V1.2
RUNGU Dualie Owner Manual – 2020 model year
®
TM
Rungu
Dualie
owner manual
1
Congratulations on purchasing a Rungu Dualie
! You own the latest generation of the ultimate electric
alternative to a Quad ATV for off-road utility and fun. Before you ride, please read the following
instructions carefully.
Rungu Dualie uses the Bafang BBSHD mid-drive motor with a custom Rungu 52V (nominal voltage) input
that generates more than 1.4kW of mechanical power for off-road use. You access the power by
pedaling ("Pedal Assist") or pressing the thumb throttle. In "Pedal Assist," the Dualie senses when you
start to pedal and engages the motor to assist your pedaling - you don't have to use the throttle if you
don't want to. The amount of power assist varies based on the power level you select as you ride.
Unless you have ordered your Dualie with Class 1 or Class 2 reprogramming, we ship the Dualie
configured with five selectable power levels starting with very little assistance up to full power, which is
intended for use off-road only. The power settings are discussed below.
Note: US Federal Law mandates a 750W/20 MPH limit for riding an e-bike on public roads without a
license. Please check with your local government to ensure you follow all local laws and ordinances.
Standard Bearer Machines are not liable for those who choose not to follow their local laws.
CAUTION: STANDARD BEARER MACHINES WILL NOT BE HELD RESPONSIBLE FOR PEOPLE WHO CHOOSE
TO DISREGARD THE LAW!
WARNING: IMPORTANT- STANDARD BEARER MACHINES WILL NOT BE LIABLE FOR ANY DAMAGE OR
INJURY THAT MAY OCCUR DUE TO OPERATION OF YOUR DUALIE. BY USING THE DUALIE, YOU ARE
AGREEING TO STANDARD BEARER MACHINES TERMS AND CONDITIONS AND THE WARNINGS AND
CONDITIONS OF THE GENERIC BIKE MANUAL WHICH ARE INCLUDED WITH OTHER LINKS ON THE
MANUAL GUIDE THAT COMES WITH THIS PRODUCT.
Standard Bearer Machines, LLC (Standard Bearer Machines) thanks you for your purchase!
1
As the owner, you agree and are bound by all sales and transfer conditions as defined in "SBM Rungu Sales Terms
and Conditions US 2020." Copies of these documents are available on the list of electronic document links that
ship with the product or upon request by e-mailing sales@riderungu.com.
Copyright 2020 Standard Bearer Machines, LLC
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dualie and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rungu Dualie

Summary of Contents for Rungu Dualie

  • Page 1 Standard Bearer Machines, LLC (Standard Bearer Machines) thanks you for your purchase! As the owner, you agree and are bound by all sales and transfer conditions as defined in “SBM Rungu Sales Terms and Conditions US 2020.” Copies of these documents are available on the list of electronic document links that ship with the product or upon request by e-mailing sales@riderungu.com.

  • Page 2: Table Of Contents

    Battery Failure Response Procedure ....................46 Operating the Dualie ........................... 47 Charging Your Main Battery without removing the battery– Dualie (single battery version only) ..47 Charging your Main Battery after removing the battery– Dualie (single battery version only) ..... 51 Charging Dual Batteries without removing the batteries –...
  • Page 3 After Each Ride ............................81 Battery Care ............................81 Storage When Not Using Dualie for Periods of Two Weeks or Longer ........... 81 Prolonging the Life of your Battery – Best Practices ................82 Chain Maintenance – Cleaning and Lubrication every 40 miles of hard use .......... 82 Maintenance –...
  • Page 4 V1.2 RUNGU Dualie Owner Manual – 2020 model year Troubleshooting ............................97 Electrical ..............................97 Motor and System Performance ......................98 Mechanical .............................. 99 Getting more information ......................... 100 Copyright 2020 Standard Bearer Machines, LLC...

