with the TP-P6 is for trace review and analysis on a Windows-based PC, following trace acquisition. You can transmit the stored trace data be either connecting the TP-P6 directly to the PC, using the included USB cable, or by transferring the files using a USB “memory stick.

  • Page 34: Preparing To Use The Otdr

    6 Preparing to use the OTDR 6.1 Connectors The TP-P6 comes standard with FC and PC optical port connectors. It can also accommodate SC and ST connectors, which are available from Precision Rated Optics. 6.2 Cleaning and Connecting to Optical Fiber To ensure measurement accuracy, always clean and connect the fiber properly before testing.

  • Page 35: Testing With The Otdr

    7 Testing with the OTDR 7.1 OTDR Quick Test 7.1.1 Check the connection between the fiber and the OTDR optical port, making sure they are properly connected. 7.1.2 Click the icon, or press the button to start testing. 7.1.3 Click the icon, or press the button to stop testing.

  • Page 36: Unsaved Traces

    7 Testing with the OTDR 7.3 Unsaved Traces Unsaved traces will be titled as “*U_xxxx” (xxxx stands for the current testing wavelength), which is displayed on the upper-left corner of the trace display area. Note: A trace name starting with an asterisk: “*” indicates that it is an unsaved trace or a modified trace. 7.4 Saving a Trace When a trace is complete, the user can save the trace, along with the parameters information.

  • Page 37: Auto Naming

    7 Testing with the OTDR Operation Notes: ● The title bar will always show the current folder path, as shown in Fig 7.2: “\SDMMC_DISK\”. ● Newly created folders will automatically be displayed. ● After a file is saved, the file name will be displayed on the upper-left corner of the trace display area.

  • Page 38: Information And Function Windows

    7 Testing with the OTDR Show A/B Marker: ● Click the {Markers} tab in the OTDR main interface and the Markers or Marker tabs will show in the trace display area. ● Press the adjustment knob once. To move the Marker quickly: ●...

  • Page 39: Switch Information And Function Windows

    FiberBase, which is also available through Precision Rated Optics. Note: Any USB “thumb” drive can be used for the transfer if data from the TP-P6 to the computer. 7.10 Get Help While Using the OTDR While using the OTDR module, click “?”...

  • Page 40: Testing Optical Fiber In Auto Mode

    ● Testing time span Note: If “Auto” mode is used, the TP-P6 analyzes the connected fiber, then calculates the setting that best fits the required test(s) to be performed. This automatic calibration generally takes under five (x5) seconds. If the fiber is removed during that time, or the operation is aborted, no test data will be displayed.

  • Page 41: Test The Optical Fiber In Manual Mode

    9.1 Common Parameters for OTDR Testing. You can set the parameters {Meas. Para.} from the [Options] section of the OTDR [Settings] dialog. Please remember that these parameters and settings are only available if there is an OTDR module connected to the TP-P6. Parameter Definition...
  • Page 42 2. Under “Average” mode, the TP-P6 accumulates and averages the testing data according to the time range set by the user. When testing is complete, the results are displayed onscreen.

  • Page 43: Range Configuration

    9 Test the optical fiber in Manual mode 9.5 Range Configuration Setting the range as close as possible to the actual length of the fiber under test will result in far greater accuracy when testing. Range Options: Auto, 1.3km, 2.5km, 5km, 10km, 20km, 40km, 80km, 160km, 240km, etc. Operation: Select the range desired.

  • Page 44: Laser Wavelength Configuration

    9 Test the optical fiber in Manual mode 9.8 Laser Wavelength Configuration The user can select the wavelength to be used for testing, or can select multiple wavelengths to be used simultaneously. Operation: Select the desired wavelength in the “Wavelength” parameter in [Setup]. Note: The available wavelengths will be determined by which module(s) are attached and being used.

  • Page 45: Reflection Threshold (Reflection Detection Threshold) Configuration

    9 Test the optical fiber in Manual mode 9.12 Reflection Threshold (Reflection Detection Threshold) Configuration This configuration has direct impact on reflection events listing. Only reflection events greater than this threshold will be displayed in events list. The threshold range is from -10dB to -65dB Note: The default value is -52.00dB 9.13 End Threshold (Optical Fiber End-Face Detection Threshold)

