Right Side View:
Left Side View:
4.4: Accessories
Warning: Use of accessories unauthorized for use with this system may result in
ineffective signal transmission or damage to the system.
Micro USB Charger:
Sensing Electrodes:
Individual Unit, Clinical Bundle
Channel 1 EMG port
Micro USB charging port
User Manual mTrigger™ Biofeedback System | V2-d4 | 06-01-21
Power Switch
(position: off)
Channel 2 EMG port
Page 9 of 27