  • Page 5: Rungu Dualie Parts Identification

    V1.2 RUNGU Dualie Owner Manual – 2020 model year RUNGU Dualie parts identification The following images show the names of various components on a Rungu Dualie Figure 1 Left Side View Figure 2 Right Side View Copyright 2020 Standard Bearer Machines, LLC...
  • Page 6 V1.2 RUNGU Dualie Owner Manual – 2020 model year Figure 3 Steering assembly view – NOTE Display now located on center bar Figure 4 Parking Brake View Copyright 2020 Standard Bearer Machines, LLC...

  • Page 7: Unpacking And Assembly Instructions

    If you intend to ship or return your Rungu, please keep all packing materials. 1. If you have purchased a model with a Rungu Cargo Rack or an optional Cargo Rack, remove the rack and place it to one side.
  • Page 8 Presta adapters, keys and pedals as well as other accessories that come with the specific model you ordered. Note: If you purchased a Dualie XR (eXtended Range) with dual batteries or a Dualie with the optional Cargo Rack, remove the rack first and place it to the side.
  • Page 9 V1.2 RUNGU Dualie Owner Manual – 2020 model year 6. Use the 5mm hex wrench to loosen the handlebar retention screws as shown below 7. Slide the right handlebar into the handlebar clamp. Copyright 2020 Standard Bearer Machines, LLC...
  • Page 10 V1.2 RUNGU Dualie Owner Manual – 2020 model year 8. Insert the RIGHT-side handlebar so that it extends at least 45 mm or 1 ¾” past the inside of the stem. CAUTION: FAILURE TO EXTEND THE HANDLEBAR AS SHOWN MAY RESULT IN WHEELS MAKING CONTACT WITH FORKS, WHICH CAN LEAD TO FORK OR TIRE DAMAGE.
  • Page 11 V1.2 RUNGU Dualie Owner Manual – 2020 model year 9. Fasten, but do not tighten handlebar retention screws 10. Slide the Left handlebar into the handlebar clamp. Copyright 2020 Standard Bearer Machines, LLC...
  • Page 12 V1.2 RUNGU Dualie Owner Manual – 2020 model year 11. Check that the left handlebar extends at least 45 mm or 1 ¾” past the stem. 12. Tighten both sets of handlebar retention screws so that you can still rotate each handlebar inside the stem.
  • Page 13 V1.2 RUNGU Dualie Owner Manual – 2020 model year 14. When you have aligned each handlebar, use a crossing pattern (shown below) of tightening the upper handlebar retention screw and then bottom screw instead of tightening both top screws and then the bottom screws for each clamp.
  • Page 14 V1.2 RUNGU Dualie Owner Manual – 2020 model year Copyright 2020 Standard Bearer Machines, LLC...
  • Page 15 V1.2 RUNGU Dualie Owner Manual – 2020 model year 16. Mount the keypad onto the left handlebar and slide the keypad near the throttle. Copyright 2020 Standard Bearer Machines, LLC...
  • Page 16 V1.2 RUNGU Dualie Owner Manual – 2020 model year 17. Reinsert the retention screw and tighten so the keypad doesn’t rotate on the handlebar. 18. Open the accessory box to remove the two quick release skewers from the packaging. 19. Select which wheel will be the right-side wheel and the left-side wheel. Often, the wheels will be labeled “Left”...
  • Page 17 V1.2 RUNGU Dualie Owner Manual – 2020 model year 20. Remove the two quick release skewers from the accessories box. Unscrew the end cap nut from the quick-release skewers and remove one of the two conical springs for each skewer.
  • Page 18 V1.2 RUNGU Dualie Owner Manual – 2020 model year 22. Replace the conical washer (small end first) on the other side of the wheel. Screw the end cap on a few turns to ready the wheel for installation. 23. Prep the RIGHT wheel. Insert the other skewer into the RIGHT wheel from the side OPPOSITE to the brake disc as shown below.
  • Page 19 V1.2 RUNGU Dualie Owner Manual – 2020 model year 24. Replace the conical washer (small end first) on the other side of the wheel. Screw on the end cap with a few turns to ready the wheel for installation. 25. Get the bike ready to mount the front wheels by making sure the parking brake is off (which is the way the bike ships).
  • Page 20 V1.2 RUNGU Dualie Owner Manual – 2020 model year 27. The ends of the axle will sit in the fork “dropouts” when correctly aligned. You may have to unscrew the end cap a turn or two if the fork doesn’t drop in place.
  • Page 21 V1.2 RUNGU Dualie Owner Manual – 2020 model year 29. The ends of the axle will sit in the fork “dropouts” when correctly aligned. You may have to unscrew the end cap a turn or two if the fork doesn’t drop in place.
  • Page 22 V1.2 RUNGU Dualie Owner Manual – 2020 model year 31. Tighten the end cap nut on the RIGHT wheel and close the quick-release lever. As a guideline the end cap nut should begin to clamp onto the fork drop out when the lever points away from the wheel at a right angle.
  • Page 23 V1.2 RUNGU Dualie Owner Manual – 2020 model year 32. Remove the pedals from the box and install the RIGHT Pedal first – the RIGHT pedal is marked with an “R” as shown below. 33. Use your fingers to thread the pedal shaft by inserting the threaded shaft into the crank arm.
  • Page 24 V1.2 RUNGU Dualie Owner Manual – 2020 model year 34. Use a 6mm Hex wrench to tighten the pedal once the pedal is fully inserted. 35. Install the LEFT Pedal next – LEFT pedal is marked with an “L” as shown below.
  • Page 25 V1.2 RUNGU Dualie Owner Manual – 2020 model year 36. Use your fingers to thread the pedal shaft by inserting the threaded shaft into the crank arm. Then hold the threaded section of the pedal in the crank arm mounting hole and spin the entire crank arm in a clockwise motion as depicted below.
  • Page 26 Note: Tire pressure plays an especially important role in how you enjoy your Rungu Dualie. If you plan to ride mostly on soft ground like sand or snow, use a tire pressure of 5 (34 kPa) for best traction and control as well as minimizing tread wear.