  • Page 46: Using The Otdr To Test Fttx-Pon Network Optical Fiber Spans

    10 Using the OTDR to Test FTTx-PON Network Optical Fiber Spans FTTx-PON network optical fiber spans are different from normal optical fiber spans. There is a branching aspect to the span. The user needs to be aware of the following, when testing FTTx-PON: 10.1 Using the PON-Optimized OTDR Module Some models are optimized specifically for testing FTTx-PON network optical fiber spans, and can achieve highly accurate trace results.
  • Page 47 Zoom Tools Grid Line Note: ● A bi-directional trace file is too large to be displayed on the TP-P6’s built-in screen.To view a bi- directional file, simply use the data analysis software, which is included with your TP-P6. www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...
  • Page 48 11.4 Trace Display After a trace has been opened, the TP-P6 will display the trace and analysis result in the trace window. The events on the trace will be marked by small icons. These events will be marked and displayed below the corresponding trace.
  • Page 49 ● For easier usage, the position of the Markers will be stored in memory - even when the unit is turned off. When the TP-P6 is turned back on, the user will see the last known Marker positions on the trace appear automatically.
  • Page 50 11 Trace Analysis and Event Operation 11.6 Switch and Move the Marked Point When analyzing loss or reflection events, there will be marked points displayed for additional testing to be performed near the selected Markers. There are various ways to switch or move the marked point(s). The user can use one or all of them to increase efficiency.
  • Page 51 In order to examine an event in greater detail, from within a trace, zooming-in can be useful. The TP-P6 provides two ways to zoom-in on a trace: Method #1: Zoom-in by cross frame, which is the fastest method. This method is fast, but less accurate.
  • Page 52 ● The trace can only be magnified to a certain degree. ● The trace cannot be contracted to more than a 1:1 ratio. ● The TP-P6 will maintain the level of zoom initiated by the user, even when initiating new traces, until the zoom level is changed by the user.
  • Page 53 Note: ● When the user turns off the PRO TP-P6, the zoom settings will not be saved. When the TP-P6 is turned on again, the trace window will display the entire trace threshold. ● When the user changes the wavelength, pulse width and/or time, as long as the distance is not changed, the previously set zoom level will be used.
  • Page 54 11 Trace Analysis and Event Operation 11.13 Moving the Magnified Trace Window After the trace has been magnified, the trace window will only display part of the trace. There are two ways to move the trace window: 1. Using the stylus or mouse to operate in the navigation window. 2.
  • Page 55 Fig 11.2 Event Options The TP-P6 displays many attributes of a trace: ● Type: Different indicators are used for different event types. For detailed information pertaining to specific types of events, please refer to the appropriate sections of this manual.
  • Page 56 11 Trace Analysis and Event Operation 11.14.1 Display the Event on the trace, and locating the event in the Event Table At any time, while scrolling through the event table, the user can check the relative info about all events tested on a particular trace.
  • Page 57 11 Trace Analysis and Event Operation 2. Fill in the event info in the “Add Event” dialog window. Fig 11.4 Add Event Dialog Window 3. Press [Ok] to save and return to the main window after editing is complete. The event will appear in the event list.
  • Page 58 11 Trace Analysis and Event Operation How to Modify an event: 1. Press [Modify] after selecting an event in the events tab. 2. From here the user can alter the event info, replacing any existing data. 3. Press [Ok] to save and automatically return to the main window after editing is complete.
  • Page 59 11 Trace Analysis and Event Operation 11.14.4 Deleting an Event Except for the following events, almost all of the events can be deleted from event table. ● Analysis complete ● Starting point of the span ● End point of the span Note: Once deleted, there is no way to recover deleted trace data.
  • Page 60 11 Trace Analysis and Event Operation 11.15 Analysis Detecting Threshold Configuration In order to optimize the event detection, the user can set the testing thresholds. ● Change a non reflection threshold (Splice Loss Threshold): It can display or hide small non-reflection event ●...
  • Page 61 ● Update an existing event table -if the data has been modified or repairs have been made. To reanalyze a trace: 1. In the [Event] options, press [Analysis]. The TP-P6 will then initiate a new trace. 2. After the analysis is complete, the new results will be displayed in the event table.
