  • Page 1 ® DataMan 70 Series Quick Reference Guide 2020 October 05 Revision: 6.2.1.1...

  • Page 2: Product Overview

    Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.
  • Page 3 Illumination LEDs LED aimers Mounting holes Good/bad read indicator USB type-C port DataMan 70 Accessories ACCESSORIES FOR DM70 Sealed USB type C cable to USB type DMA-STCBLE-IP65-25 A straight 2.5m Sealed USB type C cable to USB type DMA-STCBLE-IP65-36 A straight 3.6m Sealed USB type C cable to USB type DMA-RTCBLE-IP65-25 A angled 2.5 m...
  • Page 4 Sealed Serial I/O Adapter cable with DMA-SERIAL-IP65-ST straight USB type C connector Sealed Serial I/O Adapter cable with DMA-SERIAL-IP65-RA angled USB type C connector DM70-UBRK-000 Universal Mounting Bracket DM100-PIVOTM-00 Pivot Mounting Bracket Logistics Bracket DMA-BKT-LGS Value Line Bracket DMA-BKT-70-VAL Industrial Ethernet connection module DMA-EZCCM-001 EZCCM to USB cable DMCB-EZCCM-USB-03...
  • Page 5 DM100-IOBOX-000 DataMan Basic I/O Module...

  • Page 6: Dimensional Drawings

    Dimensional Drawings...

  • Page 7: Field Of View And Reading Distances

    Field of View and Reading Distances Horizontal Field of View values DM72 Short Range: 31 DM72 Short Range: 50 DM72 Short Range: 82 DM70 Long Range: 115 mm [1.2 in] mm [1.9 in] mm [3.2 in] mm [4.5 in] DM70 Short Range: 29 DM70 Short Range: 47 DM70 Short Range: 76 DM72 Long Range: 123...
  • Page 8 DM70 Long Range: 144 DM70 Long Range: 170 DM70 Long Range: 279 DM70 Long Range: 370 mm [5.6 in] mm [6.7 in] mm [10.9 in] mm [14.5 in] DM72 Long Range: 153 DM72 Long Range: 181 DM72 Long Range: 297 DM72 Long Range: 394 mm [6.0 in] mm [7.1 in]...
  • Page 9 Distances in mm/ Distances in mm/ 2D min. code 1D min. code Device 6.2 mm lens 6.2 mm lens Long Range Long Range 10 MIL 5 MIL 12 MIL 6 MIL 15 MIL 6 MIL DM72 20 MIL 10 MIL 25 MIL 15 MIL 1000 50 MIL...
  • Page 10 Horizontal Field of View values DM70: 22 mm DM70: 43 mm DM70: 54 mm DM70: 64 mm DM70: 106 DM70: 142 DM70: 283 [0.87 in] [1.7 in] [2.1 in] [2.5 in] mm [4.1 in] mm [5.6 in] mm [11 in] DM72: 24 mm DM72: 45 mm DM72: 58 mm...

  • Page 11: Connecting The Reader

    DM70: 14 mm DM70: 27 mm DM70: 34 mm DM70: 41 mm DM70: 68 mm DM70: 90 mm DM70: 180 [0.55 in] [1.1 in] [1.3 in] [1.6 in] [2.7 in] [3.5 in] mm [7.1 in] DM72: 18 mm DM72: 34 mm DM72: 43 mm DM72: 51 mm DM72: 85 mm...

  • Page 12: Installation

    Installation procedures and specifications are presented in detail in the DataMan Reference Manual, which is installed with the DataMan Setup Tool. From the Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software vx.x.x > Documentation.
  • Page 13 Note: If a standard component is missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. Mounting Mounting the DataMan 70 at a slight angle (15°) can reduce reflections and improve reader performance. Having a recess for screw heads on the top and the bottom, DataMan 70 allows for upside down mounting.
  • Page 14 1. After installing the software, connect the DataMan 70 Series reader to your 2. Launch the DataMan Setup Tool and click Refresh. 3. Select your DataMan 70 reader from the list and click Connect. DataMan 70 Series Specifications 43 g (without cable)
  • Page 15 DataMan 70 Series Imager Specifications Specification DataMan 70 Imager DataMan 72 Imager Image Sensor 1/3 inch CMOS 1/3 inch CMOS Image Sensor 4.51 mm x 2.88 mm (W x H), 6.0 μm 4.86 mm x 3.66 mm (W x H), 3.75µm...
  • Page 16 Please read these guidelines carefully before using your device. Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Safety and Regulatory...

  • Page 17: Led Safety Statement

    2014/30/EU Electromagnetic Compatibility Directive. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked.
  • Page 18 This product has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment, if not properly disposed. In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal.
  • Page 19 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
  • Page 20 Copyright © 2020 Cognex Corporation. All Rights Reserved.
