mTrigger Biofeedback User Manual page 15

9) Place one pair of electrodes on target muscle. See
for suggested electrode placements.
Note: For dual channel use, i.e. monitoring of activity in two separate muscles or
muscle groups, place Channel 1 electrodes on primary target and Channel 2
electrodes on secondary target.
10) Continue to Settings to define treatment parameters:
10a
10b
10c
10d
a) MVC Setup – Launch: Use this feature to assist with setting MVC goal level
i) Tap to launch the automatic maximum voluntary contraction setup protocol
Note: MVC CH1 Setup is for Ch 1 only, but turning Match Goals ON will
ensure sync Channel 1 goal to Channel 2. See 10c.)
ii) Ensure electrodes and cables are plugged into Ch 1.
iii) Select recovery phase relative to duration of entire rehabilitation program, not
within the current treatment session. This appropriately adjusts the visual
display on the next screen.
Individual Unit, Clinical Bundle
Learn more about dual channel
User Manual mTrigger™ Biofeedback System | V2-d4 | 06-01-21
Electrode Placement Database
applications.
11
10e
10f
Page 15 of 27