  • Page 27: Additional Installation Instructions - Mud Flaps

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Additional Installation Instructions – mud flaps 1. Remove the mud flaps from packaging along with their screws and retention nuts. Remove the retention nut from each screw. Copyright 2020 Standard Bearer Machines, LLC...
  • Page 28 V1.2 RUNGU Dualie Owner Manual – 2020 model year 2. Align the mounting slot on the first mud flap with the back of the front fork. Install the screw from the front of the fork as shown below. 3. Thread the nut onto the back of the screw behind the mounting slot.
  • Page 29 V1.2 RUNGU Dualie Owner Manual – 2020 model year 4. Use an adjustable wrench to secure the nut. Use a 5mm hex wrench to continue threading the nut onto the screw Copyright 2020 Standard Bearer Machines, LLC...
  • Page 30 V1.2 RUNGU Dualie Owner Manual – 2020 model year 6. Before fully tightening the nut, slide the mud flap vertically until the bend in the mud flap rises just above the lip on the back of the fork as shown below.

  • Page 31: Additional Installation Instructions - Rungu Cargo Rack With Or Without Range-Extending Battery

    Additional Installation Instructions – Rungu Cargo Rack with or without range-extending battery. 1. If you are assembling the Dualie XR, use the keys provided to open the access door to the rear battery and remove the battery from the rack at this time.
  • Page 32 V1.2 RUNGU Dualie Owner Manual – 2020 model year 4. Align the holes in the tab at the bottom left side of the rack with the fastening location on the left side metal rack support. Thread an M8 screw and washer through the tab and into the rack support.
  • Page 33 V1.2 RUNGU Dualie Owner Manual – 2020 model year 5. Align the holes in the tab at the bottom right side of the rack with the fastening location on the right-side metal rack support. Thread an M8 screw and washer through the tab and into the rack support.
  • Page 34 PINCHING THE WIRE HARNESS BETWEEN THE RACK AND THE LEFT SIDE OF THE FRAME WHEN TIGHTENING FASTENERS. Note: If you have the standard Rungu Cargo Rack, your rack installation is complete. Continue to step 8 if your Rungu Cargo Rack includes the range-extending battery.
  • Page 35 V1.2 RUNGU Dualie Owner Manual – 2020 model year 9. Push all three connectors into the battery compartment. 10. Working from the inside and the outside of the rack squeeze the grommet on the harness into place so that it covers the entire hole in the battery case and secures the cable harness.
  • Page 36 12. Connect the largest connectors together – This plug and socket connect the rear battery and the Rungu Battery Link making the front and rear batteries work together to extend your practical range. The pigtail connector remains disconnected (and may be covered with electrical tape).
  • Page 37 V1.2 RUNGU Dualie Owner Manual – 2020 model year 13. Use the zip-ties provided to fasten the wire harness to the rack in at least two places. Keep the grommet above the zip-tie locations. Clip and remove the zip-tie tails after you’ve tightened the zip-ties.

