3. Remote Electronics Mounting (remote mount
only). If you have a remote mounted XMT900
electronics, mount the XMT900 electronics to either
a wall or to a 2" pipe system using the enclosed
mounting system. If you have a local mount, go to
step 5.
7. Final Steps. Complete the SIL requirements and
register your device. Reference the Safety Manual for
the Safety Instrumented System (SIS) and PanaFlow HT
User's Manual for exact details.
GE
Measurement & Control
PanaFlow HT
Ultrasonic Liquid Flowmeter
Safety Manual for SIS
4. Remote Transducer Wiring (remote mount
only). To make electrical connections, remove the
terminal board from the enclosure by first loosening
the screws and twisting the terminal board counter
clockwise. Feed each cable through a conduit hole on
the side of the enclosure and plug into the appropriate
connection on the terminal board.
8. If you have any questions about your equipment,
please contact us at:
Telephone: +1 978 437 1000
E-mail: custcareboston@ge.com
Address: 1100 Technology Drive
Flow
http://www.ge-mcs.com/en/contact-us.html
917-025 Rev. A
January 2012
Billerica, MA 01821-4111
