Summary of Contents for CARRON ECO 5KW SE
- Page 1 Wood burning with Design Multifuel Ready option High Cleanburn Efficiency MODEL : CARRON ECO 5KW SE Document – Version 3 Dated 16 March 2021 External Modern Air Supply Design Page 1 of 10...
- Page 2 Clean Air Act will be invalid. requirements. The Carron Eco 5kW SE stove has been recommended as suitable for use in smoke control Unless authorised by Carron, this appliance areas when burning wood logs.
-
Page 3: Installation Instructions
be well insulated, or have a wall thickness of at least 100mm Carron Eco 5kw - SE Page 3 of 10... - Page 4 During this initial firing it is normal to experience fumes and a light haze from the appliance as the paint cures during which you must ensure the room is well ventilated. Carron Eco 5kw - SE Page 4 of 10...
- Page 5 Do not leave the stove unattended during lighting. After the ignition procedure is complete, the stove must not be operated with the door open Carron Eco 5kw - SE Page 5 of 10...
- Page 6 Ventilate the room Extinguish the fire Check the chimney/flue for blockages and clean if required Seek expert advice if necessary. Carron Eco 5kw - SE Page 6 of 10...
-
Page 7: Maintenance Instructions
SPARES BHC820 – Top firebrick BHC821 - Bottom firebrick BHC822 –Back firebrick BHC823 – Side firebricks x 2 BHC826 BHC828 BHC824 BHC825 Grate Door bar Ashpan Front fire bar Carron Eco 5kw - SE Page 7 of 10... -
Page 8: Specifications
SPECIFICATIONS Carron Eco 5kw – SE Fuel Wood Mineral Fuel Flue Diameter 125mm (5”) Flue Location Nominal Output Total Efficiency 78.6% 75.5% Mean flue gas temperature 309°C 347°C Flue Draft Required 12Pa Flue Mass Gas Flow 4.0g/s 4.1g/s Mean CO emission (at 13 % 0.11%... - Page 9 Carron Eco 5kW – Performance Test Results All efficiencies in table are Net values Wood Results, 0.75 hour refuels Parameter A19/10-1 A19/10-2 A19/10-3 Mean Test Duration 0.78 0.75 0.75 0.76 Total Efficiency 78.0 78.6 79.3 78.6 Nominal heat output Mean CO2 emission 10.8...