  • Page 38: Additional Installation Instructions - Pannier Bags

    RUNGU Dualie Owner Manual – 2020 model year Additional Installation Instructions – Pannier Bags. If you purchased the Dualie Rugged or Dualie XR Rubicon Trail Edition or you added pannier bag mounts as an accessory, mounting and removing pannier bags has never been easier.
  • Page 39 V1.2 RUNGU Dualie Owner Manual – 2020 model year 2. Adjust the upper quick-release catches using the adjustment knobs so that the catches fit between the two upper mounting blocks. 3. Push down on the pannier while pulling up on the quick release strap. This opens the two catches so that they engage the upper mounting tube.
  • Page 40 V1.2 RUNGU Dualie Owner Manual – 2020 model year 4. Lower the pannier onto the upper mounting tube and let go of the quick release strap. This locks the pannier in place. Copyright 2020 Standard Bearer Machines, LLC...

  • Page 41: Cautions And Safety

    Cautions and Safety General Cautions and Warnings The Rungu Dualie is an electric vehicle that you can ride like a bicycle with the added benefit of more stability on soft ground and difficult terrain. For all bicycle riding cautions and warnings, refer to the...

  • Page 42: Battery Safety

    Each battery has a Battery Management System (BMS) built into the battery to protect you and the Rungu from dangerous battery faults. Lithium cells have a lot of energy stored in a small package. There is always a possibility a battery cell fault can release this energy and can cause fire and/or severe injury unless the battery is constantly monitored during discharging and charging.
  • Page 43 V1.2 RUNGU Dualie Owner Manual – 2020 model year CAUTION: CHARGING ON A CONCRETE FLOOR, SUCH AS IN A GARAGE, AWAY FROM DEBRIS AND MATERIAL IS ALWAYS RECOMMENDED AS A SAFETY PRECAUTION. Copyright 2020 Standard Bearer Machines, LLC...

  • Page 44: Battery Safety Precautions

    IMMEDIATELY. Turn off the Dualie and inspect your battery system. Check for a burnt smell and inspect there are no melted or shorted wires. Shorted wires or a burnt smell indicate a shorted or failed BMS, stop using Rungu and contact us as soon as possible.

  • Page 45: Battery Safety (In Depth)

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Battery Safety (In Depth) Main reasons a battery packs fail Battery packs can fail when the BMS fails or is over-ridden allowing the following to occur: • Short-circuit • Over-charging – voltage higher than tolerated by cells •...

  • Page 46: Battery Failure Response Procedure

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Battery Failure Response Procedure WARNING: IF THERE IS A FIRE, STAY AWAY FROM THE SMOKE, FUMES AND FLAMES. CONTACT LOCAL FIRE AUTHORITIES TO PUT OUT THE FIRE. • Monitor the temperature from a safe distance using a non-contact thermometer or thermal imager •...

