Transport - Attach/Remove
For ease of transport the back frame can be separated from the seat base. The back frame attaches
to the seat base by inserting the housing pins on the seat frame into the brackets on the side of the
chair back frame (see below). Due to the weight of the frame you may need two people to carry
out the following actions.
Housing pins on seat base.
Steps involved in attaching the back frame:
Step 1
Firstly lie the back on top of the base with the
top facing forward.
Step 3
Slide the brackets onto the housing pins and
push down until the back is securely in place.
22
Back Frame
Step 2
Lift the back and position the brackets over the
housing pins.
Once the back frame is in position use the
locking bolts to secure it. Tighten them securely
and NEVER USE THE CHAIR IF THEY
ARE NOT PROPERLY IN PLACE.
Housing brackets on side of the back frame.
Step 4