  • Page 62 The user can modify or alter trace display options before or after a test or trace is opened. ● Grid line: Select or deselect this to display or hide the grid lines. By default, the TP-P6 is set to display the grid.
  • Page 63 11 Trace and Event Analysis Settings 11.20 Set the length unit In the OTDR parameters setting dialog box, select the length unit in the test display area options. The unit can be set to display in meters, feet or miles. Note: ●...
  • Page 64 11 Trace and Event Analysis Settings The content that the TP-P6 can display is as follows: ● File Name: The name of current trace. ● Date: Date and time of test. ● Wavelength: The laser wavelength used for testing. ● Pulse Width: The laser pulse width used for sampling.
  • Page 65 12 Manual Trace Analysis A user can use Markers and Zoom tools to measure Splice Loss, Attenuation and Reflection, or use Markers to locate Event Position and Relative Power Level. 12.1 To Use Markers Click the {Markers} tab in the OTDR main interface to activate Markers. 12.2 Event Location and Loss Information The OTDR application automatically calculates the event location and displays the location in the Events list.
  • Page 66 12 Manual Trace Analysis 12.3 Measuring Insertion Loss (2-Point and 5-Point method) Insertion Loss (unit: dB) is calculated by measuring the signal level of Rayleigh Back Scatter (RBS) and the magnitude of reduction. Insertion loss can be created by reflection and non-reflection events. The system calculates (in real-time) the loss between Markers A and B, and also calculates the insertion loss at Marker A or B.
  • Page 67 This method also applies to the measurement of point A or B’s Insertion Loss. When the [Loss] button is pressed, the PRO TP-P6 will show the marking points to measure the event loss. When Marker A is selected, the screen will display the 4 marking points related to Marker A. When Marker B is selected, the screen will display the 4 marking points related to Marker B.
  • Page 68 12 Manual Trace Analysis Using the 5-Point Method: 1. In the main interface of the PRO TP-P6 OTDR module, click the “Markers” tab. 2. Press the [Loss] button. Marker A, Marker B and their related marking points will be displayed on the trace.
  • Page 69 12 Manual Trace Analysis 12.4 Measure Attenuation (2-Point and LSA method) 2-Point method measures the attenuation between Marker A and B calculated by all the loss over the distance between Marker A and B (Unit: dB/Km). The LSA (Least-Squares Approximation) method uses linear regressions that is applied to the backscatter before and after an event (Between Marker A and B) to estimate the attenuation in the backscatter resulting from the event’s loss.
  • Page 70 12 Manual Trace Analysis 12.5 Measuring Reflectance Reflectance is the ratio of reflected power (Pr) to incident power (Pi) of an event (such as a connector). Reflectance = 10 log (Pr/Pi). 1. Click the {Markers} tab in the OTDR main interface to show Marker A and B. 2.
  • Page 71 ● For more information, please refer to the Help file on PRO TP-P6. Way 2: User can connect PRO TP-P6 to PC, PRO TP-P6 will be recognized as a mobile device. User can copy, move, rename and delete files in PC’s Windows System.
  • Page 72 4. Click “OK” to exit the disk properties. Note: It is suggested that the user check disk utilization periodically, transferring or backing up files to avoid running out of disk space when the PRO TP-P6 is in use. www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...
  • Page 73 14 Print OTDR Report The User can manage a saved trace file directly on the PRO TP-P6, as well as print a report. For reference and report printing, it is necessary to manage and update the trace information. 14.1 Trace Information After trace acquisition, the user can add or update tested fiber information ,which includes: Cable ID, Fiber ID, Fiber Type, Start Location, End Location and Operator.
  • Page 74 Note: ● An edited and saved trace file can be used as a template for later reference. ● The user can also use the TP-P6 Data Management software to edit and save trace information. 14.3 Print OTDR Report The PRO TP-P6 supports direct printing, via USB.
  • Page 75 A. To print the current file, please choose the “Print current file” option and only one trace will be printed. B. To print unopened traces saved in PRO TP-P6, please check “Batch print” option, which will allow batch printing of up to eight (x8) traces.
  • Page 76 5. Press the [Print] button to start printing. During printing, the system will display the status: “Printing... Pease wait”, as shown in Fig 14.5. Fig 14.5 Printing 6. After printing is complete, the TP-P6 will automatically return to the main interface. www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...