  • Page 47: Operating The Dualie

    RUNGU Dualie Owner Manual – 2020 model year Operating the Dualie NOTE: Your Dualie ships with the batteries partially discharged to allow longer storage. Before riding, fully charge the battery or batteries prior to your first ride. Charging Your Main Battery without removing the battery– Dualie (single...
  • Page 48 V1.2 RUNGU Dualie Owner Manual – 2020 model year 2. Unscrew the battery charging port access cover on the right side of the battery case 3. Remove the cover and place it in a location where it won’t get lost...
  • Page 49 V1.2 RUNGU Dualie Owner Manual – 2020 model year 4. Plug the charger plug to the connector extended from the battery. The connector is keyed, so there is only one way that the plug will fit. NOTE: You may hear a “pop” sound when you plug in the charger that comes from a spark that occurs inside the connectors when the two connectors mate.
  • Page 50 V1.2 RUNGU Dualie Owner Manual – 2020 model year 7. Disconnect the charger connector and replace the battery charge cover by screwing the cover back onto the outlet. Copyright 2020 Standard Bearer Machines, LLC...

  • Page 51: Charging Your Main Battery After Removing The Battery- Dualie (Single Battery Version Only)

    Charging your Main Battery after removing the battery– Dualie (single battery version only) 1. If the ambient temperature surrounding your Dualie is below 32⁰ F (0 C) and you want to charge your Main Battery indoors, you can remove the battery and charge it indoors. Use the keys supplied with your Dualie to unlock the battery case from the front.
  • Page 52 SAFE DISTANCE TO MAKE SURE ALL IS O.K. GIVE US A CALL/EMAIL US IMMEDIATELY IF A BATTERY BEGINS TO PUFF, AND CONTACT RUNGU FOR GUIDANCE ON THE NEXT STEPS. DO NOT ATTEMPT TO USE A BATTERY AFTER IT HAS SWELLED AND EXPANDED OR “PUFFED”...
  • Page 53 V1.2 RUNGU Dualie Owner Manual – 2020 model year a full charge so that you do not deplete your batteries too far when you ride. It is better in the long run to use less than 80% capacity of the battery when riding if possible .
  • Page 54 WARNING: TAKE CARE TO PLACE THE CHARGING CABLE AWAY FROM THE LATCH TO AVOID DAMAGING THE CABLE AND SHORTING THE BATTERY. BATTERIES FROM SHORTED CABLES AND SEVERED BATTERY CABLES ARE NOT COVERED BY YOUR RUNGU WARRANTY. GOOD - cables positioned away from cover BAD - Cables will be pinched by cover 8.

  • Page 55: Charging Dual Batteries Without Removing The Batteries - Dualie Xr

    Charging Dual Batteries without removing the batteries – Dualie XR WARNING: REMOVE YOUR BATTERY AND CHARGE IT INDOORS IF YOUR RUNGU DUALIE IS STORED AT A TEMPERATURE OF 32⁰ F (0⁰ C) OR LOWER. CHARGING THE BATTERY IN AN AMBIENT TEMPERATURE OF 32⁰...
  • Page 56 V1.2 RUNGU Dualie Owner Manual – 2020 model year 2. Access the charger connectors. Use the keys supplied with your Dualie to unlock the battery access door on top of the Rungu Cargo Rack. Caution: The battery has padding inside of the rack to minimize shock and vibration;...
  • Page 57 SAFE DISTANCE TO MAKE SURE ALL IS O.K. GIVE US A CALL/EMAIL US IMMEDIATELY IF A BATTERY BEGINS TO PUFF, AND CONTACT RUNGU FOR GUIDANCE ON THE NEXT STEPS. DO NOT ATTEMPT TO USE A BATTERY AFTER IT HAS SWELLED AND EXPANDED OR “PUFFED”...
  • Page 58 WARNING: TAKE CARE TO PLACE THE CHARGING CABLE AWAY FROM THE LATCH TO AVOID DAMAGING THE CABLE AND SHORTING THE BATTERY. BATTERIES FROM SHORTED CABLES AND SEVERED BATTERY CABLES ARE NOT COVERED BY YOUR RUNGU WARRANTY. GOOD - cables placed away from door and key latch BAD - cables obstruct door closure 10.

  • Page 59: Removing Dual Batteries For External Charging - Dualie Xr

    Rungu Dualie 1. Make sure each of your dual battery chargers are set to the correct voltage for your country’s power requirement.
  • Page 60 3. To remove the battery, lift the battery up from the front and lift the battery out of the Rungu Cargo Rack. Disconnect the large yellow connector connecting the battery to the extension cable. Be careful not to drop the battery. To remove the Main Battery, follow the directions in the Charging your Main Battery after removing the battery–...
  • Page 61 Main Battery Case. Then replace the battery inside the Main Battery Case according to the directions in the Charging your Main Battery after removing the battery– Dualie (single battery version only) section earlier in this document.
  • Page 62 WARNING: TAKE CARE TO PLACE THE CHARGING CABLE AWAY FROM THE LATCH TO AVOID DAMAGING THE CABLE AND SHORTING THE BATTERY. BATTERIES FROM SHORTED CABLES AND SEVERED BATTERY CABLES ARE NOT COVERED BY YOUR RUNGU WARRANTY. GOOD - cables placed away from door and key latch BAD - cables obstruct door closure 15.

  • Page 63: Inflating Tires - Using Presta Valve Adapters

    “Schraeder” or “English Valves” (standard on car tires). Some bicycle pumps come with Presta valve adapters built into the pump outlet, but many do not. Rungu ships Dualie Standard, Dualie Steep and Dualie XR bikes with a “screw-on” adapter. Rungu ships the Dualie Rugged and Dualie XR Rubicon Trail edition units with the Cycplus portable tire pump;...
  • Page 64 V1.2 RUNGU Dualie Owner Manual – 2020 model year 3. Screw on the Presta valve adapter. 4. Connect the bike tire pump and inflate tire to the pressure appropriate for where you’re riding – as recommended in the before you ride section of this document.
  • Page 65 V1.2 RUNGU Dualie Owner Manual – 2020 model year 5. Remove the bike tire pump and unscrew the Presta valve adapter. Put the valve adapter in a safe place; they are easy to lose. Caution: Do not leave the Presta valve in place. The captive nut needs to be re-fastened to retain tire airpressure.

  • Page 66: Before You Ride - Safety Check

    2010." Wear a helmet. 2. Make sure the stems are tightly clamped to your forks. To do this, stand in front of the Rungu astride the left wheel facing the steering assembly. Hold both handlebars and try to turn the steering.
  • Page 67 WARNING: TAKE CARE TO PLACE THE CHARGING CABLE AWAY FROM THE LATCH TO AVOID DAMAGING THE CABLE AND SHORTING THE BATTERY. BATTERIES FROM SHORTED CABLES AND SEVERED BATTERY CABLES ARE NOT COVERED BY YOUR RUNGU WARRANTY. Copyright 2020 Standard Bearer Machines, LLC...
  • Page 68 15 PSI (103 KPa). Note: Tire pressure plays an especially important role in how you enjoy your Rungu DUALIE. If you plan to ride mostly on soft ground like sand or snow, use a tire pressure between 5 (34 kPa) and 6 PSI (41 kPa) for best traction and control as well as minimizing tread wear.

  • Page 69: Using The Control Keypad And Understanding The Dashboard

    The keypad has the on and off switch, controls the power output level of the motor, turns the (optional) Rungu E-Light on and off, and sets up the display settings. This section provides an overview of the controls that gives you enough information to operate your Dualie.
  • Page 70 “relaxes” and returns to its unloaded voltage. The e-Light status changes when you turn on the optional Rungu E-Light. When you turn on the optional Rungu E-Light, the image of the headlight appears and the screen dims for night-time riding. You can also set the light to turn on automatically in low-light situations.

  • Page 71: Accessing The Display Settings

    Turning off Dualie Use the on/off key to turn off Dualie. Dualie also turns off if left idle for a few minutes. Display settings control the amount of time in minutes.

  • Page 72: Push Assistance

    Walk assistance Dualie can also help you push if you are walking alongside. Hold the “-“ key down for more than two seconds; the motor turns and will help you push Dualie at approximately 3 miles per hour – walking pace.