  • Page 77: Vfl Application

    The maximum detection range for the PRO TP-P6 VFL is over 5Km, making it a very useful tool for fiber identification and detection, as well as highlighting breaks, tight bends, splices and/or defective connectors in optical fiber spans.

  • Page 78: Using The Mpn Module

    16 Using the MPN Module 16.1 Main Features of the MPN Module ● Simultaneous display of “Triple-Play” PON signals at 1310, 1490 and 1550nm wavelengths. ● Burst mode 1310nm upstream signal detection & measurement. ● Dual-port, pass-through design. ● Stabilized Laser Source at 1310, 1490, 1550 and 1625nm wavelengths. ●...

  • Page 79: Pon Power Meter Of The Mpn Module

    Switching between different module interfaces is only possible when there are two or more modules. Click the button or Press the (Start/Stop) button on PRO TP-P6 front panel to start the measurement. Click button or Re-Press (Start / Stop) button on the PRO TP-P6 front panel to stop the measurement.
  • Page 80 “Buzzer”: Switch on or off to open/close the alarm buzzer function. With this feature turned on, when the TP-P6 detects a power value beyond the normal range, a buzzer will automatically sound. “Unit”: Switch to select between “W” or “dBm”.
  • Page 81 16 Using the MPN Module Double-click any Threshold Set to modify the settings, as shown in Fig 16.4. Click “OK” to save the new settings. Fig16.4 PON Power Meter- Modify Threshold Set The “Measurement Record” interface is shown as Fig 16.5. Fig 16.5 PON Power Meter - Measurement Record The name will be changed according to the user’s input.

  • Page 82: Stabilized Laser Source Of Mpn Module

    16 Using the MPN Module Fig 16.6 PON Power Meter-Open Click “Save” to save the records. 16.4 Stabilized Laser Source of MPN Module Under “SLS” there are two setting interfaces: “General Setup” and “Reference Setting.” The “General Setup” interface is shown in Fig 16.7 www.PrecisionRatedOptics.com Tel: (888) 545-1254 •...
  • Page 83 P6 front panel to start the measurement. Click the button or Re-Press the (Start/Stop) button on PRO TP-P6 front panel to stop the measurement. Note: The function icon turns red while switching on this function module. The “Reference Setting” interface is shown as Fig 16.8 Fig 16.8 Stabilized Laser Source - Ref.

  • Page 84: Optical Power Meter Of The Mpn Module

    (Start/Stop) button on the PRO TP-P6 front panel to start the measurement. Click the button or re-press the ” (Start/Stop) button on the PRO TP-P6 front panel to stop the measurement. Note: ● The function icon turns while switching on this function module.
  • Page 85 Click the “LTS” icon to enter the “Loss Test” interface, as shown in Fig 16.10. click the button or Press the (Start/ Stop) button on the PRO TP-P6 front panel to start the measurement. Click button, or re-press the (Start/Stop) button on the PRO TP-P6 front panel to stop the measurement.
  • Page 86 Fig. 16.12 The user can directly copy, move, rename and/or delete any image file or folder on the PRO TP-P6. Files can also be exchanged between the PRO TP-P6 and external storage devices, such as a USB flash drive, external hard drive and/or PC.

  • Page 87: File Management

    2. Click the “File Explorer” icon on the {Program} tab to enter File Explorer, where all connected, active drives (including USB drives and folders) are displayed for file management. 3. After a file transfer, the user can directly unplug the USB storage device from the PRO TP-P6. Note: If the USB storage device is not shown in the File Explorer, please close the File Explorer and try again.

  • Page 88: Maintenance And Calibration

    Be cautious of electric shock, and make sure that the A/C power is disconnected from the PRO TP- P6 before cleaning. Always use dry or moist, soft cloth to clean the outside of the PRO TP-P6. Never attempt to clean the inside of the TP-P6. If you suspect that the inside has been contaminated, please contact your local PRO service representative for further instructions.

  • Page 89: Cleaning Procedure

    ● The charging time is subject to the type of functional modules in use, environment, temperature, etc. ● If the TP-P6 sits unused for a long period of time (longer than two months) its capacity may not match the indicated charging status (for example, the charging indicator indicates ”Full” but the PRO TP-P6 may power off, due to a low battery).

  • Page 90: Battery Calibration

    18.12 Shipment The PRO TP-P6 should always be shipped in its original packing materials, if possible. Otherwise, the TP-P6 should be professionally packed for safe shipment. Precision Rated Optics is not liable for damage that may occur during shipping, due to incorrect or inadequate packing procedures.

  • Page 91: Troubleshooting

    ● Replace the battery ● Connect the PRO TP-P6 to external power supply. External power supply is not connected Connect PRO TP-P6 to external power supply. TP-P6 does not power on Make sure external power supply is well connected on External power supply is unplugged both ends.

  • Page 92: Warranty

    To return the PRO TP-P6 in the case of repair, calibration or other recommended maintenance, please note the following: ● Be sure to pack PRO TP-P6 with soft cushion like Polyethylene, so as to protect the shell of PRO TP-P6.
  • Page 93 Please check our web site (www.precisionratedoptics.com) for updates to this manual and additional application information. If you need technical or sales support, please contact your local Precision Rated Optics Customer Service Center, shown below: Precision Rated Optics, Inc. Product Distribution Center Manufacturing &...
  • Page 94 Precision Rated Optics, Inc. Corporate Office Billing & Processing PO Box 877 Trexlertown, PA 18087 Precision Rated Optics, Inc. Product Distribution Center Manufacturing & Testing 9999 Hamilton Blvd Breinigsville, PA 18031...