  • Page 73: Riding The Rungu Dualie

    The same holds true with Dualie. Dualie has 9 gears – first gear has the largest sprocket on the rear wheel; ninth uses the smallest. First gear has the lowest gear ratio between the motor and the rear wheel. This gear is used for hill climbing or crossing the most difficult soft terrain.

  • Page 74: Understanding And Changing Dualie Power Level

    DUALIE motor in this way. If you’re operating DUALIE on flat paved roads, using level 2 or 3 is adequate to maintain a speed of 10 mph with minimal effort.

  • Page 75: Power Level And Gear Combination Guidelines

    As noted, you can also set the number of power levels to be three or nine. Here are the power output tables for these levels. If you purchased your Dualie configured as a Class 1 or Class 2 e-bike, you’ll find the output to be half what is displayed above.

  • Page 76: Problems Resulting From Not Following Gear Shifting And Power Level Guidelines

    LEVEL 4 OR 5 AND HILL CLIMBING MAXIMIZES CHAIN WEAR AND MAY RESULT IN A BROKEN CHAIN, BENT CASSETTE COGS OR BOTH. THE DUALIE USES A CHAIN DESIGNED FOR THE OUTPUT OF THE MOTOR, HOWEVER REPEATED GEAR CHANGES AT THE HIGHER POWER LEVELS GENERATES VERY HIGH FORCE AND CAN BREAK A LINK.

  • Page 77: Rungu Dualie Operation Cautions

    Same cog after three miles of acceleration from a full stop in 10 gear using power level 5. Note tooth damage. Also prior Shimano version of Cassette. For detailed information on how to change Display settings, refer to the “Rungu MDV Display User Guide” that you can find online at this link.

  • Page 78: Riding Safety

    As with steep hills, changing gears under load may cause the chain to break or the sprockets in the cassette to bend. Note: Always ride Dualie at a level and speed you are comfortable with. If you’re uncomfortable with the terrain, walk the bike.

  • Page 79: Adjusting The Front Suspension

    To operate the switch, hold in the brake lever as hard as you can and flip the switch. The switch holds the brake lever in place, which holds the rotor in place and prevents Dualie...

  • Page 80: Using The Microshift Derailleur Clutch

    V1.2 RUNGU Dualie Owner Manual – 2020 model year from moving when parked. The parking brake is very useful when parking on angle. REMEMBER to switch off the parking brake before riding. Engaging either front or rear brake disables the motor.

  • Page 81: Rungu Dualie Maintenance, Care And Repair

    Standard Bearer Machines selected these batteries and the electrical system to be as maintenance free as possible. In the event you plan to not use the Dualie for a period of more than three weeks, open the battery case (or cases), disconnect the battery from both connectors, and remove the battery(ies) and store it (them) with ~50% charge (around 50-52V).

  • Page 82: Prolonging The Life Of Your Battery - Best Practices

    Prolonging the Life of your Battery – Best Practices The Dualie features powerful, lightweight and high-performing batteries. NMC based systems should expect around 3-5 years of use depending on how you take care of your battery and up to 800 charge cycles.

  • Page 83: Maintenance - After Strenuous Rides, And Every 500 Miles Or Six Months

    V1.2 RUNGU Dualie Owner Manual – 2020 model year After using the degreaser, empty the reservoir in the chain cleaner and fill it with water and run the chain cleaning mechanism over the chain again to remove the degreaser. Wipe and dry the chain with a new rag.

  • Page 84: Securing Your Dualie

    Rear wheel removal or replacement You may have to remove the rear wheel to fix a flat, replace the tire or replace the cassette. The Dualie uses a wheel rotation sensor to calculate and display your speedometer. The sensor may be dislocated...

  • Page 85: How To Remove The Rear Wheel

    How to remove the rear wheel 1. First, shift the rear wheel into 9 gear. Whether or not the chain is on the Rungu, shifting to 9 gear before wheel removal makes wheel removal easier. 2. If possible, find an object (e.g. empty bucket, cardboard box) that you can use to support the bike after the rear wheel is removed.
  • Page 86 V1.2 RUNGU Dualie Owner Manual – 2020 model year 3. Switch off the derailleur clutch by pushing down on the switch so it aligns with the white circle. 4. Release the quick release lever Copyright 2020 Standard Bearer Machines, LLC...
  • Page 87 V1.2 RUNGU Dualie Owner Manual – 2020 model year 5. Loosen the quick release skewer by unscrewing the end cap. Be careful to not lose the springs or other components of the skewer if you remove the end cap. 6. The wheel will drop out and the cassette will get caught on the derailleur pulley.

  • Page 88: How To Replace The Rear Wheel

    V1.2 RUNGU Dualie Owner Manual – 2020 model year How to replace the rear wheel 1. Make sure that the Derailleur clutch switch is OFF and that the derailleur is shifted into 9 gear. Lift the rear of the frame and position the rear wheel underneath and pull back on the derailleur so you can orient the chain around 9 gear on the cassette.
  • Page 89 V1.2 RUNGU Dualie Owner Manual – 2020 model year 42. Make sure the wheel axle is seated in the left and right dropouts and then tighten the quick release end cap. As a guideline the end cap nut should begin to clamp onto the left drop out when the quick release lever points away from the wheel at a right angle.
  • Page 90 5. After checking that the rear wheel is fastened tightly, switch on the derailleur clutch and test ride the Rungu for more than five minutes to make sure the speedometer is working. Continue to the section Wheel Speed Sensor Alignment, if not.

  • Page 91: Wheel Speed Sensor Alignment - "Error 21

    1. Check that the sensor is in place. It is found under the right side chain stay. Check the image below and verify the same sensor is on your Dualie. If not contact Rungu or go online to obtain a replacement sensor.
  • Page 92 RUNGU Dualie Owner Manual – 2020 model year 3. Check the picture below and verify your rear wheel has a magnet attached to one spoke. If you cannot find the magnet on one of the spokes, reorder one from Rungu or other sources online before proceeding.
  • Page 93 V1.2 RUNGU Dualie Owner Manual – 2020 model year 5. To realign the speed sensor, us wire cutters to clip the zip ties supporting the speed sensor mount and remove them from the speed sensor mount. 6. Thread new zip ties into the speed sensor mount.
  • Page 94 V1.2 RUNGU Dualie Owner Manual – 2020 model year 9. Tighten the zip ties and ensure that the sensor remains aligned with the magnet. 10. Finally, extend the head of the sensor so there is less than an 1/8” (3mm) between the sensor surface and the magnet surface.

  • Page 95: Technical Information

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Technical Information Default Display Settings Units: Imperial Brightness: 100% MAX PAS: 5 Auto Off: 2 minutes Power View: Power SOC View: % Trip Reset: No AL Sensitivity: Off Password: None Dimensions...

  • Page 96: Performance

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Performance Electrical Copyright 2020 Standard Bearer Machines, LLC...

  • Page 97: Troubleshooting

    (large yellow connectors) and then reconnecting the battery. In most cases, this action is sufficient to “wake up” the battery so it will charge again. If this action fails to work, contact Rungu. Problem: I cannot get my battery to charge or my charger is not working The green light stays on when I know the battery is discharged or no light turns on at all when I plug the battery into the charger.

  • Page 98: Motor And System Performance

    Solution: 1. Check that the speed sensor is in place and connected. When you turn on DUALIE, a red light on the end of the sensor should light. If not, 2. Refer to the section “Wheel speed sensor...

  • Page 99: Mechanical

    V1.2 RUNGU Dualie Owner Manual – 2020 model year Mechanical Problem: I hear a clicking noise when I’m pedaling in every gear; gear changes take long or are difficult The rear derailleur may be misaligned or bent, or the chain may be worn out.

  • Page 100: Getting More Information

    If the derailleur, hanger and frame are intact, 4. Contact Rungu Support if you have other questions. Getting more information Thank you again for purchasing a Rungu Dualie. For further questions, please consult the Support Page on the riderungu.com website or email support@riderungu.com.

This manual is also suitable for:

MdvDualie 2020

Table of Contents
